ITEM
.
PART NO
NO.
1 PD525 Tool Pod for SMD Hot Air Tools
2 SH230 Sponge Holder with LN230, RS199, RS243
2A RS199 Cleaning Sponge for SH230
2B RS243 Leveling Pad for SH230
2C LN230 Liner for SH230
2D SH230-1 Sponge Holder Tray
3 SR010 Label, Control Panel for 1036
4 SR011 Screw, Pan Head Phillips
5 SR012 Rubber Foot
6 SR016 Flat Washer
7 SR724 Fuse, 6.3A
8 SR015 Screw, Flat Head Slotted
9 SR468 Screw, Rd. Head Phillips
10 SR467 Nut, Square Cone
11 SR018 Top Cover
12 SR019 Dovetail Mount
13 SR535 Vacuum Pump, 115 VAC, 60 Hz
14 SR719 Air Flow Control Valve
15 SR439 Holder, Clip for AF110
16 AF110 In-Line Filter (includes items 17 & 18)
17 AF627 Felt Filter (set of 10)
18 AF040 Foam Filter (set of 10)
19 SR802 LED, Yellow
20 SR801 LED, Green
21 SR726 Power Cord Assy., 120 VAC
22 HS307 Hose, Low Static Silicone, 1/8" I.D. (sold per foot)
22A
22B
23 SR160 Terminal Block, 9 Port
24 SR034 Toggle On/Off Switches
25 SR036 Shelf Plate
26 SR035 Dovetail Riser Adapter Plate
27 SR037 3-Prong 120 VAC Receptacle
28 SR038 Bottom Base for PS542
29 SR241 Strain Relief for Power Cord
30 SR470 Well Nut
31 SR469 Spacer
32 SR721 Resistor for LED
33 SR720 Diode for LED
34 SR569 Fuse Holder
PS542 POWER SUPPLY
SPARE PARTS LIST
DESCRIPTION
QTY
REQ'D
1
1
1
1
1
1
1
4
4
4
1
3
4
3
1
1
1
1
4
2
2
2
1
1
1
6 "
1/2
5 "
3/4
2"
1
2
2
1
1
1
1
4
4
2
2
1
