IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO
ASSEMBLE OR USE YOUR 4'6 CORONA LOW END BED.
Assembly Instructions
- Please check contents and read instructions carefully before commencing assembly.
- To avoid damage assemble product on a soft, clean surface.
- The only tools required are a small mallet and screwdriver.
- Do not use power tools as this might damage the product and make it unsafe. This will also invalidate any claim.
- Assemble the product in accordance with instructions defined.
- It is recommended that two people handle and assemble product.
- This product is manufactured in pine which is a wood with natural characteristics including knots, grain and clusters or indentations.
- On unpacking the furniture you may notice an odour due to the production process. However, this will disappear after a period of time.
- For care and maintenance please refer to the attached details.
Care & Maintenance
- To enjoy your new furniture for many years please follow our recommendations below.
- Do not place product next to a radiator or direct sunlight. This product is manufactured in pine but is susceptible to temperature
change. It is recommended that an even room temperature be maintained with no sudden temperature fluctuation.
- Do not place hot or cold items directly onto the surface. Always use a placemat or marking will occur.
- For general cleaning use a duster or damp cloth (almost dry) not wet
- Do not use soap and water, detergents, aerosol sprays or any polish. The use of the materials above would invalidate any claim.
- You might wish to re-treat the surface from time to time to maintain the original finish.
This can be done by using block wax (unperfumed). Please follow the manufacturer's instructions carefully.
- Carry out regular inspection to ensure fittings are secure. Please be careful not to over tighten fittings.
- Do not place furniture on wet or damp floor as staining may occur to your floor.
f
You
Tube
ASSEMBLY INSTRUCTIONS
4'6 CORONA LOW END BED
2 0
6 0
m m
m m
8 4
1 4
Code: S000238
4 m
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Birlea S000238
Summary of Contents for Birlea S000238
- Page 1 Code: S000238 ASSEMBLY INSTRUCTIONS 4'6 CORONA LOW END BED IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR USE YOUR 4'6 CORONA LOW END BED. Assembly Instructions - Please check contents and read instructions carefully before commencing assembly. - To avoid damage assemble product on a soft, clean surface.
- Page 2 Code: S000238 PARTS LIST HARDWARE LIST Part Item Part Item Headboard panel 30mm dowel Footboard panel 40mm dowel Left headboard post 16mm Screw Right headboard post 35mm Screw Right footboard post Left footboard post 32mm Bolt Slat pack Support leg...
- Page 3 STEP 1 Code: S000238 Attach the support legs to the centre rail using hardware part and the Allen key as provided. Insert the 40mm wooden dowels to the side rails using a small mallet (not provided) DO NOT use any power tools as this may damage the item and will invalidate any claims.
- Page 4 STEP 3 Code: S000238 Attach the left headboard post and right headboard post to the headboard panel headboard rail using hardware part and the Allen key provided. DO NOT use any power tools as this may damage the item and will invalidate any claims.
- Page 5 STEP 5 Code: S000238 Fix the metal brackets to the headboard rail and footboard panel using hardware part and a screwdriver (not provided). DO NOT use any power tools as this may damage the item and will invalidate any claims.
- Page 6 STEP 7 Code: S000238 A ttach the footboard posts to the side rails using hardware parts with the Allen key as provided. Then fix the centre rail to the metal bracket using hardware parts DO NOT use any power tools as this may damage the item and will invalidate any claims.
- Page 7 STEP 9 Code: S000238 Insert the metal studs to the bed posts at the dimensions as shown in the diagram using a small mallet (not provided). DO NOT use any power tools as this may damage the item and will invalidate any claims.
