STUDIO
Dual Rain Shower
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of
publication. Kohler Co.reserves the right to make changes in product character-
istics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer.
They contain important information.
NOTES:
1. Shut off the water supplies to the fitting.
2. Inspect the supply tubing for damage. Replace as necessary.
3. Observe local plumbing codes.
4. Recommended working pressures is 2 to 5bars.
5. The highest working pressure for showerhead is 0.5 Mpa(5 bars). If it
exceeds 0.5Mpa(5 bars), a pressure
reducer is needed. The highest water and environment temperature is 60ºC.
Please keep showerhead away from heater, or it may become damaged and
cause injury to the user.
ROUGH-IN
1144
501.5
55
193
350
850
33
1200~1300
G1/2"
1012
Recommended Height
to Finished Floor
www.englefield.co.nz
5624A
