- Page 1 RPT-110-3PCxxx-K9 REPEATER USER GUIDE Technical Reference Document Version 1.2 © May-2019 RTX A/S, Denmark...
- Page 2 20 cm de toutes les personnes. Disclaimer The contents of this document are provided about RTX products. RTX makes no representations with respect to completeness or accuracy of the contents of this publication and reserves the right to make changes to product descriptions, usage, etc., at any time without notice.
- Page 3 Confidentiality This document should be regarded as confidential, unauthorized copying is not allowed © May-2019 RTX A/S, Denmark, All rights reserved http://www.rtx.dk...
-
Page 4: Table Of Contents
Contents Introduction ................................5 1.1. Document History ............................. 5 1.2. What is new ............................... 5 1.3. Main topics ................................ 5 Installation of Repeater .............................. 6 2.1. Package – Contents/Damage Inspection ......................6 2.2. Damage Inspection ............................7 2.3. Repeaters Mechanics ............................8 2.4. -
Page 5: Introduction
1. Introduction RPT-110-3PCxxx-K9 repeater user guide is designed to give a detailed overview on how to install, register and manage RTX repeaters 1.1. Document History REVISION AUTHOR ISSUE DATE COMMENTS 26-06-2019 15-08-2019 Correct the numbering of contents 20-09-2019 Add FCC and IC Regulatory information Correct Mechanics drawing, remove Ethernet connector 1.2. -
Page 6: Installation Of Repeater
2. Installation of Repeater After planning the network, next is to determine the proper places or location the repeater. The repeater should be mounted as high as possible. 2.1. Package – Contents/Damage Inspection Before Package Is Opened: Examine the shipping package for evidence of physical damage or mishandling prior to opening. If there is a proof of mishandling prior to opening, you must report it to the relevant support center of the regional representative or operator. -
Page 7: Damage Inspection
2.2. Damage Inspection The following are the recommended procedure for you to use for inspection: 1. Examine all relevant components for damage. 2. Make a “defective on arrival – DOA” report or RMA to the operator. Do not move the shipping carton until the operator has examined it. -
Page 8: Repeaters Mechanics
2.3. Repeaters Mechanics The repeaters front end shows an LED indicator that signals different functional states of the repeater. The indicator is off when the repeater is not powered on. -
Page 9: Mounting The Repeater
2.4. Mounting the repeater There are 2 way to mount the repeater. 1: Use the table stand that is in the box 2: Wall mount the repeater using the screws and anchors Screws: M3,5 x 31mm Anchors: Length 29,6mm, OD 6,0mm, ID 4,8mm NOTE: The repeater should be mounted on a wall not higher than 2 meters... -
Page 10: Recommended External Dc Adapters
3. Recommended external DC adapters Module number Specification Manufacturer Plug Type S003GV0500060 S003GB0500060 SMPS,100-240VAC,5V Ten Pao International 600mA with DC Jack S003GS0500060 S003GU0500060... -
Page 11: Repeater Registration
4. Repeater registration There are 2 different ways to register RTX repeater’s “Local Automatic” and “Manually” Local Automatic: In this mode the repeater registers to the base station with best signal strength, this option is only recommended for single cell systems and Multi cell systems where the repeater is only able to sync with one specific base station. - Page 12 Screen shot Step 3: Give the repeater a name and press “save” Step 4: Power on the repeater(s) and registration will start. When the LED is steady green the repeater is successfully registered. Screen shot PARAMETERS DESCRIPTION System counter SINGLE CELL SYSTEM: The base has always RPN00, first repeater will then be RPN01, second repeater RPN02 and third RPN03 (3 repeaters maximum per base) MULTI CELL SYSTEM:...
-
Page 13: Register Repeater(S) "Manually
4.2. Register repeater(s) “Manually” NOTE: Do not power on the repeaters before they have been added on the base station NOTE: When adding first repeater the base station(s) will reboot, this is because encryption is being enabled, the same goes if all repeaters is deleted, then the system will reboot to disable encryption. Step 1: To register repeater(s), navigate to the Repeater page. - Page 14 Screen shot Step 5: Select the RPN for the repeater. ERROR: The repeater will choose the first available slot on the selected base station. RPN x: The repeater connects to RPN x of the chosen base station. E.g. Base station RPN04 + RPN1 repeater, then the repeater connects to “RPN5” Screen shot...
-
Page 15: Firmware Update
5. Firmware update The repeaters are updated over air. Step 1: Navigate to Firmware Update page Step 2: Enter “Firmware Update server address”, “Firmware path” and DECT402x firmware version Screen shot... - Page 16 Empty IP address or DNS of firmware update files source SERVER ADDRESS Valid Inputs: AAA.BBB.CCC.DDD or <URL> Example: firmware.rtx.net or 10.10.104.41 FIRMWARE PATH Empty Location of firmware on server (or firmware update server path where firmware update files are located).
-
Page 17: Led And Button
6. LED and button Power cycle The repeater basically has two modes: Subscribed or not subscribed. When powered up without a registration, the following applies. Power Press Action 00s < x < XXs Nothing 00s < x < 05s Nothing 05s <... - Page 18 n flash n handset relayed by repeater Steady on 1. Registration procedure timed out after 5 min. 2: When key is held pressed the LED will light up in 2 sec. to indicate that releasing the key will delete registration, LED turns off after 4 more sec.
