Specifications - Kohler KARING 2.0 K-77780T-0 Installation Manual

Intelligent toilet

Advertisement

Available languages

Available languages

SPECIFICATIONS

Flushing Volume
Minimum Distance from Hole to Wall
Water Supply Pressure
Electrical Power
Outline Dimension of Product
Product Weight
Operation Environment
How to Use Piezoelectric Switch
NOTE: See "Homeowner's Guide" for detailed specifications of the bidet seat.
* Power value shall be checked under the following condition: dynamic pressure 0.2Mpa, inlet water temp 15°C.
SIMPLIFIEDDIAGRAMOFTHEUNIT
Auxiliary Panel
Fllush button
Nozzle
* Antibacterial: ring and lid contains long term anti-bacteria silver ions which will inhibit bacteria growth on surface, this does not represent the mildew and other incidental effects.
The antibacterial rate is more than 90% (test per GB21551.1-2008, GB21551.2-2010 antibacterial performance test requirements).
1250881-T01-A
3.8L
305mm
0.07MPa (Dynamic Pressure) - 0.74MPa
220V ~ 50Hz
1100W*
705mm x 451mm x 526mm
About 46kg
1 ℃-40℃
Fast Press (Caution: Hitting the switch forcefully may cause deformation.)
Bumper x 2
Press dryer button to
Seat Cover (Antibacterial*)
activate dryer function
Seat (Antibacterial*)
Seat Sensor Area
40
Light sensing area
Press button to
Press button to
activate rear wash
activate front wash
1.Standby function.
Hold "
"button (over 2s) to enter standby mode.
Details refer to "Standby function" chapter on page 15.
2. Stop function.
Press "
"button to stop flushing, dryer, air
purification, one button sterilization, manual wand
clean or UV function.
