Uplift Desk Adapt Pogo UDA130 Assembly Instructions

- Upright Sit/Stand mechanism
- Sit/Stand base
- Acorn Side-lock nut
- Monitor Bracket w/ tilt
- 10-32" x 3/8" SEMS PHPR screw
- 4mm x 12mm PHPR screw
- Cord clips
1. Place the rear clamp bracket
tight against the rear of work
surface and set on top of the
work surface.
2. Install lower clamp assembly
into the mating holes in the rear
clamp bracket and position as
close to the bottom of work
surface as possible. Using a
9/16" wrench, tighten the front
clamp foot and then tighten the
thumb screw by hand.
3. After securing the rear clamp bracket, place the Sit/stand base over the rear clamp
bracket and align the slots in the base over the nuts in the rear clamp bracket.
7.
UPLIFT Desk • 1-800-349-3839 • info@upliftdesk.com • www.upliftdesk.com
®
Assembly Instructions
What's in the box
- Rear Clamp Bracket
- Lower Clamp Assembly
- 3/8-16 x 3/4" Hex Bolt
- Flat Washer
- Lock Washer
- Keyboard Tray

Rear Clamp Mount Instructions

Adapt Pogo
UDA130

Optional Accessory items:

- Dual Monitor Adapter
- Writing surface
4. After pushing the base backward
against the front of the work surface, use
the supplied bolts and washers to attach
the Sit/stand base to the rear clamp
bracket with a 9/16" wrench.
5. After securing the Sit/stand base to the
work surface using the rear clamp mount as
supplied, set the Sit/stand mechanism onto
the base, matching the four (4) PEM studs
into the four (4) holes on the mechanism.
Using the four (4) Acorn nuts supplied,
secure the mechanism to the base.
6. Remove the cable tie restraining the
mechanism from inadvertent actuation.
After removing the cable tie, the
mechanism will need to be actuated in
order to attach a monitor. Keeping a hand
on the tray bracket with downward force,
press the lock release button to allow
the mechanism to rise.

Tools required:

- Phillips Screwdriver
- 3/8" Wrench
- 9/16" Wrench
