- Page 1 Quick Start C3 Professional HD PTZ Camera with Intelligent Tracking 8-30-2021...
-
Page 2: Table Of Contents
Quick Start C3 Professional HD PTZ Camera with Intelligent Tracking DVDO C3 camera analyzes movements and faces and adjusts its position based on settings. The following configuration is ideal for teaching or presentation purposes. Connect C3 to your LAN Calibrate Camera... -
Page 3: Connect C3 To Your Lan
TS: Need new photo….. Connect DVDO C3 ● Use Ethernet cable to connect C3 Cam directly to a PC. If you do not have a PC with Ethernet port purchase USB to Ethernet adapter. ● Connect power and turn power switch on. - Page 4 Connect C3 to your LAN Update your PC’s IP address (continued) ● Select IPv4 ● Click [Properties] ● Select Use the following IP Address and Enter IP addresses as shown Make note of your current settings before you change them.
- Page 5 Connect C3 to your LAN C3 Web Interface Change IP Configuration This will allow you to access the C3 over your network. ● Maximize the web interface window to change Language. Must have 1080p monitor or better to change language.
- Page 6 Only use Teacher Tab. Tracking software has been designed for additional functionality that is not required for DVDO C3 Cam. Enter C3 IP Address from step 1 ● Enter C3 IP Address into Feature IP and Click [Connect] ● Enter C3 IP Address into Pano IP and Click [Connect] ●...
-
Page 7: Calibrate Camera
Calibrate C3 Camera Camera Placement ● Installation distance from camera to presenter is recommended between 6-10 meters. ● We recommend installation height of the tracker at 2-3 meters; with optimal height between 2.2-2.4 meters. ● Adjust Pano Cam up and down to set coverage of trackable area. - Page 8 Calibrate C3 Camera Calibrating Feature PTZ Cam to the Pano Cam ● Click [Stop Track] then click >expand> or <fold< to access full menu. ● Click Pano Lens Pos tab and check Show Calibration Cross ● Using the PTZ controls, position PTZ Feature Cam image in top box to...
-
Page 9: Set Coverage Presets
Set Coverage Presets Set Coverage Presets. Motion Coverage Motion Coverage Preset 2 Preset 1 *Optional No Motion Coverage Preset 0 Pano Cam Image ● Position PTZ Feature Cam for each Coverage Presets shown above. Each Coverage Preset is made up of a zoom and a position. Only Coverage Preset 0 and 1 are required. -
Page 10: Start Tracking
Start Tracking When [Start Track] is turned on PTZ Feature Cam will track a person. PTZ Cam tracks person As person moves PTZ Cam tracks... -
Page 11: Tracking Area And Shield Area
Tracking Area and Shield Area Set Tracking Area ● To set tracking area, press [Stop Track]. Set tracking area by clicking [Show] to bring up the current area, then use left mouse button click in image to draw tracking area. Then click [Start Track]. -
Page 12: Basic Settings And Navigate Key Action
Basic Settings and Navigate Key Action... -
Page 13: Target Lost Action And Multi Object Action
Target Lost Action and Multi Object Action... -
Page 14: Track Settings And Teacher Board Settings
Track Settings and Teacher Board Settings... -
Page 15: Tracking Mode
Tracking Mode... -
Page 16: Parameter Backup
Parameter Backup...
