- Page 1 Operation Manual Warranty Card Household electrical convection heater, Plaza Ext series ВЕР/ЕХТ-1000 | BEP/EXT-1500 | BEP/EXT-2000 Prior to operation read carefully this Manual and keep it in a safe accessible place.
-
Page 2: Table Of Contents
2 Contents Designations Safety rules Purpose Convector design Technical specifications Operation Care and maintenance Safety measures Maintenance Installation Electrical diagram Service life Storage Date of manufacture Warranty Scope of delivery Rules of disposal Product certification Warranty card Designations After the convector is installed, the electric plug should be located in an accessible place. -
Page 3: Safety Rules
Safety Rules 3 Safety rules If the device falls in water, do not try to take it out • of it. Immediately take the plug out of the socket. Never operate the heater with damaged cable, plug • in case of faults, falls or other damages. Contact a ATTENTION! skilled electrician to check electrical, mechanical The general safety rules should be observed during... -
Page 4: Purpose
4 Safety rules This device is not intended for using on carpets is not recommended by the manufacturer and • with long nap and on Flocatti carpets. may lead to fire, electric shock or accident. During operation ensure the cable does not touch •... -
Page 5: Convector Design 5
Convector design 5 Remote control: Convector design Fig. 2 Fig. 4 1. Control unit 2. Air bleeding grills 1. Power On/Off button 3. Convection chamber 2. Full/half power 4. Temperature sensor 3. Control buttons 5. Stands 4. Control buttons 6. Rollers 5. -
Page 6: Technical Specifications
6 Technical specifications Technical specifications Part No. ВЕР/ЕХТ-1000 ВЕР/ЕХТ-1500 ВЕР/ЕХТ-2000 Heating power I, W 1000 Heating power II, W 1000 1500 2000 Rated watts input I, kW 0.75 Rated watts input II, kW Rated voltage, V ~ Hz 220-240 ~ 50 220-240 ~ 50 220-240 ~ 50 Rated current, A... -
Page 7: Care And Maintenance
Operation 7 display, the time indicator flashes (the timer is set by of heating. Full power mode is set by default. Press the the clock). Press the buttons to increase power selector button to set the heating power. or decrease the time by one hour; the timer can be set The heater will operate at maximal power. -
Page 8: Safety Measures
8 Safety measures Prior to cleaning disconnect the heater from the mains. be replaced by the service centre representative or Loosen the spacer screws on the latches. Lower two another qualified specialist. latches «Р» (see Fig. 6) on the rear panel of the heater and pull the device to yourself. -
Page 9: Installation 9
Installation 9 The device can be fixed on the bracket as follows: screw two fixing screws at the top into the latches on the bracket; put the lower part of the convector on the bracket using the special holes on the lower part of the convector;... -
Page 10: Warranty
(In absence of the new certificate copy in the box ask the Seller for a copy) Scope of delivery Manufacturer: 1. Heater BALLU INDUSTRIAL GROUP LIMITED 2. Set of stands with rollers Suite 18В, 148 Connaught Road Central, Hong 3. Wall-mounting brackets Kong, China 4. - Page 11 Such modifications are introduced without prior notice on the web-site: www.ballu.ru to the Buyers and do not involve liabilities for Additional details you can obtain from the Seller or modification/improvement of previous products.
- Page 12 TYPE Warranty period IR-heaters for installation into suspended ceilings (series BIH-S) 5 (five) years Air conditioners (BSE, BSEI, BSA, BSAI, B20I-FM, B30I-FM, B40I-FM, BSEI-FM, BDI-FM, 3 (three) years BCI-FM, BPHS)*, air dryers (BDM), electrical convectors, electrical household IR-heaters, electrical fan heaters (series VKH) Air conditioners (BSWI), water heaters (series BWH/S Nexus (H), BWH/S Nexus titanium 2 (two) years edition (H), BWH/S Omnium 0 (U)**, BWH/S Space***, electrical IR-heaters (series BIH-...
- Page 13 of electrical or water supply mains and other external technical maintenance of the water heating units networks; according to the Operation Manual, including: non- • defects due to ingress of foreign objects, liquids observance of the frequency and terms of technical (except for those provided in the Operation maintenance provided by the instruction in the amount Manual), insects and their waste products, etc.
- Page 14 only the original (patented) accessories of the unit and check the operation of the air conditioner manufacturer. in all modes. This will provide stable operation of 2. Prior to operation of the air cleaner remove the your air conditioner. filters from the package. Do not install the air It should be noted that there is a number of cleaner in an air flow (in draft, in front of the fan, peculiarities of using the air conditioner in winter.
-
Page 15: Warranty Card
To be filled in by the Seller Taken by the specialist during maintenance WARRANTY CARD TEAR-OFF CARD To be kept by the Customer for warranty service Model Model Serial number Serial number Date of sale Date of sale Seller's title Date of acceptance for repair Order No. - Page 16 www.ballu.ru...
