Making British gardens great
SLATTED CORNER PERGOLA
INSTRUCTIONS
We recommend using the following tools (NOT SUPPLIED):
Pozidrive
Tape
Screwdriver
Measure
It is vital that you build your new pergola on a level ground in your desired location.
FIXING PACK CONTAINS:
6 x 120mm Screws
QTY: 12
PLEASE KEEP PLASTIC BAGS AND SMALL PARTS AWAY FROM CHILDREN
IMPORTANT
Assembly requires 5+
adults.
THE ROOF OF THIS PERGOLA IS NOT A LOAD BEARING STRUCTURE
Missing something or need more information?
Call our aftersales team on
0333 777 7089
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
Drill & 2mm
Hammer
Drill Bit
5 x 80mm Screws
QTY: 20
Visit our website for spare instructions and
more information
www.forestgarden.co.uk
FIXING PACK CODE: SCP90FP
Ladder
4 x 50mm Screws
QTY: 24
REMINDER
Always pre-drill before
screwing.
ISSUE: 0321
Spirit Level
Advertisement
Table of Contents
Related Manuals for Forest SCP90FP
Summary of Contents for Forest SCP90FP
- Page 1 THE ROOF OF THIS PERGOLA IS NOT A LOAD BEARING STRUCTURE Missing something or need more information? Visit our website for spare instructions and more information Call our aftersales team on 0333 777 7089 www.forestgarden.co.uk Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB...
- Page 2 PREPARATION We strongly advise that you anchor your pergola down with either fixtures shown below to enhance stability. You will need to purchase these separately. Apply each fixture to each leg before fully constructing your pergola. 130mm of your post will be supported within the fixture. FOR GRASS/SOIL (SOFT SURFACES) Easy-Fit Fencefast...
- Page 3 BACK CORNER FRONT CORNERS FRONT POST FRONT POST BACK POST SCREWS SCREWS Assemble this stage with 3 adults holding onto a post each. If your 3 posts are anchored, use the measurements provided as a guide for spacing. Lift up the assembled roof and place onto the designated grooves provided on the Back Post and Front Posts as shown above.
- Page 4 CHECK YOU HAVE ALL YOUR PARTS. (The parts do not have codes on them. They are listed below should you need to order one.) The components provided may be heavy. Please lift with caution and with a minimum of 2 people. Slatted Corner Pergola (SCP90) Description Part Code...
