AquaLabo LOG-AQUA User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
LOG-AQUA
User Manual
Version 1.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the LOG-AQUA and is the answer not in the manual?

Questions and answers

Summary of Contents for AquaLabo LOG-AQUA

  • Page 1 LOG-AQUA User Manual Version 1.1...
  • Page 2 It is important that you read the Quick Start Guide in a controlled environment prior to installation. Set up, activate, and successfully test the entire system (LOG-AQUA, sensors, and antenna connection) indoors, in a controlled environment, before going to the field for installation...
  • Page 3 LOG-AQUA SCHEMATIC FRONT Magnetic Activator NEMA Wavelet mechanical enclosure Slots for zip ties and/or bolts for mounting Panel connectors protector 13,3 cm (5,2 po) BOTTOM Discrete port Cellular antenna port Serial Port External power port Analog port - 3 -...
  • Page 4 LOG-AQUA INTERNAL UPPER ENCLOSURE Military-grade lithium battery pack (field replaceable, non-rechargeable) Interface board ON/OFF switch Indicator LEDs INTERNAL LOWER ENCLOSURE GSM antenna GPS antenna SIM card slot #1 SIM card slot #2 Memory card Cellular modem - 4 -...
  • Page 5 LOG-AQUA COMPONENTS Logger Activator Panel connectors protector LOG-AQUA Cellular antenna and mounting Zip ties, screws, and anchors bracket REQUIRED and sold separately) - 5 -...

  • Page 6: Sensor Connection

    SENSOR CONNECTION Connect the sensor cable(s) assembly with the field attachable connector to the mating panel connector on the LOG-AQUA. See page 17 for more details. Turn the adjustable stainless-steel end piece to secure the field attachable connector to the LOG-AQUA.

  • Page 7: External Antenna Connection

    Place the magnetic activator on the embossed logo on the front of the LOG- AQUA enclosure. The LOG-AQUA will initiate a 15-minute test mode of sampling and send a few transmissions of data. The device will then return to its default...
  • Page 8 Upper Clips Protector Arches Lower Clips a. Insert the two lower clips into the two lower holes of the LOG-AQUA enclosure. Snap the upper clips into place in the two grooves above the panel connector CAUTION: The protector is provided to shield the connector from tampering or over-exposure that could result in disconnected wiring.
  • Page 9 LOG-AQUA ACTIVATION The LED light on the back cover of the Wavelet indicates the device status. Access the AQUALABO user interface at XXXX by using your log-in credentials. Expect data to appear 5 – 10 minutes after the test mode is...
  • Page 10 If the LOG-AQUA transmits properly, change the LOG-AQUA installation then the test was successful. location and activate again. You can now install the LOG-AQUA in the field and begin to collect and view If the problem persists, contact the your data! Aqualabo Team for help: sav@aqualabo.fr...
  • Page 11 LOG-AQUA SPECIAL INSTALLATIONS LOCATIONS WEAK SIGNAL LOCATIONS UNDERGROUND/INDOOR If the LOG-AQUA is installed in an area If the LOG-AQUA is installed in an area with weak cellular signal, activate the with weak cellular signal, activate the LOG-AQUA and place in the intended...
  • Page 12 LOG-AQUA MONTAGE DU LOG-AQUA Additional tools and/or materials might be required (not included) Rotary hammer Screwdriver with bit - 12 -...
  • Page 13 LOG-AQUA LOG-AQUA MOUNTING Secure the LOG-AQUA on a wall, pipe, or other secure mount location by using zip ties or screws. Wall mounted Pipe mounted - 13 -...

  • Page 14: Antenna Mounting

    ✓ Mount antenna at least 5cm (2in.) of these methods for initiating data away from the LOG-AQUA. transmission. Repeating the use of either ✓ Finalize the antenna setup to the method will not expedite data transmission.
  • Page 15 LOG-AQUA ANTENNA MOUNTING - TROUBLESHOOTING If the Wavelet does not transmit, move the antenna to a different position. If the Wavelet still does not transmit after multiple attempts at repositioning the antenna, consider using an alternative solution, such as an in-road or a high-gain antenna.
  • Page 16 LOG-AQUA YOUR LOG-AQUA IS SUCCESSFULLY INSTALLED ! - 16 -...
  • Page 17 LOG-AQUA LOG-AQUA PINOUT Panel Inputs Connector 4x analog and 1x discrete RS485, RS232, SDI-12 (16 channels) 4x discrete 6-24VDC - 17 -...
  • Page 18 LOG-AQUA AQUALABO 90 Rue du Professeur Paul Milliez • 94506 Champigny sur Marne • France Tel.: +33 (0)1 55 09 10 10 Hotline: +33(0)4 11 71 97 41 E-mail: info@aqualabo.fr Website: https://www.aqualabo.fr/ - 18 -...
