DLP
Projector
®
8964WUSS/8964WSS
User's Manual (concise)
Thank you for purchasing this projector.
Please read through this manual before using this product, in order to use safely
and utilize well the product.
WARNING
product. After reading them, store them in a safe place for future reference.
NOTE
In this manual, unless any comments are accompanied, "the manuals"
means all the documents provided with this product, and "the product" means this
projector and all the accessories came with the projector.
Contents
............................................ 2
Important safety instruction ..............................2
Regulatory notices .............................. 3
Contents of package........................... 4
Arrangement ....................................... 6
Connecting power supply ................. 10
8964WUSS-8964WSS-Concise-00
............... 9
.......................... 10
Turning on the power ........................ 12
Displaying the picture ....................... 14
Turning off the power ........................ 15
Cleaning the intake vents ................ 16
Using the CD manual ....................... 18
................................... 19
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DLP 8964WUSS and is the answer not in the manual?

Questions and answers

Related Manuals for Dukane DLP 8964WUSS

Summary of Contents for Dukane DLP 8964WUSS

  • Page 1: Table Of Contents

    Projector ® 8964WUSS/8964WSS User's Manual (concise) Thank you for purchasing this projector. Please read through this manual before using this product, in order to use safely and utilize well the product. WARNING product. After reading them, store them in a safe place for future reference. NOTE In this manual, unless any comments are accompanied, “the manuals”...

  • Page 2: Entries And Graphical Symbols Explanation

    First of all Entries and graphical symbols explanation The following entries and graphical symbols are used for the manuals and the product as follows, for safety purpose. Please know their meanings beforehand, and heed them. WARNING This entry warns of a risk of serious personal injury or even death. CAUTION This entry warns of a risk of personal injury or physical damage.

  • Page 3: Regulatory Notices

    Regulatory notices About Electro-Magnetic Interference This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. This product may cause interference if used in residential areas. Such use must be avoided unless the user takes special measures to reduce electromagnetic emissions to prevent interference to the reception of radio and television broadcasts.

  • Page 4: About Waste Electrical And Electronic Equipment

    Regulatory notices (continued) About Waste Electrical and Electronic Equipment The mark is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment including any spent or discarded batteries or accumulators as unsorted municipal waste, but use the return and collection systems available.

  • Page 5: Preparing For The Remote Control

    Preparing for the remote control Please insert the batteries into the remote control before using it. If the remote control starts to malfunction, try to replace the batteries. If you will not use the remote control for long period, remove the batteries from the remote control and store them in a safe place.

  • Page 6: Arrangement

    Arrangement Refer to tables T-1 to T-2 at the back of this manual as well as the following to determine the screen size and projection distance. The values shown in the table are calculated for a full size screen. Ⓗ × Ⓥ : Screen size ⓐ...
  • Page 7 Arrangement (continued) WARNING Install the projector where you can access the power outlet easily. Install the projector in a stable horizontal position. manufacturer. Read and keep the manuals of the accessories used. required. in the manual. Do not place the projector where any oils, such as cooking or machine oil, are used.

  • Page 8: Connecting With Your Devices

    Connecting with your devices the required accessories, such as a cable in accord with the signal of the device. Consult your dealer when the required accessory did not come with the product or the accessory is damaged. After making sure that the projector and the devices are turned off, perform the gures F-1 to F-4 at back of this manual.
  • Page 9 Fastening the adapter cover prevention. USB wireless adapter: Temperature range: 0 ~ 40°C(operating) Loosen the screw on the bottom left of the WIRELESS port. Insert the tab of the cover into the hole at the upper right of the WIRELESS port in the direction of the arrow.

  • Page 10: Connecting Power Supply

    Connecting power supply Put the connector of the power cord into the AC (AC inlet) of the projector. outlet. In a couple of seconds after the power supply connection, the POWER Power cord indicator will light up in steady orange. Please remember that when the DIRECT POWER ON function activated, the connection of the power supply make the projector turn on.

  • Page 11: Attaching The Terminal Cover

    Attaching the terminal cover Terminal cover A Hook Claw Insert the two claws of the Terminal cover into the hole of Do not hold the terminal cover when moving the projector. When detaching the Terminal cover, push the Hook in the direction of the arrow and pull it forward. Hook Claw Insert the two claws of the Terminal cover into the hole of...

  • Page 12: Turning On The Power

    Turning on the power projector and the outlet. STANDBY/ON button Make sure that the POWER indicator is lighted in steady orange. Then POWER indicator remove the lens cover. Press the STANDBY/ON button on the projector or the remote control. The projection light source will light up and the POWER indicator will begin blinking in green.

  • Page 13: Adjusting The Projector's Elevator

    Adjusting the projector’s elevator Lengthening or shortening the length of the elevator feet shifts the projection position and the projection angle. Turn the elevator feet each to adjust their length. max. 21mm WARNING lengthened exceeding the limit may come off and drop the projector down, and result in an injury or damaging the projector.

  • Page 14: Displaying The Picture

    Displaying the picture VOLUME Activate your signal source. Turn the signal INPUT MYBUTTON ASPECT PbyP AUTO FREEZE VOLUME + / - MAGNIFY FOCUS ZOOM VOLUME source on, and make it send the signal to the buttons PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK...

  • Page 15: Turning Off The Power

    Turning off the power Press the STANDBY/ON button on the STANDBY/ON button projector or the remote control. POWER indicator The message “Power off?” will appear on the screen for about 5 seconds. Press the STANDBY/ON button again while the message appears. The light source will go off, and the POWER indicator will begin blinking INPUT...

  • Page 16: Cleaning The Intake Vents

    Cleaning the intake vents It is recommended to check and clean the intake vents periodically for maintaining the ventilation inside of the projector and normal operation. If a message prompts you to clean or check the intake vents, or if the TEMP indicator lights in red, clean the intake vents immediately.

  • Page 17: Replacing The Internal Clock Battery

    Replacing the internal clock battery Installing the battery is required in some cases. ( Event Scheduling in the User's Manual - Network Guide) A battery is not contained at the time of factory shipment. Please replace a battery according to the following procedure. Turn the projector off, and unplug the power cord.

  • Page 18: Using The Cd Manual

    Also available at; http://www.dukane-av.com/service/downloads.asp Note: The Dukane model described in this document is manufactured by Hitachi and use the same firmware, software programs, control code, and accessory parts. The equivalent Dukane to Hitachi models are; 8964WUSS (LP-WU3500) and 8964WSS (LP-WX3500).
  • Page 19 Item Product name ® projector 8964WSS: 1,024,000 pixels (1280 horizontal x 800 vertical) 8964WUSS: 2,304,000 pixels (1920 horizontal x 1200 vertical) Light Source Speaker 16W x1 Power supply/ Rated AC100V-120V: 5.6A, AC220V-240V: 2.9A current Power consumption AC100V-120V: 560W, AC220V-240V: 550W Operating Refer to the following table.
  • Page 20 Item COMPUTER IN ......D-sub 15 pin mini jack x1 HDMI 1 / MHL ....... HDMI / MHL connector x1 HDMI 2 ........... HDMI connector x1 HDMI OUT ..........HDMI connector x1 HDBaseT ............RJ45 jack x1 MONITOR OUT ......D-sub 15 pin mini jack x1 VIDEO ...............

  • Page 21: Troubleshooting - Warranty And After-Service

    If this does not resolve the problem, please consult your dealer or service company. They will tell you what warranty condition is applied. for this projector. DUKANE CORP AV SERVICE DEPT 2900 Dukane Drive St Charles, IL 60174 800-...
  • Page 22 Ⓗ x Ⓥ : Screen size ⓐ : Projection distance Projector top (from the front of the projector unit) Projector bottom 8964WSS (1280 x 800, ±10%) 16 : 10 16 : 9 4 : 3 Screen Screen Screen Projection distance Projection distance Projection distance size size...
  • Page 23 8964WUSS (1920 x 1200, ±10%) 16 : 10 16 : 9 4 : 3 Screen Screen Screen Projection distance Projection distance Projection distance size size size a min. a max. a min. a max. a min. a max. inch inch inch inch inch...
  • Page 24 Smartphone Tablet Computer External device Computer wireless adapter (optional) Access point...
  • Page 25 VCR/DVD/ Blu-ray Disc player Speakers Another Monitor projector (Wired) Remote control...
  • Page 27 PAGE GEOMETRY PICTURE MUTE DOWN INTERACTIVE NETWORK BLANK MENU (13) ENTER OSD MSG RESET (14) (15) (16) (10) (11) DUKANE CORP AV SERVICE DEPT 2900 Dukane Drive St Charles, IL 60174 800- 800-676-2487 / 630-762- Fax 630-584-5156 avservice@dukane.com www.dukaneav.com 8964WUSS-8964WSS-Concise-00...
