LevelLift
"L" Series
UltraLift
"UL" Series
"UL2" Series
TO LIFT BOAT
1 Position boat over lift and attach Guide ropes to rear cleats of boat.
2 Rotate Valve Handle to LIFT/LAUNCH and turn Blower Switch ON. NOTE: If
Blower does not activate, reset GFCI switch.
3 Gently push boat back until Guide Ropes are taut and bow is centered over lift. 4
Release boat when lift contacts the hull.
5 When large air bubbles appear from under the tanks, turn Blower Switch OFF and
rotate valve handle to DRY DOCK.
TO LAUNCH BOAT
1 Rotate Valve Handle to LIFT/LAUNCH position.
LEAVE BLOWER SWITCH OFF.
2 When boat is floating freely, rotate Valve Handle
to DRY DOCK.
3 Remove Guide Ropes from boat.
Guide Ropes
Blower
Switch
One Valve Control
GFCI
Valve
Handle
