LAUNCH
Fixed frequency simulation
Predefined waveform simulation
Hand-drawn waveform
simulation
Signal generator interface
External power supply port
Solenoid interface
Multimeter interface
Working temperature
Storage temperature
Multimeter:
Parameter
DC voltage
AC voltage
Resistance
Capacitance
Diode
Continuity detection
www.diagtools.eu, Pernavas 43A, Riga, Latvia, LV-1009, +37129416069, info@diagtools.eu
X-431 Module S2 User Manual
Support
Support
Support
2
1
2
2
0℃~50℃
-30℃~70℃
Range
0V~700V
0V~700V
0Ω~40MΩ
0F~100uF(maximum 30s measurement time)
0V~1.5V
Sounds below 30Ω
5
