LOCKING SYSTEM EURO 5000
LOCKING SYSTEM EURO 5000
3.31.50XX.0
with profi le-cylinder and 3 keys
Date of issue 06/2017 • All specifi cations are approximate • Errors and changes excepted product photos are for illustration purposes only
Available options:
• door thicknesses 52 - 60 mm, 72 - 80 mm, 82 - 90 mm, 92 - 100 mm, 102 - 110 mm, 112 - 120 mm, 132 - 140 mm, 152 - 160 mm
• electronic status indicator profi le-cylinder
• electronic status indicator inside handle
• Multiple Locking System Euro 5000
• Locking System Euro 5000 single with latch
FEATURES
Operation angle
Mounting
Temperature range
Cap
Model
Tested up to
MATERIALS & SURFACE
Housing, Cap
Handle
Inside guide
Outside guide
Conformity of the materials
www.stuv.de
90°
16 x Countersunk screw M5
-40°C up to +80°C
luminescent
right hand and left hand mountable
200.000 cycles
Plastic, dyed
Stainless steel
Plastic, dyed
Zinc die-casting, plated
all materials used are RoHS and REACH compliant
1
MADE
IN
GERMANY
Advertisement
Table of Contents
Related Manuals for Stuv EURO 5000
Summary of Contents for Stuv EURO 5000
- Page 1 • door thicknesses 52 - 60 mm, 72 - 80 mm, 82 - 90 mm, 92 - 100 mm, 102 - 110 mm, 112 - 120 mm, 132 - 140 mm, 152 - 160 mm • electronic status indicator profi le-cylinder • electronic status indicator inside handle GERMANY • Multiple Locking System Euro 5000 • Locking System Euro 5000 single with latch FEATURES Operation angle 90° Mounting...
- Page 2 When changing the profile half cylinder, make sure that the locking lug is in 90° position (3 o‘clock) SAFETY NOTICE For safety reasons a second person must be on the outside of the door when testing the emergency escape function with the door installed www.stuv.de...
- Page 3 Washer Inside handle Stop bolt Outside handle Inside guide Outside guide Inside guide Stop bolt Square shaft Inside handle When changing the profile half cylinder, make sure that the locking lug is in 90° Figure Z position (3 o‘clock) www.stuv.de...
- Page 4 TOLERANCE COMPENSATION 3.31.50XX.0 Washer Hexagon socket screw Tolerance compensation Square shaft Tolerance compensation nose Fig 1 Inside handle Fig 2 Fig 3 Fig 4 Tolerance compensation nose (Pos.10) Inner lever nose (Pos.2) www.stuv.de...
- Page 5 DRILLING PATTERN 3.31.50XX.0 Door Door Outside Inside Frame Frame Inside Outside Door www.stuv.de...
