TRUE
manufacturing co
CONGRATULATIONS!
You have just purchased the finest commercial refrigerator
available. You can expect many years of trouble-free operation.

TABLE OF CONTENTS

Ownership, Uncrating, & How to Connect to Electricity
WARRANTY
TRUE MANUFACTURING CO., INC.
2001 East Terra Lane • O'Fallon, Missouri 63366-4434
(636)-240-2400 • FAX (636)-272-2408 • INT'L FAX (636)272-7546 • (800)-325-6152
Parts Department (800)-424-TRUE • Parts Department FAX# (636)-272-9471
Web: www.truemfg.com
.,
.
inc
2
3
4
5
6
7
8
8
9
12
21
22
23
24
25
INSTALLATION MANUAL
TMC-34
TMC-58-DS-HC
INSTALLATION MANUAL
milk coolers
milk coolers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TMC-49-HC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for True TMC-49-HC

Summary of Contents for True TMC-49-HC

  • Page 1: Table Of Contents

    General Maintenance WARRANTY Warranty TMC-58-DS-HC INSTALLATION MANUAL milk coolers TRUE MANUFACTURING CO., INC. 2001 East Terra Lane • O’Fallon, Missouri 63366-4434 (636)-240-2400 • FAX (636)-272-2408 • INT'L FAX (636)272-7546 • (800)-325-6152 Parts Department (800)-424-TRUE • Parts Department FAX# (636)-272-9471 Web: www.truemfg.com...

  • Page 2: Safety Information

    You have selected one of the finest commercial refrigeration units made. It is manufactured under strict quality controls with only the best quality materials available. Your TRUE cooler when properly maintained will give you many years of trouble-free service. WARNING: Use this appliance for its intended purpose as described in this Owner Manual.

  • Page 3: Proper Disposal, Connecting Electricity, & Adapter Plugs

    NEMA plugs TRUE uses these types of plugs. If you do not have the right outlet have a certified electrician install the correct power source. NOTE: International plug configurations vary by voltage and country.

  • Page 4: Installation

    • Lamps must be replaced by identical lamps only. Before you start to install your TRUE unit, carefully inspect it for freight damage. If damage is discovered, immediately file a claim with • Appliance tested according to the climate classes 5 and 7 the delivery freight carrier.

  • Page 5: Wire Gauge Chart

    TRUE milk coolers truemfg WIRE GAUGE CHART 115 Volt s Distance In Feet To Center of Load 230 Volts Distance In Feet To Center of Load Amps 20 30 40 50 60 70 80 90 100 120 140 160 Amps...

  • Page 6: Locating

    TRUE milk coolers truemfg LOCATING A. Remove skid by using a phillips head screwdriver and an 35° adjustable wrench. F° For easy removal from the skid, unscrew and remove grill from the back of the cooler. C. Remove the four brackets from the base of the cooler.

  • Page 7: Leveling

    WARNING Warranty is void if ventilation is insufficient. Proper leveling of your TRUE cooler is critical to operating success. Effective condensate removal and door operation will be effected by leveling. (See image 2) 35°...

  • Page 8: Setup

    RECOMMENDATION - Before loading product we recommend • Electronic control with display: you run your TRUE unit empty for two to three days. This allows you - In countertop to be sure electrical wiring and installation are correct and no ship- - In top louvered panel ping damage has occurred.

  • Page 9: Mechanical Temperature Controls Sequence Of Operation

    TRUE milk coolers truemfg MECHANICAL TEMPERATURE CONTROLS COIL SENSING An evaporator coil sensing temperature control ensures that the evaporator coil will remain clear of frost and ice by not allowing the compressor to restart until the coil temperature is above the freezing temperature.
  • Page 10 TRUE milk coolers truemfg MECHANICAL TEMPERATURE CONTROLS WHEN TO MAKE AN ADJUSTMENT TO A MECHANICAL TEMPERATURE CONTROL We advise to make a mechanical temperature control adjustment only for a high altitude location. HOW TO ADJUST A MECHANICAL TEMPERATURE CONTROL Back of Temperature...
  • Page 11 TRUE milk coolers truemfg MECHANICAL TEMPERATURE CONTROLS Bottom of Temperature Control DANFOSS TEMPERATURE CONTROL ADJUSTMENT FOR HIGH ALTITUDE APPLICATIONS: Cut-out Adjustment Screw Allen (5/64" or 2 mm.) REQUIRED TOOLS: • Allen Wrench (5/64”) • Torx Screw (T-7) Cut-in Adjustment TERMS:...

  • Page 12: Electronic Temperature Controls Sequence Of Operation

    TRUE milk coolers truemfg LAE ELECTRONIC TEMPERATURE CONTROLS LAE ELECTRONIC CONTROL GENERAL SEQUENCE OF OPERATION 1. Cabinet is plugged in. a. Display will illuminate. b. Interior light will illuminate on Glass Door Models only. Solid door cabinet lights are controlled by the door switch.
  • Page 13 TRUE milk coolers truemfg LAE ELECTRONIC TEMPERATURE CONTROLS PRODUCT ADVISEMENT DETERMINING THE TYPE OF ELECTRONIC CONTROL DISPLAY Reason for Advisement Both Danfoss and LAE electroinc controls utilize similar digital displays. To provide the visual differences and operations between the displays used for the LAE Electronic Control and the Danfoss Electronic control NOTE: Displays do not interchange with each other due to wiring and programming limitations.
  • Page 14 TRUE milk coolers truemfg LAE ELECTRONIC TEMPERATURE CONTROLS HOW TO USE AN LAE ELECTRONIC CONTROL Indicator lights for Refrigeration/Heating Mode, Fan Operation, Defrost Mode. LAE Control LAE Control Icons Compressor Running Evaporator Fan Running Cabinet in Defrost Activation of 2nd Parameter Set...
  • Page 15 TRUE milk coolers truemfg LAE ELECTRONIC TEMPERATURE CONTROLS HOW TO LOCK AND UNLOCK LAE CONTROLLER: LAE Control Info / Set Point Manual Defrost / Button Down Button Manual Activation Stand-By Up Button Button HOW TO TURN OFF THE LAE ELECTRONIC CONTROL: TURN OFF THE LAE ELECTRONIC CONTROL: May need to unlock control.
  • Page 16 TRUE milk coolers truemfg LAE ELECTRONIC TEMPERATURE CONTROLS LAE Control Info / Set Point Manual Defrost / Button Down Button Manual Activation Stand-By Up Button Button HOW TO CHANGE THE “SET POINT”: CHANGING THE “SET POINT”: May need to unlock control.
  • Page 17 TRUE milk coolers truemfg LAE ELECTRONIC TEMPERATURE CONTROLS LAE Control Info / Set Point Manual Defrost / Button Down Button Manual Activation Stand-By Up Button Button HOW TO INITIATE A MANUAL DEFROST: INITIATE A MANUAL DEFROST: May need to unlock control.
  • Page 18 TRUE milk coolers truemfg LAE ELECTRONIC TEMPERATURE CONTROLS LAE Control Info / Set Point Manual Defrost / Button Down Button Manual Activation Stand-By Up Button Button HOW TO CHANGE “DEFROST INTERVALS”: CHANGING “DEFROST INTERVALS”: May need to unlock control. This can only be changed if defrost mode parameter “DFM” is set for “TIM”.
  • Page 19 TRUE milk coolers truemfg LAE ELECTRONIC TEMPERATURE CONTROLS LAE Control Info / Set Point Manual Defrost / Button Down Button Manual Activation Stand-By Up Button Button HOW TO CHANGE DISPLAY READOUT FROM FAHRENHEIT TO CELSIUS: CHANGE DISPLAY READOUT FROM FAHRENHEIT TO CELSIUS: May need to unlock control.
  • Page 20 TRUE milk coolers truemfg LAE ELECTRONIC TEMPERATURE CONTROLS LAE Control Info / Set Point Manual Defrost / Button Down Button Manual Activation Stand-By Up Button Button HOW TO DISPLAY PROBE TEMPERATURES: DISPLAYING TEMPERATURE PROBES, T1, T2, T3: WHY: To display temperature probe readings in different locations of the cabinet.

  • Page 21: Maintenance, Care, Cleaning Tmc-49-Hc

    TRUE milk coolers truemfg MAINTENANCE, CARE, CLEANING CLEANING THE CONDENSER COIL When using electrical appliances, basic safety precautions should be followed, including the following: TOOLS REQUIRED • Phillips Screwdriver • Air Tank or CO2 Tank • Stiff Bristle Brush •...

  • Page 22: Important Warranty Information

    CO 2 , nitrogen, or pressurized air. Reconnect the electrical power to the unit. If you have any questions, please call TRUE Manufacturing at 636- If you cannot remove the dirt adequately, please call your refrigera- 240-2400 or 800-325-6152 and ask for the Service Department.

  • Page 23: Stainless Steel Equipment Care And Cleaning

    TRUE milk coolers truemfg STAINLESS STEEL EQUIPMENT CARE 8 STEPS THAT CAN HELP PREVENT RUST ON AND CLEANING STAINLESS STEEL: USING THE CORRECT CLEANING TOOLS CAUTION: Do not use any steel wool, abrasive or chlorine based products to clean stainless steel surfaces.

  • Page 24: General Maintenance

    TRUE milk coolers truemfg GENERAL MAINTENANCE To clean interior of cooler move the unit close to a floor drain. Remove floor racks from inside of the unit. Wash interior of the tank. At the rear of the unit and below the grill there is a tank drain plug that will need to be removed to release the waste from inside of the unit.

  • Page 25: Warranty

    TRUE and upon proper installation and start-up in accordance with the instruction packet supplied with each TRUE unit. TRUE’s obligation under this warranty is limited to a period of three (3) years from the date of original installation or 39 months after shipment date from TRUE, whichever occurs first.
