IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

Tools Needed

Helpline

If you have any problems with this product or
require any replacement fittings please contact
Customer Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is
found to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
• Carefully check that you have all parts before beginning assembly.
instructions.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
PRODUCT INFORMATION
• Made from MDF with painted finish.
• Made in China.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent
scratching or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration
or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if
necessary.
855836 ISABELLA SINK CONSOLE
ASSEMBLY INSTRUCTIONS.
Page 1 of 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISABELLA 855836 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next ISABELLA 855836

  • Page 1 855836 ISABELLA SINK CONSOLE ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 FITTINGS G x 2 J x 4 M x 4 N x 4 P x 4 PARTS (1) Top Panel x 1 (2) Side Panel (L&R) x 2 (3) Bottom Panel x 1 (4) Back Foot (L&R) x 2 (5) Shelf Panel x 1 STEP ONE 1.
  • Page 3 STEP THREE 1. Insert 4 x cambolts (B) and 1 x wooden dowel (C) into side panel 2-R. 2. Attach back rail 8,front top rail 7 and top back rail 10 to side panel 2-R. 3. Insert 4 x camlocks (A) into back rail 8, front top rail 7 and top back rail 10.
  • Page 4 STEP SIX 1. Attach top panel 1 to the assembled unit with 4 x bolts (J) and tighten. STEP SEVEN 2. Insert the back panel 11 into grooves of bottom panel 3. STEP EIGHT 1. Attach back panel 11 to middle back rail 8 with 3 x screws (F), tighten with a screwdriver.
  • Page 5 STEP NINE 1. Attach 4 x hinges (D) to door panels 6 (both L&R) with 8 x screws (E). 2. Attach 2 x handle (G) to door panel 6 (both L&R) with 2 x screw (H), tighten with a screwdriver. STEP TEN 1.
  • Page 6 NB: Wall fixings are not incuded, please source suitable fixings for your wall type. If in doubt please consult a qualified trades person. Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 6 of 6...
