Defender FreeMotion B801 User Manual

Defender
FreeMotion B801
Wireless Bluetooth Stereo Headset
Беспроводная
Bluetooth-стереогарнитура
User Manual
Руководство по продукту
www.defender-global.com
Operating frequency: 2.402-2.480 GHz (2.4 GHz ISM-band)
Diameter of speaker, mm: 12
Operation range, m: 10
Power supply: internal lithium battery
Talk time/ Audio playback, h: 7/ 7
Charging time, h: 2.5
Micro-USB charger port
I. DEsIgn
1. Adjustable headband
2. Next track button
3. Previous track button
4. LED indicator / USB charging port
5. Multifunction button. Functions: on/off, answer a call, end a call, reject a call, last
dialed number, play/pause music.
6. Volume up button
7. Volume down button
8. Built-in microphone
9. Audio jack for cable connection (for wired connection)
10. NFC-antenna

II. opERATIon

charging with the usb-cable

If you charge the battery for the first time, please make sure that it is fully charged
before you start using the headset.
Insert the USB-cable into the PC USB-port with the absorbed current up to 0.5 A.
Connect the other end of the cable to the headset. Red LED-indicator will be turned on.
The charging is in process.
When the headset is fully charged, the LED-indicator changes its colour for blue.

Turning on/off

Press and hold button 5 for 3 seconds.

pairing to a bluetooth device

Make sure that the headset is off. Press and hold button 5 for 6 seconds until the AC
signal of the LED-indicator is on.
Activate Bluetooth on your tablet or mobile phone and start searching for a new device.
Select the Bluetooth headset from the list and confirm the connection.
README:
Read the user manual and keep all the printed manuals for the future reference.
This manual contains important information about safety precautions and health
effect of the purchased Defender device.

IMpoRTAnT sAfETy InfoRMATIon

When receiving the product make sure there are no free moving objects in the
package.
Do not expose the product to mechanical stress that can lead to its mechanical
damage. Mechanical damage is not covered by warranty.
Avoid damp, humidity, moisture, vibration, extreme temperatures and mechanical
stress.
Use and store the product in dry location with air humidity 20-90%, avoid
condensation.
The normal operation and storage temperature range is +5...+40º С without
condensation.
If the product was transported during subzero weather, keep it in a warm room (+16-
25º С) for 3 hours before use.
Do not disassemble the product! It doesn't have any parts, which are subjected to self-
repairing. For any service or replacement of a defective product contact the distributor
or Defender authorized service center.
Turn off the product every time you plan to store it for a long period of time.
Long-term exposure to high-power sound may cause temporary or permanent hearing
disabilities.
Turn off the wireless device before emplaning or placing it into the luggage.
The product may contain small parts that pose risk for children under 3 years old. Do
not give the product to children.
The product is not for industrial, medical or manufacturing use.
DIsposAl of bATTERIEs, ElEcTRIcAl AnD ElEcTRonIc EquIpMEnT
This sign on the product, its batteries or package indicates that the product
cannot be disposed together with domestic waste. It should be delivered to
an appropriate batteries, electrical and electronic equipment collecting and
recycling company.

pAckAgE conTEnTs

• Headset with microphone
• Cable for headset wired connection
• Micro-USB charging cable
• User manual

spEcIfIcATIon

Bluetooth version: V3.0+EDR
Supported profiles: HSP, HFP, A2DP, AVRCP
If it asks for the password enter 0000 or simply confirm your choice.
If the pairing is not successful, turn off the mobile phone and the headset and repeat all
the steps again. After the devices are successfully paired, they are ready to use. You only
need to pair the headset with your phone just once.
It is necessary to install an additional program to use USB-Bluetooth adaptor in
Windows. In most cases you'll need to install BlueSoleil or the software making a part of
the delivery set of your product.
Every time you turn the headset on, it will be automatically connected with the last two
paired devices.

nfc connection

If your mobile phone or tablet supports NFC, than connect the headset as follows:
Turn on the headset. Turn on the NFC-function on your mobile phone.
Find NFC-antenna on your mobile phone and touch the antenna 10 on your headset
with it. The mobile phone will turn the headset on itself and offer you to proceed with
the connection.

Wired connection of the headset

If the battery of the headset is discharged or your PC does not support Bluetooth you
can connect the headset with a cable, but all the control buttons on the headset will be
disabled.

calls through bluetooth headset

Last number redial: Shortly press button 5 two times.
Volume control: Shortly press button 6 or 7.
Answer an incoming call: Shortly press the multifunction button 5.
Ending a call: Shortly press the multifunction button 5.
Call rejection: Press and hold the multifunction button 5 within 1 second.

listening to music

Play/Pause: Shortly press the multifunction key 5.
Next/Previous track: Shortly press button 2 or 3.
Volume control: Shortly press button 6 or 7.

processes indication

Red LED: Charging is in process.
Blue LED: Charging is completed.
Red and blue LEDs blink alternately: The headset is available to other devices and can be
paired to them.
Blue LED blinks twice every few seconds: No device connected.
Red and blue LEDs blink alternately every 2 seconds: Setting of HFP and A2DP connection.
Blue LED blinks twice every 20 seconds: Low Battery.
Tone sound
The tone sound which you hear every 20 second notifies you about the low battery.
