Programming manual
PIXEL UP
40405
Panel with Due Fili Plus audio/video electronic unit, display and alphanumeric keyboard
MI_40405_49401379A0_MI_00_P103E_en.indd 1
22/01/2019 18:42:53

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elvox PIXEL UP 40405 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vimar Elvox PIXEL UP 40405

Summary of Contents for Vimar Elvox PIXEL UP 40405

  • Page 1 Programming manual PIXEL UP 40405 Panel with Due Fili Plus audio/video electronic unit, display and alphanumeric keyboard MI_40405_49401379A0_MI_00_P103E_en.indd 1 22/01/2019 18:42:53...
  • Page 2 PIXEL UP: 40405 Video entryphone panel with Due Fili Plus audio/video electronic unit, display and alphanumeric keyboard Outdoor video entryphone unit with call from contacts list. The device is supplied with a display and keyboard used to make calls using the contacts list or by directly entering the extension number to be called.

  • Page 3: Picture Control

    PIXEL UP: 40405 Description The AV module is equipped with: - interfacing to acoustic devices used by the hard-of-hearing; - voice synthesis, for signalling the call state; - full-duplex audio with Larsen effect removal; - Front LEDs, for signalling the call state; - automatic gain control (AGC), to stabilise the speaker output level, whatever the type of installation;...
  • Page 4 PIXEL UP: 40405 The standard mode provides optimal operation in typical environmental conditions, while the enhanced portrait mode highlights the caller in a backlit situation (such as at dawn). Can be selected with Save Prog. Dusk/dawn function This lets you enable automatic brightness control of the entrance panel backlighting according to the ambient light brightness. Can be selected with Save Prog.

  • Page 5: Configuration Via Pc

    The advanced configuration of the electronic module is performed via a PC, using the “SaveProg” Due Fili system management software, available from the website www.vimar.com, and connecting the electronic module to the PC via a USB-MiniUSB cable. Take care, when the PC is connected to the USB port the control panel is disconnected and disabled.
  • Page 6 PIXEL UP: 40405 3.2.2. Setting contacts list filters PC configuration software is used to enable a set of filters for targeted access to the sub-sets of the contacts list. The available filters are described below. 3.2.2.1. Initials pre-filter This filter lets you access a section of the contacts list identified by the names that start with the chosen letter. A-B-C D-E-F G-H-I...

  • Page 7: Additional Information

    PIXEL UP: 40405 3.2.2.3. Stair filter The Stair filter lets you access the subset of users paired with a specific stair or all users. It can be combined with the two previous filters. In particular, with the buildings filter you obtain: Tutti Tutti Scala A...
  • Page 8 PIXEL UP: 40405 3.3. Configuration from menu The display provides the ability to configure the basic parameters of the outdoor unit. There are two menus: 1. administrator: the administrator side lets you modify the display module interface; 2. installer: lets you change some of the functional parameters of the outdoor unit. You access the menu by simultaneously pressing (UP) + (DOWN) for 5 secs and entering the respective passwords.

  • Page 9: Installer Menu

    PIXEL UP: 40405 3.3.1. Installer menu The structure is shown below: Level 0 Level 1 Level 2 Level 3 Level 4 Settings Contacts List Edit Select “Name”, id 2f to scroll and Name Enter name search Information Enter info Secondary info Enter info Visible YES/NO...
  • Page 10 PIXEL UP: 40405 Display Language Italian, English, French, German, Spanish, Greek, Portuguese, Russian, Swedish, Dutch and Polish (Default: French) Menu Font Normal/Large (Default: Large) Navigation Direct, Navigable, Expanded Brightness 1-5 (Default:5) Colours B/W, BLUE, GREEN (Default: BLUE) Standby ON/OFF (Default: ON) Outdoor unit Audio Speaker...

  • Page 11: Contacts List

    PIXEL UP: 40405 3.3.2. Contacts List This section is used to edit or add to the user contacts list stored in the outdoor unit. The administrator can only edit some fields of a user while the installer can edit all fields, enter a new user, delete a user or the whole contacts list.
  • Page 12 PIXEL UP: 40405 3.3.4.2. Menu It is used to select: • Font: Normal/Large Changes the font size, to improve readability. Recherche Par Nom Appel Par N° Ouverture Par Code Appel Gardien Normal Large • Navigation: Direct/Navigable/Expanded Edits the style of the home page viewed and relative access modes to the available functions. Navigable Direct Extended...

  • Page 13: Outdoor Unit

    PIXEL UP: 40405 3.3.4.3. LCD This lets you define the operating parameters of the display • Brightness: 0-5 Brightness level. When there are high internal temperatures, the display is automatically dimmed. • Colours: B/W, BLUE, GREEN Lets you select one of the predefined colour schemes for viewing the menu, according to readability. BLUE GREEN •...
  • Page 14 PIXEL UP: 40405 3.3.5.3. Timing This lets you choose the times for: • Lock Lock command duration • Talk Maximum talk duration • Answer Time available for answering a call after the ringtone cycles have ended. • Self-start Maximum duration of the self-start time. 3.3.5.4. Call digits No.

  • Page 15: Notification Messages

    Check the module connections and restart the electronic unit. UPGRADE THE MODULES Upgrade the display module and the audio video module to the latest FW release, which can be downloaded from the Vimar website, along with SaveProg. Comm. Error If the problem persists, please contact customer service.
  • Page 16 PIXEL UP: 40405 Updating The devices are updated via a USB connection. • To update the AV module, connect the USB as indicated in the figure in chapter 3.1 and run the update. • To update the display module disconnect the device from the other modules and connect the USB to the module. The update must be run within 30 s.
  • Page 17 PIXEL UP: 40405 MI_40405_49401379A0_MI_00_P103E_en.indd 17 22/01/2019 18:43:00...
  • Page 18 PIXEL UP: 40405 MI_40405_49401379A0_MI_00_P103E_en.indd 18 22/01/2019 18:43:00...

  • Page 19: Installation Rules

    PIXEL UP: 40405 The instructions manual can be downloaded from the website www.vimar.com Installation rules Installation must be carried out by qualified persons in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed.
  • Page 20 Viale Vicenza 14 36063 Marostica VI - Italy 49401379A0_MI_EN 00 1901 www.vimar.com MI_40405_49401379A0_MI_00_P103E_en.indd 20 22/01/2019 18:43:00...
