Multihead Hydraulic Swaging Unit
(MHSU)—16FK
Operating Instructions
READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE USING THE MHSU.
Definitions
Statements and symbols are used in this document
to identify safety concerns. Read the definitions
below before setting up and operating the MHSU.
WARNING
Statements that identify conditions or
practices that could result in personal injury
or loss of life.
Safety Precautions
W ARNING, EYE PROTECTION
Safety glasses must be worn when setting
up and operating the MHSU. Failure to wear
safety glasses may result in serious personal
injury.
CAUTION
Do not tamper with or alter any components
of the MHSU. Tampering with or altering
components of the MHSU may cause
equipment failure and/or affect fitting
performance.
1 in. medium-pressure 16FK MHSU with base
for use with 1 in. medium-pressure tube fittings
CAUTION
Statements that identify conditions or
practices that could result in damage to the
equipment or other property.
WARNING
If a malfunction or any sign of excess
leakage occurs, do not use the MHSU.
Return it to your authorized Swagelok
representative for assistance. Continued use
may result in serious personal injury, cause
equipment failure, and/or affect fitting
performance.
CAUTION
Do not use the hand pump after the
indicator knob releases. Failure to stop
pumping after the indicator knob releases
may affect fitting performance.
Advertisement
Table of Contents
Related Manuals for Swagelok 16FK MHSU
Summary of Contents for Swagelok 16FK MHSU
- Page 1 Multihead Hydraulic Swaging Unit (MHSU)—16FK Operating Instructions 1 in. medium-pressure 16FK MHSU with base for use with 1 in. medium-pressure tube fittings READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE USING THE MHSU. Definitions Statements and symbols are used in this document to identify safety concerns.
- Page 2 Base Lock ring Die head Chamfer block Safety glasses Gap inspection gauge Shipping Case Contents The following items ship with each case: 16FK MHSU Hydraulic Swaging Unit ■ 1 in. Chamfer Block ■ 16FK Gap Gage ■ Safety Glasses ■...
- Page 3 C. For the 16FK MHSU, use the chamfer block Indicator knob provided. Insert the cut end of the tubing into the chamfer block, and while firmly...
- Page 4 Mark Bottoming marks Body Tube face Fig. 5 Tighten Nut with Wrench Fig. 3 Tube Bottoming Mark CAUTION Use the Swagelok 16FK gap inspection gauge to ensure the fitting has been sufficiently tightened or system leakage could result.
- Page 5 Gauging Instructions Die Head Replacement 1. Unthread and remove the threaded lock ring Position the Swagelok 16FK gap inspection gauge from the hydraulic housing. adjacent to the gap between the nut and body hex. See Fig. 6. 2. Remove the previously installed die head from If the gauge will not enter the gap, the fitting is the hydraulic housing.
- Page 6 A small amount of leakage is pump components. acceptable. If oil is continuously dripping or there is a puddle, return the unit to your authorized Swagelok representative. Warranty Information Swagelok products are backed by The Swagelok Limited Lifetime Warranty. For a copy, visit swagelok.com or contact your...
