Summary of Contents for Blue-White FLEXFLO A-100
- Page 1 MODEL A-100 Peristaltic Injection Pump Operating Manual 5300 Business Drive Huntington Beach, CA 92649, USA Phone: 714-893-8529 FAX: 714-894-9492 E mail: sales@blue-white.com or techsupport@blue-white.com Website: www.Blue-White.com...
- Page 2 A-100 Page 2 PREFACE You have just received a peristaltic metering pump. This is sometimes called a roll pump. Different models measure the amount of fluid delivered in several ways, the most common is based on R.P.M. (Revolutions Per Minute) of the pump motor output shaft plus a percentage of running time.
-
Page 3: Unpacking Information
Page 3 A-100 1. UNPACKING INFORMATION Verify that you have received all of the following equipment: - One A-100 series pump - 10 ft. 3/8” O.D. Clear vinyl tubing with flow indicator - One threadless injector (T.I.) Fitting - One suction tube strainer - One ceramic weight - Two pump head tube assemblies (with fittings) - Two mounting screws... -
Page 4: Electrical Requirements
A-100 Page 4 ELECTRICAL REQUIREMENTS - Be certain you connect the unit to the proper power supply. - Using incorrect voltage will cause server damage to the motor. - The voltage requirement is printed on the serial number label. - All pump models are supplied with a junction box and cover. - To reduce the risk of electric shock, be certain that a grounding conductor is connected to the green grounding located inside the junction box. -
Page 5: Output Adjustments
½ equals approximately 30 seconds on. 3/4 equals approximately 45 seconds on, etc. MEASURING THE OUTPUT This volumetric test will take into account Blue-White Injection Fitting installation factors such as line pressure, fluid velocity, specific gravity, etc. This test is the most accurate for measuring the injector’s output in an individual... - Page 6 Page 6 TUBE THREADING INSTRUCTIONS CAUTION: Keep fingers out of pump head! Video Instructions: http://www.blue-white.com/Video.htm We offer free training on this over the web. Hold the tube in your right hand with the fitting marked “R” facing you. Note that the fitting marked “L”...
-
Page 7: Replacement Parts
Page 7 A-100 4. REPLACEMENT PARTS 1. Retainer knob A-011 7. Motor: 2. Cover, pump head A-001 24V AC / 60HZ 14 RPM A-149-1 3. Roller assembly A-003 24V AC / 60HZ 30 & 45 RPM A-309-1 4. Pump head A-005 115V AC / 60HZ 14 RPM A-149-2... -
Page 8: Typical Installation
A-100 Page 8 TYPICAL INSTALLATION Pumping unit Discharg e Tube Chemical Suction Container Tube 1. The threadless injector requires 3/8” DIA. Hole only. 2. The 1/4” & ½” Male N.P.T. (fits either) requires a Tee, a Street ELL, of a Saddle Fitting. -
Page 9: Flooded Suction
Page 9 A-100 5. TANK METERING SYSTEM A specially designed chemical tank constructed to support the series A-100 peristaltic pump which is available in three capacities; 7, 15, or 30 gallon, complete with inserts for attaching the pump bracket. The pump is placed low on the tank side to obtain a FLOODED SUCTION. - Page 10 Please follow these steps when cleaning your injection fitting / check valves. 1. Wash the pump, tubing and fittings out with clean water. Blue-White To do this, place the "suction Pump PRIME 99 SEC. CYCLE...
- Page 11 Page 11 A-100 Optional Threaded Injection Fitting (check Valve) installation. The Injection Fitting is designed to 1/2” Male NPT install directly into either 1/4" or 1/2" female pipe threads (NPT). 1/4” Male NPT You can trim the injection point (nose) 2 in.
-
Page 12: Limited Warranty
LIMITED WARRANTY Your new pump is a quality product and is warranted to be free of defects as set down it this policy. All parts, including rubberized goods and labor are covered under warranty for 90 days from date of purchase. Used peristaltic tubes are not war- ranted.
