Dorner 2100 Series Safety, Setup, Operation & Maintenance Manual

Center mount drive package for standard & heavy load 60 hz gearmotors
Hide thumbs Also See for 2100 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
for Standard & Heavy Load 60 Hz Gearmotors
Introduction
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Required Tools
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2100 & 6100 Series
Center Mount Drive Package
. . . . . . . . . . . . . . . . . . . . .
Setup, Operation
& Maintenance Manual

Table of Contents

2
Preventative Maintenance & Adjustment
2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
3
5
5
5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
851-292 Rev. B
7
7
7
8
8
8
10
11
12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dorner 2100 Series

Summary of Contents for Dorner 2100 Series

  • Page 1: Table Of Contents

    Setup, Operation & Maintenance Manual 2100 & 6100 Series Center Mount Drive Package for Standard & Heavy Load 60 Hz Gearmotors Table of Contents Warnings – General Safety ..... Preventative Maintenance &...

  • Page 2: Warnings - General Safety

    Dorner’s Limited Warranty applies. D Inspect packages for shipping damage. Contact carrier re- Dorner reserves the right to make changes at any time garding damage. without notice or obligation. D Accessories may be shipped loose. See accessory in- structions for installation.

  • Page 3: Product Description

    Mount Style: 1 = Type 1, Veritical Mount; 2 = Type 2, Bottom Mount Language Code = US English 2 = 2100 Series Conveyor 6 = 6100 Series Conveyor * See “Ordering and Specifications” Catalog for details. Table 1: Gearmotor Specifications...
  • Page 4 29 – 242 9 – 74 NOTE: For belt speed other than those listed, con- tact factory for details. 2100 & 6100 Series Center Mount Drive Package for Standard & Heavy Load 60Hz Gearmotors SOMM 851-292 Rev. B Dorner Mfg. Corp.

  • Page 5: Installation

    1 or 4 (Figure 3). 103 in-lb (12 Nm). Figure 5 Figure 3 2100 & 6100 Series Center Mount Drive Package for Standard & Heavy Load 60Hz Gearmotors SOMM Dorner Mfg. Corp. 851-292 Rev. B...
  • Page 6 Ç Drive shaft keyway may be sharp. HANDLE WITH CARE. Install key (N of Figure 8). Figure 9 2100 & 6100 Series Center Mount Drive Package for Standard & Heavy Load 60Hz Gearmotors SOMM 851-292 Rev. B Dorner Mfg. Corp.

  • Page 7: Timing Belt Tensioning

    Install cover (K of Figure 11) with four (4) screws Loosen tensioner (V of Figure 12). (L). Tighten screws to 35 in-lb (4 Nm). 2100 & 6100 Series Center Mount Drive Package for Standard & Heavy Load 60Hz Gearmotors SOMM Dorner Mfg. Corp. 851-292 Rev. B...

  • Page 8: Timing Belt Replacement

    Install cover (K of Figure 11) with four (4) screws (L). Tighten screws to 35 in-lb (4 Nm). Figure 14 2100 & 6100 Series Center Mount Drive Package for Standard & Heavy Load 60Hz Gearmotors SOMM 851-292 Rev. B Dorner Mfg. Corp.
  • Page 9 Wrap timing belt around drive pulley and complete step 13. Complete steps 6 through 9 of “Installation” section on page 6. 2100 & 6100 Series Center Mount Drive Package for Standard & Heavy Load 60Hz Gearmotors SOMM Dorner Mfg. Corp. 851-292 Rev. B...

  • Page 10: Motor Replacement

    D For a three phase motor, reverse step 2, on this page. D For a DC variable speed motor, reverse step 3 on this Figure 20 page. 2100 & 6100 Series Center Mount Drive Package for Standard & Heavy Load 60Hz Gearmotors SOMM 851-292 Rev. B Dorner Mfg. Corp.

  • Page 11: Service Parts

    Service Parts NOTE: For replacement parts other than those shown on this page, contact an authorized Dorner Service Center or the factory. Item Part No. Part Description Motor, 0.25hp (0.19Kw), 115/230 Volts, 826-328 60 Hz, 1-Phase Motor, 0.25hp (0.19Kw), 115/230 Volts,...

  • Page 12: Return Policy

    Authorization Number to reference. There will be a 15% restocking charge on all new items returned for credit where Dorner was not at fault. These will not be accepted after 60 days from original invoice date. The restocking charge covers inspection, cleaning, disassembly, and reissuing to inventory.
