- Page 1 Quick Start Guide TEK-BAR 3800E Utilities/Non-Explosion Proof Multivariable Transmitter 796 Tek Drive, Crystal Lake, IL 60014 USA +1 847 857 6076 +1 847 655 6147 www.tek-trol.com...
- Page 2 Do not remove the transmitter covers in explosive environments when the circuit is live. Make sure the transmitter is installed by qualified personnel and in accordance with applicable codes of practice. 2. Unpack Tek-Bar 3800E Utilities/Non-Explosion Proof Multivariable Transmitter 3. Dimensional Drawing Horizontal Impulse Piping Type 8”...
- Page 3 Total reset: Clearing the accumulated traffic. Setup: Setting instrument run parameters. Calibration: Setting the flow parameters and the temperature channel, pressure channel, current output, flow coefficient and differential pressure transmitter zero calibration settings. Password: Modifying the settings, clear and calibrate passwords. TEK-BAR 3800E...
- Page 4 Quick Start Guide 5. Power Supply Fig 6: Wiring Connection 1. Power supply: 1: Power supply 24V + 2: Power supply 24V- 2. Current output: 1: Power supply 24V+ 2: Current output I+ (with HART communication) 3. Pulse: 2: Pulse negative 3: Pulse positive 4.
- Page 5 Place taps on the side and mount the transmitter beside or below the taps. Ensure that the drain or vent valves are oriented upwards. Fig 7: Liquid Flow Installation • Gas Flow Place taps on the top of the line and mount the transmitter above the taps. Fig 8: Gas Flow Installation TEK-BAR 3800E...
- Page 6 Quick Start Guide • Steam Flow Use impulse lines to place the transmitter away from the line. Place taps on the side of the line. Mount the transmitter beside or below the taps. Fill impulse lines with water at start-up. Fig 10: Steam Flow Installation 7.
- Page 7 Tek-Trol Middle East FZE PO Box 121 Windsor, Colorado Florijnstraat 18, 4879 AH SAIF Zone, Y1-067, PO BOX No. 80550, USA Etten-Leur, Netherlands 21125, Sharjah, UAE Sales: +1 847-857-6076 Sales: +31 76-2031908 Sales: +971-6526-8344 Support: +1 847-857-6076 Email: tektrol@tek-trol.com www.tek-trol.com TEK-BAR 3800E...
