  • Page 1 Altos BrainSphere P555 F5 USER’S Guide Revision 1.0...
  • Page 2 Preface About This Manual This manual is written for system integrators, IT technicians and knowledgeable end users. It provides information for the installation and use of the P555 F5. About This System Built upon the functionality and capability of the AMD EPYC™ 7002 Series Processor processor, the P555 F5 provides superior graphics capability and system performance while consuming little power.

  • Page 3: Table Of Contents

    P555 F5 User's Manual Table of Contents Chapter 1 Introduction 1.1 Quick Reference.........................1 0 Quick Reference Table......................1 1 Motherboard Features.......................1 3 1.2 Processor and Chipset Overview..................1 6 1.3 Special Features ........................1 6 Recovery from AC Power Loss..................1 6 1.4 System Health Monitoring ....................17 Onboard Voltage Monitors ....................1 7 Fan Status Monitor with Firmware Control ...............17 Environmental Temperature Control .................17...
  • Page 4 P555 F5 User's Manual 2.7 Jumper Settings .........................45 How Jumpers Work......................45 2.8 LED Indicators........................47 Chapter 3 Troubleshooting 3.1 Troubleshooting Procedures ....................49 Before Power On ......................49 No Power ..........................49 No Video ...........................50 System Boot Failure......................50 Memory Errors ........................50 When the System Loses its Setup Configuration .............50 When the System Becomes Unstable ................51 3.2 Technical Support Procedures ...................52 3.3 Battery Removal and Installation ..................55...
  • Page 5 Preface Appendix B Standardized Warning Statements B.1 Battery Handling .........................9 2 B.2 Product Disposal.........................94 Appendix C UEFI BIOS Recovery C.1 Overview..........................9 5 C.2 Recovering the UEFI BIOS Image ..................97 C.3 Recovering the BIOS Block with a USB Device ..............97...
  • Page 6 P555 F5 User's Manual Chapter 1 Introductio...

  • Page 7: Chapter 1 Introduction

    Chapter 1: Introduction Figure 1-1. P555 F5 Mobthboard Image Note: All graphics shown in this manual were based upon the latest PCB revision available at the time of publication of the manual. The motherboard you received may or may not look exactly the same as the graphics shown in this manual.

  • Page 8: Quick Reference

    P555 F5 User's Manual 1.1 Quick Reference USB0/1 UID-SW LAN1 IPMI LAN UID-LED LAN2 USB2/3 JPL1 COM1 LEDM1 JPWR1 JPG1 FAN5 JNCSI1 JBT1 JTPM1 JWD1 JIPMB1 USB4/5 JOH1 SGPIO2 JUID M.2-M1 L-SAS4-7 JPS1 SGPIO1 L-SAS0-3 M.2-M2 JPWR3 JPWR2 JSD1 I- SATA0 I- JPI2C1 SATA1...

  • Page 9: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting UID SW Unit ID switch (push-button toggle switch ON/OFF) JBT1 Clear CMOS Open (Normal) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPS1 SAS Enable/Disable Pins 1-2 (Enabled) JWD1 Watch Dog control Pins 1-2 (Reset) JPL1 LAN Enable/Disable...
  • Page 10 P555 F5 User's Manual Connector Description JPWR3 24-pin ATX power supply connector JPWR1 12V 8-pin CPU core power supply connector JPWR2 12V 8-pin CPU core power supply connector Front panel external speaker header JPI2C1 Power supply SMBus I C header LAN1, LAN2 Back panel LAN1, LAN2 connectors Back panel VGA port...
  • Page 11 Chapter 1: Introduction Systme Features Features • Single AMD EPYC™ 7002 Series Processor in a Socket SP3 Memory • 2TB Registered ECC DDR4-3200 SDRAM in eight DIMM slots DIMM Size • Up to 128GB size at 1.2V Chipset • System on Chip Expansion Slots •...
  • Page 12 P555 F5 User's Manual Features BIOS • 256Mb SPI AMI BIOS • ACPI 5.1, SMBIOS 3.1.1, Plug-and-Play (PnP), BIOS rescue hot-key, RTC (Real Time Clock) wake up, Riser Card Auto- Detection Support Power Management • ACPI power management (S5) • Power button override mechanism •...
  • Page 13 Chapter 1: Introduction SATA 8-15 G3 [0-7] NVMe 2-3 Slot 2 G3 [8-15] REV ERSA L PCIe x8 SATA 0-7 G2 [0-7] NVMe 0-1 G2 [8-11] PCIe x4 M.2 R E V E RSA L G2 [12-15] PCIe x4 M.2 R EV E RSA L Slot 1 G1 [0-15]...

  • Page 14: Processor And Chipset Overview

    P555 F5 User's Manual 1.2 Processor and Chipset Overview The P555 F5 offer maximum I/O expandability, energy efficiency, and data reliability in a 7-nm process architecture, and is optimized for high performance computing, NVMe storage solutions, and ideal for High Density Data Center applications. The P555 F5 supports the new microarchitecture 7-nm process technology, which drastically increases system performance for a multitude of server applications.

  • Page 15: System Health Monitoring

    Chapter 1: Introduction 1.4 System Health Monitoring This section describes the health monitoring features of the P555 F5 motherboard. The motherboard has an onboard Baseboard Management Controller (BMC) chip that supports system health monitoring. Once a voltage becomes unstable, a warning is given or an error message is sent to the screen.

  • Page 16: Acpi Features

    P555 F5 User's Manual 1.5 ACPI Features ACPI stands for Advanced Configuration and Power Interface. The ACPI specification defines a flexible and abstract hardware interface that provides a standard way to integrate power management features throughout a computer system including its hardware, operating system and application software.

  • Page 17: Feont Panel & I/O

    P555 F5 User's Manual 1.7 Front Panel & I/O Coolant Level Coolant Inlet Temp Display USB 3.0 * 2...

  • Page 18: Internal Plancement (Liquis Cooling)

    P555 F5 User's Manual 1.8 Internal Placement (Liquid Cooling) ACPI stands for Advanced Configuration and Power Interface. The ACPI specification defines a flexible and abstract hardware interface that provides a standard way to integrate power management features throughout a computer system including its hardware, operating system and application software.

  • Page 19: Internal Plancement (Air Cooling)

    P555 F5 User's Manual 1.9 Internal Placement (Air Cooling) ACPI stands for Advanced Configuration and Power Interface. The ACPI specification defines a flexible and abstract hardware interface that provides a standard way to integrate power management features throughout a computer system including its hardware, operating system and application software.

  • Page 20: Chapter 2 Installation

    Chapter 2 Installation 2.1 Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic components. To prevent damage to your motherboard, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. Precautions •...

  • Page 21: Processor And Heatsink Installation

    Chapter 2: Installation 2.2 Processor and Heatsink Installation Warning: When handling the processor package, avoid placing direct pressure on the label area of the fan. Important: • For the Processor/Heatsink installation you need to use a T20 screwdriver when opening/ closing the CPU socket.
  • Page 22 P555 F5 User's Manual 2. The spring-loaded Force Frame will raise up after the last screw securing it (#1) is removed. Gently allow it to lift up to its stopping position. 3. Lift the Rail Frame up by gripping the lift tabs near the front end of the rail frame. While keeping a secure grip of the Rail Frame, lift it to a position so you can do the next step of removing the External Cap.
  • Page 23 Chapter 2: Installation 4. Remove the External Cap from the Rail Frame by pulling it upwards through the rail guides on the Rail Frame. External Cap PnP Cover Cap 5. The CPU Package is shipped from the factory with the Carrier Frame pre-assembled. Grip the handle of the Carrier Frame/CPU Package assembly from its shipping tray, and while gripping the handle, align the flanges of the Carrier Frame onto the rails of the Rail Frame so its pins will be at the bottom when the Rail Frame is lowered later.
  • Page 24 P555 F5 User's Manual Note: You can only install the CPU inside the socket in one direction with the handle at the top. Make sure that it is properly inserted into the CPU socket before closing the Rail Frame plate. If it doesn't close properly, do not force it as it may damage your CPU. Instead, open the Rail Frame plate again, and double-check that the CPU is aligned properly.
  • Page 25 Chapter 2: Installation 8. Gently lower the Rail Frame down onto the socket until the latches on the Rail Frame engage with the Socket housing. and it rests in place. DO NOT force it into place!
  • Page 26 P555 F5 User's Manual 9. Gently lower the Force Frame down onto the Rail Frame and hold it in place until it is seated in the Socket housing. Note that the Force Frame is spring loaded and has to be held in place before it is secured.
  • Page 27 Chapter 2: Installation 11.After the Force Frame is secured and the CPU package is in place, now you must install the heatsink to the frame. Lower the heatsink down till it rests securely over the four screw holes on CPU Package on the socket frame. 12.
  • Page 28 P555 F5 User's Manual Un-installing the Processor and Heatsink 1. Remove the heatsink attached to the top of the CPU Package by reversing the installation procedure. 2. Clean the Thermal grease left by the heatsink on the CPU package lid to limit the risk of it contaminating the CPU package land pads or contacts in the socket housing.

  • Page 29: Memory Support And Installation

    Chapter 2: Installation 2.3 Memory Support and Installation Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The P555 F5 supports up to 2TB Registered ECC DDR4 3200MHz speed, RDIMM/LRDIMM 3DS/3DS RDIMM memory in eight slots. Refer to the table below for additional memory information.

  • Page 30: Dimm Module Population

    P555 F5 User's Manual DIMM Module Population There is no specific order or sequence required when installing memory modules. However do keep the following in mind: • Always use DDR4 DIMM modules of the same type, size and speed. • Mixed DIMM speeds can be installed.
  • Page 31 Chapter 2: Installation DIMM Poulation Guide (with AMD 7002 Processor) CPU# Channel 1 DIMM (supported but not recommend) CPU1 2 DIMMs (supported but not recommend) CPU1 4 DIMMs (condictionally recommended if 32 cores or fewer) CPU1 8 DIMMs CPU1 16 DIMMs CPU1 Note: Most configurations populating fewer than eight channels are supported, but not recom- mended.

  • Page 32: Dimm Installation

    P555 F5 User's Manual DIMM Installation 1. Insert the desired number of DIMMs into the memory slots, there is no specific sequence or order required. Receptive 2. Push the release tabs outwards on both Point ends of the DIMM slot to unlock it. 3.

  • Page 33: Rear I/O Ports

    Chapter 2: Installation 2.4 Rear I/O Ports See Figure 2-1 below for the locations and descriptions of the various I/O ports on the rear of the motherboard. Figure 2-1. I/O Port Locations and Definitions Rear I/O Ports Description Description Description COM Port USB 1 (3.0) LAN Port #1...
  • Page 34 P555 F5 User's Manual 1. COM Port There is one serial communications port (COM1) on the rear I/O panel. 2. IPMI LAN Port One IPMI LAN port is located on the I/O back panel. This port accepts an RJ45 type cable. 3~6.

  • Page 35: Front Control Panel

    Chapter 2: Installation 2.5 Front Control Panel JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis.. See the figure below for the location of JF1. 3.3V PWR LED 3.3V Stby HDD LED...

  • Page 36: Connectors

    P555 F5 User's Manual 2.6 Connectors Onboard Fan Headers (FAN1~FAN5, FANA, FANB) There are seven fan headers on the motherboard. These are 4-pin fan headers; pins 1-3 are backward compatible with traditional 3-pin fans. The onboard fan speeds are controlled by Thermal Management (via Hardware Monitoring) in the BMC.
  • Page 37 Chapter 2: Installation L-SAS Ports (L-SAS0~L-SAS7), The motherboard supports eight SAS ports on two onboard connectors, L-SAS0~L-SAS3 and L-SAS4~L-SAS7. Connect hard drives to these SAS ports using a MiniSAS to 4 breakout cable, one for each connector that supports up to four drives each. SATA/SAS Connectors Pin Definitions Pin#...
  • Page 38 P555 F5 User's Manual TPM Header/Port 80 Connector (TPM Port) The JTPM1 header is used to connect a Trusted Platform Module (TPM), which is available from a third-party vendor. A TPM is a security device that supports encryption and authentication in hard drives.
  • Page 39 Chapter 2: Installation USB Ports (USB0~USB5) There are a total of six USB ports supported on the motherboard. Four are located on the back panel (USB 0/1 (3.0) and USB 2/3 (3.0)). There are also two ports located on the motherboard header (USB 4/5 (3.0)).
  • Page 40 P555 F5 User's Manual Onboard Battery (BT1) The onboard back up battery is located at BT1. The onboard battery provides backup power to the on chip CMOS, which stores the BIOS' setup information. It also provides power to the Real Time Clock (RTC) to keep it running. NCSI Header (JNCSI1) The NCSI (Network Controller Sideband Interface) header is located at JNCSI1.
  • Page 41 Chapter 2: Installation Standby Power Header (JSTBY1) The Standby Power header is located at JSTBY1 on the motherboard. Standby Power Pin Definition Pins Definition +5V Standby Ground Wake-up IPMB System Management Bus Header (JIPMB1) A System Management Bus header for IPMI 2.0 is located at JIPMB1. Connect the appropriate cable here to use the IPMB I C connection on your system.
  • Page 42 P555 F5 User's Manual 12V 8-pin Auxilliary Power Connector (JPWR1) JPWR1 is an 8-pin ATX power input to provide core power to the processor. Refer to the table below for pin definitions. 12V 8-pin Power Connector Pin Definitions Pins Definition 1 through 4 Ground 5 through 8...

  • Page 43: Jumper Settings

    Chapter 2: Installation 2.7 Jumper Settings How Jumpers Work To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin #1 is identified with a thicker border line on the printed circuit board. See the diagram below for an example of jumping pins 1 and 2.
  • Page 44 P555 F5 User's Manual VGA Enable/Disable (JPG1) JPG1 allows you to enable or disable the VGA port. The default position is on pins 1 and 2 to enable VGA. See the table below for jumper settings. VGA Enable/Disable Jumper Settings (JPG1) Jumper Setting Definition Pins 1-2...

  • Page 45: Led Indicators

    Chapter 2: Installation 2.8 LED Indicators LAN Port LEDs The motherboard's Ethernet ports has two LED indicators. The Activity LED is yellow and indicates connection and activity. The Link LED may be green, amber, or off to indicate the speed of the connection. Refer to the tables below for more information. Link LED Activity LED Link LED...
  • Page 46 P555 F5 User's Manual UID Switch and LED Indicator (UID LED & UID-SW) The rear UID LED is located next to the UID switch. The front UID LED is located on the front panel. When you press the UID switch, both rear and front UID LED indicators will turn on. Press the UID switch again to turn off the LED indicators.

  • Page 47: Chapter 3 Troubleshooting

    Chapter 3: Troubleshooting Chapter 3 Troubleshooting 3.1 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/ or ‘Returning Merchandise for Service’ section(s) in this chapter. Always disconnect the AC power cord before adding, changing or installing any non hot-swap hardware components.

  • Page 48: No Video

    P555 F5 User's Manual No Video 1. Check that the VGA cable is connected properly, and the monitor is on. 2. Set JPG1 to [1-2] and check if you follow the guidelines to install the memory module (see DIMM Module Population in chapter 2). 3.

  • Page 49: When The System Becomes Unstable

    Chapter 3: Troubleshooting When the System Becomes Unstable A. If the system becomes unstable during or after OS installation, check the following: 1. CPU/BIOS support: Make sure that your CPU is supported and that you have the latest BIOS installed in your system. 2.

  • Page 50: Technical Support Procedures

    P555 F5 User's Manual component in question in another system. If the new system works, the component is good and the old system has problems. 3.2 Technical Support Procedures Before contacting Technical Support, please take the following steps. Also, note that as a motherboard manufacturer, we do not sell directly to end-users, so it is best to first check with your distributor or reseller for troubleshooting services.
  • Page 51 Chapter 3: Troubleshooting than your BIOS before downloading. You can choose from the zip file and the .exe file. If you choose the zip BIOS file, please unzip the BIOS file onto a bootable USB device. Run the batch file using the format FLASH.BAT filename.rom from your bootable USB device to flash the BIOS.
  • Page 52 P555 F5 User's Manual Question: When I ran the setup.exe to install the AMD SP3 I/O driver on Windows, the following message showed up: Answer: It happens in some environments. To solve this problem, click OK and save the installation package to the location you specify. The driver is then installed automatically.

  • Page 53: Battery Removal And Installation

    Chapter 3: Troubleshooting 3.3 Battery Removal and Installation Battery Removal To remove the onboard battery, follow the steps below: 1. Power off your system and unplug your power cable. 2. Locate the onboard battery as shown below. 3. Using a tool such as a pen or a small screwdriver, push the battery lock outwards to unlock it.

  • Page 54: Proper Battery Disposal

    P555 F5 User's Manual Proper Battery Disposal Please handle used batteries carefully. Do not damage the battery in any way; a damaged battery may release hazardous materials into the environment. Do not discard a used battery in the garbage or a public landfill. Please comply with the regulations set up by your local hazardous waste management agency to dispose of your used battery properly.

  • Page 55: Chapter 4 Uefi Bios

    Chapter 4: UEFI BIOS Chapter 4 UEFI BIOS 4.1 Introduction This chapter describes the AMI BIOS™ Setup utility for P555 F5 system that are equipped with the EPYC 7002 Series Processor. The BIOS is stored on a chip and can be easily upgraded using a flash program.

  • Page 56: Main Setup

    P555 F5 User's Manual 4.2 Main Setup When you first enter the AMI BIOS setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab on the top of the screen. The Main BIOS setup screen is shown below.
  • Page 57 Chapter 4: UEFI BIOS Build Date This item displays the date when the version of the BIOS ROM used in the system was built. CPLD Version This item displays the CPLD version of the BIOS ROM used in the system. Memory Information Total Memory This feature displays the total system memory detected.

  • Page 58: Advanced

    P555 F5 User's Manual 4.3 Advanced Use the arrow keys to select a top item and press <Enter> to access the submenu items. Warning: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable.
  • Page 59 Chapter 4: UEFI BIOS Bootup NumLock State Use this feature to set the Power on state for the <Numlock> key. The options are On and Off. Wait For "F1" If Error Use this feature to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled.
  • Page 60 P555 F5 User's Manual Trusted Computing Security Device Support If this feature and the TPM jumper on the motherboard are both set to Enabled, onboard security devices will be enabled for TPM (Trusted Platform Module) support to enhance data integrity and network security. Please reboot the system for a change on this setting to take effect.
  • Page 61 Chapter 4: UEFI BIOS ACPI SRAT L3 Cache As NUMA Domain Use this setting to enabe/disable ACPI SRAT L3 Cache As NUMA Domain. The options are Disabled, Enabled, and Auto. Super IO Configuration The following Super IO information will display: •...
  • Page 62 P555 F5 User's Manual Serial Port Console Redirection COM1 Console Redirection Select Enabled to enable console redirection support for a serial port specified by the user. The options are Disabled and Enabled. *If the item above set to Enabled, the following items will become available for user's configuration: Console Redirection Settings Terminal Type...
  • Page 63 Chapter 4: UEFI BIOS Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None and Hardware RTS/CTS.
  • Page 64 P555 F5 User's Manual *If the item above set to Enabled, the following items will become available for user's configuration: Console Redirection Settings Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support.
  • Page 65 Chapter 4: UEFI BIOS VT-UTF8 Combo Key Support Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100 terminals. The options are Disabled and Enabled. Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server.
  • Page 66 P555 F5 User's Manual Console Redirection Settings Out-of-Band Mgmt Port The feature selects a serial port in a client server to be used by the Microsoft Windows Emergency Management Services (EMS) to communicate with a remote host server. The options are COM1 and SOL. Terminal Type Use this feature to select the target terminal emulation type for Console Redirection.
  • Page 67 Chapter 4: UEFI BIOS CPU Configuration SMT Control Use this setting to specify Simultaneous Multithreading. The options are Disabled and Auto. Core Performance Boost This setting is used to configure for Core Performance Boost. Options include Disabled and Auto. Global C-state Control This setting is used to configure for Global C-state Control.
  • Page 68 P555 F5 User's Manual CPU1 Information These sections are for informational purposes. They will display some details about the detected CPUs on the motherboard, such as: • CPU Version • Number of Cores Running • Processor Family • Processor Model •...
  • Page 69 Chapter 4: UEFI BIOS Memory Configuration Memory Clock This setting allows you to select different memory clock speed. Options include Auto and supported frequencies. Memory Interleaving This setting controls fabric level memory interleaving. Note that the channel, die and socket have requirements on memory populations and it will be ignored if the memory doesn't support the selected option.
  • Page 70 P555 F5 User's Manual SR-IOV Support If the system has SR-IOV capable PCI-E devices, this setting will Disable or Enable the Single Root IO Virtualization Support for the system. BME DMA Mitigatioin Use this setting to re-enable the Bus Master Attribute that was disabled during PCI enumeration for PCI bridges after SMM is locked.
  • Page 71 Chapter 4: UEFI BIOS CPU SLOT 5 PCI-E 4.0 X16 OPROM This setting enables or disables the listed PCI/PCIX/PCIe Slot OPROM option. The options include Disabled, Legacy and EFI. CPU SLOT 6 PCI-E 4.0 X16 OPROM This setting enables or disables the listed PCI/PCIX/PCIe Slot OPROM option. The options include Disabled, Legacy and EFI.
  • Page 72 P555 F5 User's Manual CPU SLOT4 PCI-E 4.0 X8 Bifurcation This setting selects the bifurcation configuration for this particular PCI-E slot. The options include Auto, and x4x4. CPU SLOT5 PCI-E 4.0 X16 Bifurcation This setting selects the bifurcation configuration for this particular PCI-E slot. The options include Auto, x16, x8x8, x4x4x8, and x4x4x4x4.
  • Page 73 Chapter 4: UEFI BIOS IPv6 HTTP Support This setting allows you to Disable or Enable IPv6 HTTP boot support. If disabled, IPv6 HTTP boot support will not be available. PXE Boot Wait Time This setting allows you to set in a number field the wait time to press the ESC key to abort the PXE boot.
  • Page 74 P555 F5 User's Manual SATA Information This section displays information on the detected SATA devices: • I-SATA0~7 • SATA0~15 KMIP Server Configuration This feature allows the user to adjust KMIP Server network parameters. KMIP Server IP address KMIP TCP Port number TimeZone Client UserName Client Password...
  • Page 75 Chapter 4: UEFI BIOS Network Configuration Configured Select Enabled to activate IPv4 network configuration. The options are Enabled and Disabled. *If the item above is set to Enabled, the following item will become available for configuration: Enable DHCP This feature allows the user to select the source of the IP address for this computer. If Disabled is selected, you will need to know the local IP address of this computer and enter it to the system manually in the field.
  • Page 76 P555 F5 User's Manual Add an Attempt Delete Attempts Change Attempt Order TLS Authenticate Configuration This submenu allows the user to configure Transport Layer Security (TLS) settings. Server CA Configuration Enroll Certification Enroll Certification using File Use this feature to enroll certification from a file. Certification GUID Use this feature to input the certification GUID.

  • Page 77: Ipmi

    Chapter 4: UEFI BIOS 4.4 IPMI This tab allows you to configure the following IPMI settings for the system. Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI STATUS This item indicates the status of the IPMI firmware installed in your system.
  • Page 78 P555 F5 User's Manual Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot.
  • Page 79 Chapter 4: UEFI BIOS Station IP Address This item displays the Station IP address for this computer. This should be in decimal and in dotted quad form. Subnet Mask This item displays the sub-network that this computer belongs to. The value of each three- digit number separated by dots should not exceed 255.

  • Page 80: Event Logs

    P555 F5 User's Manual 4.5 Event Logs This tab allows the user to configure the following event logs settings for the system. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot. The options are Disabled and Enabled. Erasing Settings Erase Event Log Select Yes to erase all error events in the SMBIOS (System Management BIOS) log before...
  • Page 81 Chapter 4: UEFI BIOS When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full. Select Do Nothing for the system to do nothing when the SMBIOS event log is full. The options are Do Nothing and Erase Immediately. SMBIOS Event Log Standard Settings Log System Boot Event Select Enabled to log system boot events.

  • Page 82: Security

    P555 F5 User's Manual 4.6 Security This tab allows you to configure the following security settings for the system. Administrator Password Press Enter to create a new, or change an existing Administrator password. Note that if the Administrator Password is erased, the User Password will be cleared as well. Password Check Select Setup for the system to check for a password at Setup.
  • Page 83 Chapter 4: UEFI BIOS SMCI Security Erase Configuration Secure Boot This section contains options and menus for securing your boot mode and for key management. Secure Boot This option allows you specify when the Platform Key (PK) is enrolled. When enabled, the System Mode is user deployed, and the CSM function is disabled.
  • Page 84 P555 F5 User's Manual Device Guard Ready Remove 'UEFI CA' from DB B (available when the system is not in Device Guard Ready) Select and press Yes to remove Microsoft UEFI CA certificate from the DB. The options are Yes and No. Restore DB defaults Select and press Yes to restore the DB variables to factory defaults.
  • Page 85 Chapter 4: UEFI BIOS Append Key Select Yes to add the DBX from the manufacturer's defaults to the existing DBX. Select No to load the DBX from a file. The options are Yes and No. Authorized TimeStamps Set New Key Select Yes to load the DBT from the manufacturer's defaults.

  • Page 86: Boot

    P555 F5 User's Manual 4.7 Boot Use this tab to configure Boot Settings: Boot Mode Select Use this item to select the type of device that the system is going to boot from. The options are Legacy, UEFI, and DUAL. The default setting is DUAL. LEGACY to EFI Support This option Disables or Enables the system to boot to an EFI OS after the boot failed from the legacy boot order.
  • Page 87 Chapter 4: UEFI BIOS Delete Boot Option Use this feature to remove a pre-defined boot device from which the system will boot during startup. The settings are [any pre-defined boot device]. UEFI Application Boot Priorities This feature allows the user to specify which UEFI devices are boot devices. •...

  • Page 88: Save & Exit

    P555 F5 User's Manual 4.8 Save & Exit Select the Save & Exit tab to enter the Save & Exit BIOS Setup screen. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer.
  • Page 89 Chapter 4: UEFI BIOS Discard Changes Select this option and press <Enter> to discard all the changes and return to the AMI BIOS utility Program. Default Options Restore Optimized Defaults To set this feature, select Restore Optimized Defaults from the Save & Exit menu and press <Enter>.

  • Page 90: Battery Handling

    B.1 Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い 電池交換が正しく行われなかった場合、破裂の危険性があります。交換する電池はメーカーが推...
  • Page 91 Appendix B: Warning Statements Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant. Jeter les piles usagées conformément aux instructions du fabricant. ¡Advertencia! Existe peligro de explosión si la baterí...

  • Page 93: Product Disposal

    P555 F5 User's Manual B.2 Product Disposal Warning! Ultimate disposal of this product should be handled according to all national laws and regulations. 製品の廃棄 この製品を廃棄処分する場合、国の関係する全ての法律・条例に従い処理する必要があります。 警告 本产品的废弃处理应根据所有国家的法律和规章进行。 警告 本產品的廢棄處理應根據所有國家的法律和規章進行。 Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen.

  • Page 94: Appendix C Uefi Bios Recovery

    Appendix C: UEFI BIOS Recovery Appendix C UEFI BIOS Recovery Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall, special, incidental, or consequential damages arising from a BIOS update. If you need to update the BIOS, do not shut down or reset the system while the BIOS is updating.

  • Page 95: Recovering The Bios Block With A Usb Device

    P555 F5 User's Manual 2. While the system is turned off, insert the USB device that contains the new BIOS binary image (SUPER.ROM). 3. Power on the system. 4. After the system is turned on, the system will enter the BIOS Recovery menu. Select "Proceed with flash update"...
  • Page 96 Appendix C: UEFI BIOS Recovery 5. After the Boot Sector Recovery Process is complete, press any key to reboot the system.
