NI PXIe-4137 Specifications page 30

Figure 11. 10 μs Pulse Output with Load, Fast Transient Response
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0
Solution
SourceAdapt allows users to set the desired gain bandwidth, compensation frequency, and
pole-zero ratio through custom transient response to obtain the desired pulse waveform. To
use SourceAdapt, first set the Transient Response to Custom.
To achieve the resulting waveform in the following figure, use the parameters in the
following table.
Figure 12. 10 μs Pulse Output with Load, Custom Transient Response
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0
30 | ni.com | PXIe-4137 Specifications
50 100 150
50 100 150
200 250 300
Time (us)
200 250 300
Time (us)
350 400 450
350 400 450
500
500
