TRANSPORTING THE FLOAT
After the float has been lifted onto a flatbed truck, do
the following:
1. Locate the tie-down symbols (Figure 4) on each side
of the float.
Figure 4. Tie-Down Symbol
2. Attach suitable tie-down straps to the locations marked
by the tie-down symbols. Be sure to connect the
tie-down strap hooks directly to the float as shown in
Figure 5. DO NOT wrap the tie-downs around the frame
as shown in Figure 6.
NOTICE
Use tie-downs with flat hooks or U-hooks only.
Figure 5. Tie-Down Method (Correct)
PAGE 16 — PRX RIDE-ON POWER FLOAT • OPERATION MANUAL — REV. #1 (01/05/21)
FLATBED
HOOK
TIE-DOWN
STRAP
CORRECT
LIFTING AND TRANSPORTING
Figure 6. Tie-Down Method (Incorrect)
3. Secure the float to a flatbed (Figure 5) with the tie-down
straps, making sure they are properly tied to prevent
movement of the float during transport.
INCORRECT
