  • Page 1 Robex 380LC-9SH CRAWLER EXCAVATOR SERVICE MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENT FOREWORD 1. Structure 2. How To Read The Service Manual 3. Conversion Table SECTION 1 GENERAL Group 1 Safety Group 2 Specifications 1. Major Component 2. Specifications 3. Working Range 4. Weight 5. Lifting Capacities 6. Bucket Selection Guide 7.
  • Page 3 2. Function SECTION 3 HYDRAULIC SYSTEM Group 1 Hydraulic Circuit HYDRAULIC CIRCUIT (CLUSTER TYPE 1) HYDRAULIC CIRCUIT (CLUSTER TYPE 2) Group 2 Main Circuit 1. Suction And Delivery Circuit 2. Return Circuit 3. Drain Circuit Group 3 Pilot Circuit 1. Suction, Delivery And Return Circuit 2.
  • Page 4 Memorandum 1. Power Circuit (cluster Type 1) 2. Starting Circuit (cluster Type 1) 3. Charging Circuit (cluster Type 1) 4. Head And Work Light Circuit (cluster Type 1) 5. Beacon Lamp And Cab Light Circuit (cluster Type 1) 6. Wiper And Washer Circuit (cluster Type 1) Group 3 Electrical Component Specification Group 4 Connectors 1.
  • Page 5 Group 12 Engine Control System 1. Mcu (machine Control Unit) 2. Mcu Assembly 3. Exchange Method Of The Rom In The Cluster (type 2) 4. Engine Speed Sensor Group 13 Eppr Valve (cluster Type 1) 1. Pump Eppr Valve Eppr Valve (cluster Type 2) 1.
  • Page 6 10. When Safety Solenoid Does Not Operate 11. When Travel Speed 1, 2 Does Not Operate (hcespn 167, Fmi 5 Or 6) Group 3 Electrical System (cluster Type 2) 1. When Starting Switch Is Turned On, Monitor Panel Display Does Not Appear 2.
  • Page 7 Group 2 Major Component 1. Main Pump 2. Main Control Valve 3. Swing Device 4. Travel Motor 5. Rcv Lever 6. Rcv Pedal 7. Turning Joint 8. Cylinder Group 3 Track And Work Equipment 1. Track 2. Work Equipment SECTION 8 DISASSEMBLY AND ASSEMBLY Group 1 Precautions 1.
  • Page 8 4. Assembling Reduction Gear Group 7 Rcv Lever 1. Removal And Install 2. Disassembly And Assembly Group 8 Turning Joint 1. Removal And Install 2. Disassembly And Assembly Group 9 Boom, Arm And Bucket Cylinder 1. Removal And Install 2. Disassembly And Assembly Group 10 Undercarriage 1.

  • Page 9: Foreword

    This section shows bolt specifications and standard torque values needed when mounting components to the machine. The specifications contained in this shop manual are subject to change at any time and without any advance notice. Contact your HYUNDAI distributor for the latest information. Find manuals at https://best-manuals.com...

  • Page 10: How To Read The Service Manual

    Revised edition mark(①②③…) Any additions, amendments or other changes will When a manual is revised, an edition mark is be sent to HYUNDAI distributors. recorded on the bottom outside corner of the Get the most up-to-date information before you pages.

  • Page 11: Conversion Table

    3. CONVERSION TABLE 3. CONVERSION TABLE Method of using the Conversion Table The Conversion Table in this section is provided to enable simple conversion of figures. For details of the method of using the Conversion Table, see the example given below. Example Example Method of using the Conversion Table to convert from millimeters to inches...
  • Page 12 Millimeters to inches Millimeters to inches 1mm = 0.03937in 0.039 0.079 0.118 0.157 0.197 0.236 0.276 0.315 0.354 0.394 0.433 0.472 0.512 0.551 0.591 0.630 0.669 0.709 0.748 0.787 0.827 0.866 0.906 0.945 0.984 1.024 1.063 1.102 1.142 1.181 1.220 1.260 1.299 1.339...
  • Page 13 Liter to U.S. Gallon Liter to U.S. Gallon 1ℓ = 0.2642 U.S.Gal 0.264 0.528 0.793 1.057 1.321 1.585 1.849 2.113 2.378 2.642 2.906 3.170 3.434 3.698 3.963 4.227 4.491 4.755 5.019 5.283 5.548 5.812 6.6076 6.340 6.604 6.869 7.133 7.397 7.661 7.925 8.189...
  • Page 14 kgf·m to to lbf lbf·ft ft 1kgf·m = 7.233lbf·ft 14.5 21.7 28.9 36.2 43.4 50.6 57.9 65.1 72.3 79.6 86.8 94.0 101.3 108.5 115.7 123.0 130.2 137.4 144.7 151.9 159.1 166.4 173.6 180.8 188.1 195.3 202.5 209.8 217.0 224.2 231.5 238.7 245.9 253.2...
  • Page 15 kgf/cm kgf/cm to to lbf/in lbf/in 1kgf / cm = 14.2233lbf / in 14.2 28.4 42.7 56.9 71.1 85.3 99.6 113.8 128.0 142.2 156.5 170.7 184.9 199.1 213.4 227.6 241.8 256.0 270.2 284.5 298.7 312.9 327.1 341.4 355.6 369.8 384.0 398.3 412.5 426.7...
  • Page 16 TEMPERATURE TEMPERATURE Fahrenheit-Centigrade Conversion. A simple way to convert a fahrenheit temperature reading into a centigrade temperature reading or vice verse is to enter the accompanying table in the center or boldface column of figures. These figures refer to the temperature in either Fahrenheit or Centigrade degrees. If it is desired to convert from Fahrenheit to Centigrade degrees, consider the center column as a table of Fahrenheit temperatures and read the corresponding Centigrade temperature in the column at the left.

  • Page 17: Section 1 General

    SECTION 1 GENERAL SECTION 1 GENERAL Group 1 Safety Hints -------------------------------------------------------------------------------------------------------- 1-1 Group 2 Specifications ----------------------------------------------------------------------------------------------------- 1-10...

  • Page 18: Group 1 Safety

    SECTION 1 GENERAL SECTION 1 GENERAL GROUP 1 SAFETY GROUP 1 SAFETY FOLLOW SAFE PROCEDURE FOLLOW SAFE PROCEDURE Unsafe wor k practices are dangerous. Understand service procedure before doing work; Do not attempt shortcuts. WEAR PROTECTIVE CLOTHING WEAR PROTECTIVE CLOTHING Wear close fitting clothing and safety equipment appropriate to the job.
  • Page 19 PREPARE FOR EMERGENCIES PREPARE FOR EMERGENCIES Be prepared if a fire starts. Keep a first aid kit and fire extinguisher handy. Keep emergency numbers for doctors, ambulance ser vice, hospital, and fire department near your telephone. 13031GE04 PROTECT AGAINST FLYING DEBRIS PROTECT AGAINST FLYING DEBRIS Guard against injury from flying pieces of metal or debris;...
  • Page 20 KEEP RIDERS OFF EXCAVATOR KEEP RIDERS OFF EXCAVATOR Only allow the operator on the excavator. Keep riders off. Riders on excavator are subject to injury such as being struck by foreign objects and being thrown off the excavator. Riders also obstruct the operator's view resulting in the excavator being operated in an unsafe manner.
  • Page 21 SUPPORT MACHINE PROPERLY SUPPORT MACHINE PROPERLY Always lower the attachment or implement to the ground before you work on the machine. If you must wor k on a lifted machine or attachment, securely support the machine or attachment. Do not support the machine on cinder blocks, hollow tiles, or props that may crumble under 13031GE10 continuous load.
  • Page 22 BEWARE OF EXHAUST FUMES BEWARE OF EXHAUST FUMES Prevent asphyxiation. Engine exhaust fumes can cause sickness or death. If you must operate in a building, be positive there is adequate ventilation. Either use an exhaust pipe extension to remove the exhaust fumes or open doors and windows to bring enough outside air into the area.
  • Page 23 SERVICE MACHINE SAFELY SERVICE MACHINE SAFELY Tie long hair behind your head. Do not wear a necktie, scarf, loose clothing or necklace when you work near machine tools or moving parts. If these items were to get caught, severe injury could result.
  • Page 24 AVOID HEATING NEAR PRESSURIZED AVOID HEATING NEAR PRESSURIZED FLUID LINES FLUID LINES Flammable spray can be generated by heating near pressurized fluid lines, resulting in severe burns to yourself and bystanders. Do not heat by welding, soldering, or using a torch near pressurized fluid lines or other flammable materials.
  • Page 25 PREVENT ACID BURNS PREVENT ACID BURNS Sulfuric acid in battery electrolyte is poisonous. It is strong enough to burn skin, eat holes in clothing, and cause blindness if splashed into eyes. Avoid the hazard by: 1. Filling batteries in a well-ventilated area. 2.
  • Page 26 DISPOSE OF FLUIDS PROPERLY DISPOSE OF FLUIDS PROPERLY Improperly disposing of fluids can harm the environment and ecology. Before draining any fluids, find out the proper way to dispose of waste from your local environmental agency. Use proper containers when draining fluids. Do not use food or beverage containers that may mislead someone into drinking from them.

  • Page 27: Group 2 Specifications

    GROUP 2 SPECIFICATIONS GROUP 2 SPECIFICATIONS 1. MAJOR COMPONENT 1. MAJOR COMPONENT Battery box Fuel tank Hydraulic tank Main pump Engine Oil cooler Tooth Bucket Turning joint Swing motor Main control valve Radiator Arm cylinder Boom Boom cylinder Muffler Counterweight Bucket cylinder Connecting link Idler...

  • Page 28: Specifications

    2. SPECIFICATIONS 2. SPECIFICATIONS I(I') B(L) 3809SH2SP02 Description Unit Specification Operating weight kg (lb) 38450 (84770) Bucket capacity (SAE heaped), standard 1.62 (2.12) Overall length 11120 (36' 6") Overall width, with 600 mm shoe 3340 (10'11") Overall height 3450 (11' 4") Superstructure width 2980 ( 9' 9") Overall height of cab...

  • Page 29: Working Range

    3. WORKING RANGE 3. WORKING RANGE ·6.5 6.5 m m (21' 4") BOOM (21' 4") BOOM 3809SH2SP03 2.5 m (8' 2") Arm * 3.2 m (10' 6") Arm 3.9 m (12' 10") Arm 4.3 m (14' 1") Arm Description Max digging reach 10720 mm (35' 2") 11250 mm (36'11") 11870 mm (38'11") 12380 mm (40' 7") Max digging reach on ground 10490 mm (34' 5") 11040 mm (36' 3") 11670 mm (38' 3") 12180 mm (40' 0")
  • Page 30 ·6.15 6.15 m (20' 2") (20' 2") BOOM BOOM 3809SH2SP03 Description 2.5 m (8' 2") Arm Max digging reach 10330 mm (33'11") Max digging reach on ground 10100 mm (33' 2") Max digging depth 6450 mm (21' 2") Max digging depth (8ft level) 6270 mm (20' 7") Max vertical wall digging depth 5490 mm (18' 0")
  • Page 31 ·8.6 8.6 m (28' 3") (28' 3") BOOM BOOM 3809SH2SP03 Description 5.1 m (16' 9") Arm Max digging reach 15280 mm (50' 2") Max digging reach on ground 15120 mm (49' 7") Max digging depth 11230 mm (36'10") Max digging depth (8ft level) 11120 mm (36' 6") Max vertical wall digging depth 10060 mm (33' 0")

  • Page 32: Weight

    4. WEIGHT 4. WEIGHT R380LC-9SH Item Upperstructure assembly 15040 33160 Main frame weld assembly 3090 6810 Engine assembly 2030 Main pump assembly Main control valve assembly Swing motor assembly Hydraulic oil tank assembly Fuel tank assembly 6.5, 6.15 m boom 6500 14330 Counterweight...

  • Page 33: Lifting Capacities

    5. LIFTING CAPACITIES 5. LIFTING CAPACITIES 6.5 m (21' 4") boom, 3.2 m (10' 6") arm equipped with 1.62 m (SAE heaped) bucket and 600 mm (24") triple grouser shoe and 6500 kg (14330 lb counterweight. : Rating over-front : Rating over-side or 360 degree Load radius At max.
  • Page 34 6.15 m (20' 2") boom, 2.5 m (8' 2") arm equipped with 1.62 m (SAE heaped) bucket and 600 mm (24") triple grouser shoe and 6500 kg (14330 lb) counterweight. Load radius At max. reach 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft) Capacity...
  • Page 35 6.5 m (21' 4") boom, 3.9 m (12' 10") arm equipped with 1.62 m (SAE heaped) bucket and 600 mm (24") triple grouser shoe and 6500 kg (14330 lb) counterweight. Load radius At max. reach Load 1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft) 9.0 m (30.0 ft) Capacity Reach point...
  • Page 36 8.6 m (28' 3") boom, 5.1 m (16' 9") arm equipped with 1.46 m (SAE heaped) bucket and 600 mm (24") triple grouser shoe and 8100 kg (17860 lb) counterweight. Load radius At max. reach Load 1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft) 9.0 m (30.0 ft) 10.5 m (35.0 ft) 12.0 m (40.0 ft) 13.5 m (45.0 ft) Capacity Reach point...

  • Page 37: Bucket Selection Guide

    6. BUCKET SELECTION GUIDE 6. BUCKET SELECTION GUIDE GENERAL BUCKET GENERAL BUCKET ※1.62 m 1.46 m 1.90 m 2.10 m 2.32 m heaped bucket heaped bucket heaped bucket heaped bucket heaped bucket Recommendation mm (ft-in) Capacity 6150 8600 Tooth Width Weight (20' 2") 6500 (21' 4") boom...
  • Page 38 2) 2) HEAVY DUTY AND ROCK-HEAVY DUTY BUCKET HEAVY DUTY AND ROCK-HEAVY DUTY BUCKET ◈ 1.62 m ⊙ 1.62 m ◈ 1.90 m ⊙ 1.90 m ◈ 2.10 m heaped bucket heaped bucket Recommendation mm (ft-in) Capacity 6150 Tooth Width Weight (20' 2") 6500 (21' 4") boom...

  • Page 39: Undercarriage

    7. UNDERCARRIAGE 7. UNDERCARRIAGE 1) 1) TRACKS TRACKS X-leg type center frame is integrally welded with reinforced box-section track frames. The design includes dry tracks, lubricated rollers, idlers, sprockets, hydraulic track adjusters with shock absorbing springs and assembled track-type tractor shoes with triple grousers. 2) 2) TYPES OF SHOES TYPES OF SHOES...
  • Page 40 4) 4) SELECTION OF TRACK SHOE SELECTION OF TRACK SHOE Suitable track shoes should be selected according to operating conditions. Method of selecting shoes Method of selecting shoes Confirm the category from the list of applications in table 2, then use table 1 to select the shoe. Wide shoes (categories B and C) have limitations on applications.

  • Page 41: Specifications For Major Components
