- Page 1 INSTALLATION INSTRUCTIONS & USER MANUAL EVO BIDET SHOWER TOILET SEAT | EV105 IMPORTANT! Please read these instructions prior to installation Distributed by: T 04 568 9898 E sales@plumbline.co.nz www.plumbline.co.nz...
- Page 2 INSTALLATION INSTRUCTIONS EVO BIDET SHOWER TOILET SEAT | EV105 General Installation Instructions Please carefully check the bidet shower seat prior to installation to ensure it has not been damaged during handling or transport, and check that all parts have been supplied.
-
Page 3: Table Of Contents
Safety Notes Safety Notes User Precautions Product Description Components Description Installation Steps Method of Use Cleaning & Maintenance Faults & Troubleshooting Product Dimensions Product Technical Specification... -
Page 4: Safety Notes
Safety Notes Read the safety instructions carefully before use so as to use the bidet seat correctly. Note the following warnings relevant to safety Warning Prohibited Mandatory Note Failure to observe the above-mentioned warning signs may result in injury or life- threatening risk. - Page 5 Safety Notes Only use a suitable power outlet Ensure that no water, cleaning socket. Excessive loads on chemical or urine comes in multi-outlet powerboards is contact with the power plug. strictly prohibited. May result in fire or electric shock. May result in overheating or fire. Do not pull on the power plug/ Do not use if socket is loose.
- Page 6 Safety Notes Do not disassemble, repair and Always unplug the power supply modify without authorization. when cleaning the bidet seat. May result in fire or electric shock. May result in electric shock. Do not use cigarettes or other Do not bend or twist the water combustible items near the bidet supply hose.
-
Page 7: User Precautions
User Precautions Do not place this product in direct Ensure room temperature is sunlight. above 4°C. May cause product discoloration and If temperature is below 4°C water supply failure of seat heating function. can freeze. Do not shower urine on the bidet Do not use a substandard power body and nozzle. -
Page 8: Product Description
Product Description Toilet seat lid Drain plug Toilet seat Nozzle Control knob Water supply hose connection Power plug Disassembly button Function settings key Function Settings Key Control Knob Water temperature Seat temperature STOP adjustment indicator adjustment indicator Water temperature Seat temperature Bidet Rear Wash adjustment key... -
Page 9: Components Description
Component Description 1. Bidet Shower Toilet Seat 2. Installation template 3. Mounting fittings Expansion bolt (2) Screw (2) Fixing bracket (1) Nut (2) Adjustment plate (2) 4. T-junction with filter 5. Water inlet hose 3. Installation instructions Installation Instructions Filter screen... - Page 10 Installation Installation Tools Phillips screwdriver Adjustable wrench Bucket and rag Pre-Installation Precautions 1. Water supply pressure: 0.1-0.75MPa, please follow the instructions. 2. Ensure the angle valve is installed close to the bidet seat water inlet location. 3. Before any hoses are connected to the angle valve firstly flush it out to clear impurities and sludge that may have been embedded in the pipe prior to/during installation.
- Page 11 Installation C L I 4. The installation template is designed for 5. Slightly push the bidet seat into the fixing one-time use. Please discard it after the plate in the specified direction until a installation is completed. “click” sound is heard, indicating that the bidet seat has been installed in place.
- Page 12 Installation Connecting the Power 1. Insert the power plug as the picuture shown on the left. 2. Press the “Reset” button on the RCA surge protector to turn the power on; the indicator light will be on. 3. Press the “Test” button on the RCA surge protector to turn the power off;...
- Page 13 Function Instructions Standby Mode 1. Make sure the plug is dry before power supply is connected. 2. After the power supply is connected, the bidet seat will perform a self-check. When the self-check is completed, it will send a confirmation “beep”, then the bidet seat can be used normally.
- Page 14 Function Instructions Functions Settings Function Settings Key Water temperature Seat temperature adjustment indicator adjustment indicator Prompt Light OFF Lowlighted Highlighted Water temperature Seat temperature adjustment key adjustment key The knob lamp can be turned off by pressing the water temperature adjusting button and the seat temperature adjusting button at the same time.
-
Page 15: Cleaning & Maintenance
Cleaning & Maintenance Manual Cleaning of Spray Nozzle - Pull the nozzle in and out gently more than 5 times; - Gently support the nozzle. Use a soft cloth, sponge or small brush dipped in non-abrasive detergent and wipe the nozzle and nozzle head. Wipe away any excess cleaning detergent. Cleaning the Filter Fcreen Braided hose Filter screen... - Page 16 Cleaning & Maintenance RCD / Surge Protector Check the surge protector regularly, at least once a month Inspection method: - Press the surge protector “Reset” button: - indicator light is on, and the power supply is on. - Press the surge protector “Test” key button: - indicator light is off, and the power supply is disconnected.
-
Page 17: Faults & Troubleshooting
Faults & Troubleshooting Common fault diagnosis If you think the bidet seat has a fault, try some of the following process methods. If the product is still not working properly, contact an authorised technician or electrician. Check power supply Check water supply 1. -
Page 18: Product Dimensions
Faults & Troubleshooting / Product Dimensions Alarm Function Phenomenon Possible cause Solution Control Knob switch is not reset to OFF state Buzzer continuously beeps Reset Control Knob to OFF state when away from seat Surge protector sometimes Cut off power supply, stop using product, Electricity leakage beyond normal value trips. -
Page 19: Product Technical Specification
Product Technical Specification Item Description Model EV105 Water Inlet Side Power Cord Inlet Side Net Weight 3.5kg Rated Voltage 220-240V~, 50/60Hz 960W (Under the conditions: entering water Rated Power Consumption temperature15°C, flow rate 600ml/min) Maximum Power Cousumption 1500W/220V Length of Power Cord 1.5m...
