HAI Access Control

HAI Access Control allows you to access doors by opening an electric or magnetic lock, arm and disarm the security system, and
achieve many home automation functions such as controlling lighting, energy management, surveillance, and audio. The Access
Control Reader is a 125 KHz high security, digitally encrypted, 26-bit proximity card reader. It has durable and scratch resistant
polycarbonate housing and full epoxy potting which ensures successful operation even in harsh environments.
Users can utilize either a standard credit card sized Access Control Card or the convenient Access Control Key Tag to access the
system. Each card is attached to a user code in the controller which can be managed with several privileges. Users can be granted
privileges based on time of day and day of week as well as any other desired events.
The HAI Access Control Card Reader can be used for:
Validating HAI Access Control Cards or Key Tags
Logging of Users assigned to Access Control Cards or Key Tags

Activating an Electric or Magnetic Lock

Validating HAI Access Control Cards and Key Tags

It its normal state (i.e. the lock output is in the locked state), a single LED indicator at the bottom of the Access Control Card Reader
is illuminated red. When an Access Control Card or Key Tag is presented at an Access Control Card Reader
If a valid card or key tag is presented:
When a valid card or key tag is presented at the reader, the Access Control Card Reader will beep once and all 9 LED indicators will
illuminate the color of the current security arming state for that area.
LED indicators illuminate red: The security system in the respective area is currently armed
LED indicators illuminate green: The security system in the respective area is currently disarmed
Note: The LED indicators will remain illuminated until the "Door Unlock" time expires. The "Door Unlock" time is the amount of
time configured for the door to remain unlocked when a valid card or key tag is presented at an Access Control Reader.
If an invalid card or key tag is presented:
If an invalid card is presented, the Access Control Card Reader will not beep or change the color or pattern of the LED indicators.
Logging of the User assigned to the Access Control Card or Key Tag
When a card or key tag is presented at the reader and if the card that was presented is configured to log activity, the HAI controller
will log that the user presented their card at the respective Access Control Card Reader. The HAI controller will log:
The Access Control Card Reader where the card was presented
The User that presented the card
If the card was accepted or declined
The time and date in which the card was presented
Activating an Electric or Magnetic Lock
The HAI Access Control Card Reader has an output for an electric or magnetic door lock. When a valid card or key tag is presented at
the reader, all 9 LED indicators will illuminate indicating that the door is currently unlocked (the color of the LED indicators signifies
the current security arming state for that area). The LED indicators will stay illuminated while the lock is unlocked. The lock will
remain unlocked until the "Door Unlock" time expires. The "Door Unlock" time is configured in the setup of the reader.
Note: When a valid card or key tag is presented at the reader, all 9 LED indicators will illuminate and remain illuminated until the
"Door Unlock" time expires, even if there is not a physical lock connected to the reader.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HAI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Home Automation HAI

  • Page 1 Logging of the User assigned to the Access Control Card or Key Tag When a card or key tag is presented at the reader and if the card that was presented is configured to log activity, the HAI controller will log that the user presented their card at the respective Access Control Card Reader. The HAI controller will log:...
  • Page 2 Arming or Disarming of the Security System in the respective Area Each HAI Access Control Card Reader is assigned to an Area. When a valid card or key tag (a card or key tag that is valid for the current time of day and day of week, that is assigned for the respective reader, and that has arming and disarming privileges for the...
  • Page 3 #=DEL Note: you have 3 minutes to complete the operation once the system is put into configuration mode. If an HAI Access Control Card or Key Tag has not been swiped 3 times within the first 3 minutes, the controller will automatically exit configuration mode.
  • Page 4 Assign Access Control Cards and Key Tags to Specific Access Control Readers Each Access Control Card or Key Tag can be assigned to 1 or more Access Control Readers. When an Access Control Card or Key Tag is assigned to specific readers, the user only has access at the assigned readers. Users do not have access to any reader in which their Access Control Card or Key Tag is not assigned.
  • Page 5 Press the ' # ' (#=CFG) key to put the system into configuration mode. The display will show: CONFIGURE READER 1 SWIPE CARD 3 TIMES Go to the Access Control Reader to be enrolled and swipe any HAI Access Control Card or Key Tag 3 times in front of the reader: READER 1 ADDRESS: 8.5.0.137 #=DEL Note: you have 3 minutes to complete the operation once the system is put into configuration mode.
  • Page 6 Area Assignment Each Access Control Reader can be assigned to a specific Area on the controller. When used for security arming and disarming, the security mode of the Area where the Access Control Reader is assigned will be changed. READER 1 AREA: Enter the Area for the selected Access Control Reader followed by the ' # ' key.
  • Page 7 Lock Type The Lock Type specifies the type of door lock that is connected to the selected Access Control Reader. The Lock Type can be either be configured for a "Fail Secure" device (door is locked when power fails) or "Fail Safe" mode (door is unlocked when power fails). READER 1 LOCK TYPE: 0=SECURE 1=SAFE...
