Triton LocBoard LB2 Installation & Assembly Instructions

LB2-Kit, BKit, RKit, - (2) 24" x 42-1/2" LocBoard®(s), 63 Hooks
Read all instructions completely before installing. Should you have any questions about your
installation, please call Customer Service at 440-248-5480

Review Carton Contents:

2 Pcs. LocBoard Pegboard 24" x 42.5" (BKit= Blue, RKit=Red, Kit=White)
63 Pcs. Assortment of LocHook® Pegboard Hooks
1 Pk. Wall Mounting Hardware
•
Boards can be positioned side by side or in separate location in vertical or horizontal mounting
positions.
•
Pegboards fasten directly to concrete, solid wood and hollow wall structures without the use of
furring strips.
•
Pegboards are designed with internal mounting flanges that keep mounting hardware hidden
from sight and add to the board's structural integrity and holding power.
•
If installing to bare studs you will need to install wood headers before completing installation.
LocBoard™ Installation:
Tools needed for Installation (not supplied with kit)
Level, marker, 7/32" standard or masonry drill bit, 7/64" drill bit for wood studs, #2 Phillips head
screwdriver, power drill.
For drywall, hollow concrete wall installation: Use (12 each) plastic drywall anchors and #8 Phillips
head wood screws (SUPPLIED WITH THIS SYSTEM). If installing to bare studs you will need to install
wood headers before completing installation using wood screws only. NOTE: Always install one board at
a time.
1. (IMPORTANT!) Select wall location for your LocBoards and the desired vertical or horizontal mounting
pattern you wish to mount in. When selecting a location for mounting always make sure that mounting
locations do not fall in line with, are adjacent to or interfere with any internal or external electrical
wiring, wall mounted or built-in electrical appliances, heaters, gas lines, ductwork or plumbing inside of
wall, or are located on the opposite side of any wall surface from where you are mounting. If you are
unsure, please consult a professional before proceeding with installation.
2. There are twelve screw holes on the back of your LocBoard that are accessible through the square
holes on the front (see images on back).
3. Place one LocBoard flat against wall surface, while using a level to make sure your board is straight
and squared. Mark a minimum of 2 mount hole locations per bracket using figure 1-1: Note: Installation
for first board should be completed before marking mounting holes for the second board.
4. Pre-drill holes for #8 wall anchors marked in Step 3 using 7/32" standard or masonry drill bit
depending on wall surface. If you hit a wood stud stop drilling and using a 7/64" drill bit create a pilot
hole for the wood screw, Note: avoid over-drilling holes. (Plastic wall anchors should fit snug.)
5. Insert plastic wall anchors in each hole drilled in Step 4 except where you drilled 7/64" pilot hole for
wood stud.
