  • Page 1 MOP-TFT320240-35A-BLM-TPN Hardware Manual Revision 1.0...
  • Page 2: Revision History

    Revision History Revision Date Description Author May 26, 2017 Initial Release Divino MOP-TFT320240-35A-BLM-TPN...
  • Page 3: Table Of Contents

    11.3 Static Charge Precaution .............................. 13 11.4 Packing ..................................13 11.5 Precautions during Operation ..........................13 11.6 Storage Recommendations ............................. 14 11.7 Safety Precautions ..............................14 12 Ordering ....................................15 12.1 Part Numbering Scheme ............................... 15 12.2 Options ..................................15 13 Contact ....................................15 MOP-TFT320240-35A-BLM-TPN...
  • Page 4: General Information

    The LED Life-time is defined as the estimated time to 50% degradation of initial brightness at Ta=25°C and IF =40mA. The LED lifetime could be decreased if operating IF is larger than 40mA, and increased if IF is less than 40mA. MOP-TFT320240-35A-BLM-TPN...
  • Page 5: External Dimensions

    5 External Dimensions Figure 1: MOP-TFT320240-35A-BLM-TPN Drawing MOP-TFT320240-35A-BLM-TPN...
  • Page 6: Electro-Optical Characteristics

    Instruments or compatible. For contrast ratio, Surface Luminance, Luminance uniformity and CIE, the testing data is based on TOPCON’s BM-7 or BM-5 photo detector or compatible. *Note 7: For TFT module, Gray scale reverse occurs in the direction of panel viewing angle. MOP-TFT320240-35A-BLM-TPN...
  • Page 7: Interface Description

    Green(0-7) Green data 21-28 Blue(0-7) Blue data Ground DCLK Dot-clock signal DISP Display on/off HSYNC Horizontal sync input. VSYNC Vertical sync input Data enable Clock pin of serial interface Data input pin in serial mode XR(NC) YD(NC) XL(NC) YU(NC) MOP-TFT320240-35A-BLM-TPN...
  • Page 8: Ac Characteristics

    DOTCLK High Period tCKH Data Setup Time Data Hold Time Reset pulse width tRES μS *Note: External clock source must be provided to DOTCLK pin of HX8238-D. The driver will not operate if absent of the clocking signal. MOP-TFT320240-35A-BLM-TPN...
  • Page 9: Data Timing

    1224 1350 tDOTCLK Vertical Back Porch tVBP Lines Vertical Front Porch tVFP Lines Vertical Data Start Point tVBP Lines Vertical Blanking Period tVBP + tVFP Lines NTSC Vertical Display VDISP 280(PALM=0) Lines Area 288(PALM=1) Vertical Cycle NTSC Vcycle Lines MOP-TFT320240-35A-BLM-TPN...
  • Page 10: Power Sequence

    - 1 line: 408 CLK tshut-on - 1 frame: 262 line 232.4 - DOTCLK = 6.5MHz *Note: it is necessary to input DOTCLK before the falling edge of SHUT. Display starts at 10th falling edge of VSTNC after the falling edge of SHUT MOP-TFT320240-35A-BLM-TPN...
  • Page 11: Power Down Sequence

    DOTCLK must be maintained at least 2 frames after the rising edge of SHUT. Display turns off at the 2nd falling edge of VSYNC after the falling edge of SHUT. If RESET signal is necessary for power down, provide it after the 2- frames-cycle of the SHUT period. MOP-TFT320240-35A-BLM-TPN...
  • Page 12: Inspection Criterion

    10 Inspection Criterion 10.1 Description This specification is made to be used as the standard acceptance/rejection criteria for the MOP-TFT320240-35A-BLM-TPN. 10.2 Sample plan Sampling plan according to GB/T2828.1-2003/ISO 2859-1: 1999 and ANSI/ASQC Z1.4-1993, normal level 2 and based on: Major defect: AQL 0.65 Minor defect: AQL 1.5...
  • Page 13: Lcd Pixel Defect

    1. If the fold mark and linear scar for polarizer is visible with operating condition, the defect is judged with line judge 2. If the fold mark and linear scar for polarizer is visible with non-operating condition, the defect is judged with the above judgment standard. MOP-TFT320240-35A-BLM-TPN...
  • Page 14: Handling Precautions

    If the display area is pushed hard during operation, some font may be abnormally drawn but the LCD will return to normal after it is reset.  Slight dew depositing on terminals can cause an electro-chemical reaction, damaging traces and resulting in an open circuit. Usage under the maximum operating temperature, 50%Rh or less is required MOP-TFT320240-35A-BLM-TPN...
  • Page 15: Storage Recommendations

    If any liquid leaked out of a damaged glass cell, and comes in contact with your hands, please wash it off well with soap and water MOP-TFT320240-35A-BLM-TPN...
  • Page 16: Ordering

    Table 1: Parallel TFT Part Numbering Scheme TFT 320 12.2 Options Table 2: Parallel Part Options Designator Options Product Line MOP: Matrix Orbital Parallel Display Screen Type TFT: Graphic TFT Display Columns 320: Three Hundred Twenty Pixel Columns Display Rows 240: Two Hundred Forty Pixel Rows Display Size 35: 3.5”...
