Pamex GHFA590 Installation Instructions

Friction hold open arm

Advertisement

Quick Links

ldentify direction of hold-open
nut according to mounting.
Regular Arm-Pull Side
RH Door LH Door

Position of arms and index settings

RIGHT HAND DOOR
MAIN ARM
Regular arm installation -Pull side
Right hand door illustrated .Same dimensions apply to left hand door
Measured from hinge
Do not scale drawing
A
7
8
22
9
16
14.3
9
16
14.3
Door /wall/hardware/jamb conditions permitting
Applicable door weight 44-188 pounds
Top Jamb-Push Side
LH Door RH Door
Parallel Arm -Push Side
LH Door
LEFT HAND DOOR
FOREARM
FOREARM
inches
Dimensions are in
C
(mm)
3
5
8
136.5
1
11
(282.5mm)
8
Dim.A
Opening
3
7-
TO 120°
32
15
120°-180°
3-
16
GHFA590 Friction Hold Open Arm
RH Door
MAIN ARM
3
1-
4
44
Installation sequence.
1. Select degree of door.Use dimensions shown in chart to mark
2. Assemble main arm to closer spindle
3. Attach closer body to door with speed regulating valves toward
(180mm)
4. Attach the foot of the forearm to frame.
(100mm)
5. Adjust length of forearm to position forearm at right angle to frame.
6. Snap pinion cap over spindle at bottom of closer.
7. Adjust door closer speed,Backcheck /Delayed action.
8. Loosen the Hex nut at the elbow of the forearm by wrench.
Installation Instructions
inal adjustment and regulation.
F
Regulating door speed
and latching speed
Turn speed regulating valve
clockwise to slow down and
counter-clockwise to speed up
door movement
LATCH
OPTIONAL
DELAYED ACTION
CLOSING

Closing speed control

Latch
10°
Standard closing cycle
Attention:
Adjust closing speed time between 4 to 6 seconds from 90° opening.
Use of the door by handicapped, elderly or small children may require
longer closing time.
Screw and washer
1
1-
4
32
Pinion cap
location of attaching screws on door leaf and frame.
hinge.
Note:The nut is on the top for RH door and bottom for LH Door.
Then tighten the screw of forearm.
Open the door to the angle you need, and then tighen the hex Nut
to hold the door open.

Regulating backcheck

Turn BC regulating vave clockwise to
increase or counter clockwise to decrease.
Never close ths valve completely.
BACKCHECK
Caution:
Do not back valves out of
closer or a leak will result.
Foot
Frame
Door
Leaf
