- Page 1 FS-23 ERTICAL AISE SSEMBLY ANUAL Model: FS-23 REV: 030620...
- Page 2 ESSAGE TO USTOMERS Frank Trulaske began TRUE Fitness® over thirty-five year ago with the simple philosophy of delivering superior fitness products, service, and support. Today, TRUE is the global leader in premium fitness equipment for the commercial and residential markets. Our goal is to be the leader in technology, innovation, performance, safety and style.
-
Page 3: Table Of Contents
ABLE ONTENTS ......................AFETY ..............ENERAL ARE AND AINTENANCE & W ............... ACHINE IMENSIONS EIGHTS ....................ARNING ABELS ......................SSEMBLY ....................ARTS IAGRAMS ................. ARRANTY........ -
Page 4: Safety
AFETY ACILITY AND AFETY RECAUTIONS 1. Review and understand all of the warning labels affixed to this machine and on the facility safety sign. 2. Be certain that the machine operation is understood before it is used. Refer to the instructional Procedure Label affixed to the machine. - Page 5 AFETY 12d. This equipment is designed for standard olympic size weight plates with a 50mm bore (1.9”). 12e. Do not exceed the maximum weight capacity of the machine. Maximum plate size is 45 lbs. (25 kg.). 13. On Selectorized and Cable equipped machines: 13a.
- Page 6 AFETY AINTENANCE AFETY RECAUTIONS 1. Refer to Maintenance Schedule label on the machine as well as this manual for when to perform maintenance. 2. Check the function of your machine DAILY by verifying the following: • Inspect cables and end fittings for any signs of wear. Replace if worn, frayed or damaged with original TRUE replacement components.
-
Page 7: General Care And Maintenance
Be sure all hardware is tight before using the machine. Retain these instructions for future reference. If you have any questions, do not hesitate to contact your TRUE dealer or TRUE Fitness Corp. at (800) 883-8783 or service@truefitness.com. -
Page 8: Machine Dimensions & Weights
& W ACHINE IMENSIONS EIGHTS Carton Size: 84.25” X 38.75” X 7.75” 215 cm x 100 cm x 20 cm Carton Weight (as shipped) = 173 lbs (79 kg.) Assembled Weight (as shown) = 156 lbs (71kg.) Maximum User Weight = 300 lbs. (136 kg.) -
Page 9: Warning Labels
ARNING ABELS The following are the warning labels required for this product. If any of these labels are missing or become damaged contact TRUE. Note: these labels are not to scale. LBL-PR-FS23 LBL-WRN-0016... -
Page 10: Assembly
SSEMBLY Required Tools: • steel hammer • 3/8” diameter pin punch • (2) 9/16 wrenches or Sockets With Ratchet NOTE CURVE TO TOP Handles... - Page 11 SSEMBLY Drive pins through frame tube and handle. Be sure they are even front to back. LONG TUBE ON TOP SHORT TUBE ON BOTTOM...
-
Page 12: Parts Diagrams
ARTS IAGRAMS... - Page 13 ARTS IAGRAMS...
- Page 14 ARTS IAGRAMS...
-
Page 15: Warranty
Page # 15 of 17 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com... - Page 16 (if anyone other than a TRUE authorized dealer/ technician initially assembles and installs the Product, this The FS-23 comes with one serial number on the base of the Limited Warranty will be void unless the written authorization machine. Please write down your serial number below and keep of TRUE is first obtained).
- Page 17 If you prefer to mail your warranty card, have the owner of the product complete the information below and return it to TRUE Fitness within 30 days from the date of equipment installation.
