Net World Sports VERMONT Quick Start Manual

ITEM COMPONENT
BASE
POST
SUPPORT
TOP
POST
BOTTOM
POST
WHEEL
1.5 INCH
BOLT
KNOB
2.5 INCH
BOLT,
NUT,
DOME.
WRENCH
& KEY
Net World sports UK
www.networld-sports.co.uk
sales@networld-sports.co.uk
+44 1691 683 807
Net World sports USA
www.networld-sports.com
sales@networld-sports.com
1-866-861-9095
Badminton/ Volleyball combi post assembly instructions
QTY
Step 1: Unscrew bolt from post support
2
2
Step 2: Attach post support to base with same bolt.
2
Attach wheels to base using 1.5inch bolts.
2
4
4
Step 2: Insert top post into bottom post and secure with 2.5inch bolt,
nut and dome. Insert assembled post into post support with
the cleat facing away from the playing area.
2
secure in place by inserting 2.5 inch bolt through the post and
screwing bolt tight. Then screw on dome cap.
To anchor post firmly in place screw Knob through post support
4
to clamp post.
1 set
SAFETY: Please read through instructions before assembling.
Please check all parts are present with no defects
prior to assembly.
Take extreme care when moving/lifting posts.
Regularly check equipment to ensure it is safe to use
DO NOT climb or swing on posts or net.
Volleyball
1.5 inch bolt
Badminton
2.5 inch bolt
2.5 inch bolt
