TABLE OF CONTENTS
1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.1.1. Leakage Current Cold Check---------------------- 3
1.) --------------------------------------------------------- 3
2 Warning -------------------------------------------------------------- 4
to Electrostatically Sensitive (ES) Devices---------- 4
2.2. About lead free solder (PbF)---------------------------- 5
3 Service Navigation ----------------------------------------------- 6
3.1. Service Hint ------------------------------------------------- 6
4 Specifications ----------------------------------------------------- 7
5 Service Mode ------------------------------------------------------ 8
5.1. How to enter into Service Mode ----------------------- 8
5.1.1. Contents of adjustment mode --------------------- 8
5.1.2. How to exit---------------------------------------------- 8
5.2. SRV-TOOL -------------------------------------------------- 9
5.2.1. How to access ----------------------------------------- 9
5.2.2. Display of SOS History ------------------------------ 9
TH-L32E3A
Model No.
Chassis:
KM11
Destination:
AUSTRALIA
PAGE
5.2.3. POWER ON TIME/COUNT -------------------------9
5.2.4. Exit --------------------------------------------------------9
5.2.5. Self Check Mode ------------------------------------ 10
5.2.6. Hotel Mode Adjustment ---------------------------- 10
5.2.7. Hotel Mode-------------------------------------------- 10
6 Troubleshooting Guide --------------------------------------- 11
6.1. Check of the IIC bus lines------------------------------ 11
6.1.1. How to access --------------------------------------- 11
6.1.2. Exit ------------------------------------------------------ 11
6.1.3. Screen display --------------------------------------- 11
6.2. Power LED Blinking timing chart --------------------- 12
6.3. No Power--------------------------------------------------- 12
7 Disassembly and Assembly Instructions--------------- 13
7.1. AC Cord Dressing---------------------------------------- 13
7.3. Speaker and Bottom Bracket Installation ---------- 15
7.4. LCD Panel Fixing & Handling Method -------------- 16
7.5. LED Panel Installation --------------------------------- 17
7.6. Install and Screw PCB ---------------------------------- 18
ORDER NO. MTV1101013CE
© Panasonic Corporation 2011. Unauthorized
copying and distribution is a violation of law.
LCD TV
PAGE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic TH-L32E3A
Summary of Contents for Panasonic TH-L32E3A
-
Page 1: Table Of Contents
7.4. LCD Panel Fixing & Handling Method -------------- 16 5.2.1. How to access ----------------------------------------- 9 7.5. LED Panel Installation --------------------------------- 17 5.2.2. Display of SOS History ------------------------------ 9 7.6. Install and Screw PCB ---------------------------------- 18 © Panasonic Corporation 2011. Unauthorized copying and distribution is a violation of law. - Page 2 TH-L32E3A 7.7. Small Part Install, Screw and Sponge Sticking --- 19 12 Printed Circuit Board------------------------------------------ 70 7.8. Back Cover Installation --------------------------------- 20 12.1. A-BOARD-------------------------------------------------- 70 7.9. Stand Assembly & Accessories 12.2. KA-BOARD------------------------------------------------ 72 Assembly --------------------------------------------------- 21 12.3. LD-BOARD ------------------------------------------------ 73 8 Measurements and Adjustments -------------------------- 22 12.4.
-
Page 3: Safety Precautions
TH-L32E3A 1 Safety Precautions 1.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed. -
Page 4: Warning
TH-L32E3A 2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor [chip] components. -
Page 5: About Lead Free Solder (Pbf)
TH-L32E3A 2.2. About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). -
Page 6: Service Navigation
TH-L32E3A 3 Service Navigation 3.1. Service Hint Board Name Main Device Remarks A BOARD AVSW, TUN, OFDM, P-SLD2, EEP Repairable P BOARD Power Supply Repairable KA BOARD Remote, LED, Luminunce Sensor Repairable LD BOARD LED Driver Repairable TC BOARD FHD LVDS signal board... -
Page 7: Specifications
TH-L32E3A 4 Specifications Power Power Rating AC 220 - 240 V, 50 / 60 Hz 0.33 A Normal (Home) mode 44 W Standby Condition 0.2 W Display panel Aspect Ratio 16:9 Visible screen size 80 cm (diagonal) 698 mm (W) × 393 mm (H) 2,073,600 (1,920 (W) ×... -
Page 8: Service Mode
TH-L32E3A 5 Service Mode 5.1. How to enter into Service Mode While pressing [VOLUME ( - )] button of the main unit, press [INFO] button of the remote control three times within 2 seconds. Contents of adjustment mode 5.1.1. • Value is shown as a hexadecimal number. -
Page 9: Srv-Tool
TH-L32E3A 5.2. SRV-TOOL 5.2.1. How to access 1. Select [SRV-TOOL] in Service Mode. 2. Press [OK] button on the remote control. 5.2.2. Display of SOS History SOS History (Number of LED blinking ) indication. From left side; Last SOS, before Last, three occurrence before, 2nd occurrence after shipment, 1st occurrence after shipment. -
Page 10: Self Check Mode
TH-L32E3A 5.2.5. Self Check Mode 1. Press the ‘MENU’ button (on the remote control) and the ‘VOL DOWN’ button on the LCD panel. 2. Press ON/OFF button on the panel to Exit. 5.2.6. Hotel Mode Adjustment 1. Press the ‘VOLUME DOWN’ button on the TV panel and simultaneously press the AV button on the remote control 3 times to enter Hotel Mode. -
Page 11: Troubleshooting Guide
TH-L32E3A 6 Troubleshooting Guide Use the self-check function to test the unit. 1. Checking the IIC bus lines 2. Power LED Blinking timing 6.1. Check of the IIC bus lines 6.1.1. How to access Self-check indication only: Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control for more than 3 seconds. -
Page 12: Power Led Blinking Timing Chart
TH-L32E3A 6.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality occurs, the protection circuit will operate and reset the unit to stand by mode. During this time, the defective block can be identified by the number of blinking times of the Power LED on the front panel of the unit as follow:... -
Page 13: Disassembly And Assembly Instructions
TH-L32E3A 7 Disassembly and Assembly Instructions 7.1. AC Cord Dressing 1. Fix Re-Use band at bottom bracket. 2. Cover AC cord with protect sheet and dressing with re-use band. → → → (follow sequence 1... -
Page 14: Control Panel Assembly & Side Av Installation
TH-L32E3A 7.2. Control Panel Assembly & Side AV Installation Fix control panel button into control panel bracket. -
Page 15: Speaker And Bottom Bracket Installation
TH-L32E3A 7.3. Speaker and Bottom Bracket Installation 1. Fix SP Rubber Bush at SP unit (L & R). 2. Install SP unit L and SP unit R. 3. Install bottom bracket. -
Page 16: Lcd Panel Fixing & Handling Method
TH-L32E3A 7.4. LCD Panel Fixing & Handling Method 1. Place down the cabinet as shown below. 2. Fix LCD panel into the cabinet by taking below precautions. Other general precautions 1. Do not press panel surface to avoid blue spot on the panel display. -
Page 17: Led Panel Installation
TH-L32E3A 7.5. LED Panel Installation 1. Fix LED PANEL on CABINET. 2. Insert an A10-KA10 lead connector in KA-Print. 3. Put KA-Print on LED PANEL. 4. Fix LED PANEL assy with SCREW. -
Page 18: Install And Screw Pcb
TH-L32E3A 7.6. Install and Screw PCB 1. Install P-print on LCD panel. 2. Install A-print on LCD panel. 3. Install Metal Bracket PCB A on LCD panel. 4. Fix power button into P Print first before control panel. 5. Fix spacer in to P Print. -
Page 19: Small Part Install, Screw And Sponge Sticking
TH-L32E3A 7.7. Small Part Install, Screw and Sponge Sticking 1. Install Control Panel 2. Install side AV bracket. 3. Install Speaker Bracket (4). 4. Install Metal Bracket Bottom. 5. Screw Control Panel into board. 6. Screw Side AV bracket. 7. Screw Metal Bracket Bottom. -
Page 20: Back Cover Installation
TH-L32E3A 7.8. Back Cover Installation 1. Screw back cover. 2. Stick model name plate, rear av indication sheet at back cover. 3. Fix adjustment sheet at back cover. 4. Stick serial no label at back cover. -
Page 21: Stand Mtg Assembly & Accessories Assembly
TH-L32E3A 7.9. Stand MTG Assembly & Accessories Assembly 1. Wrapping stand mounting with plastic bag (Make by supplier). 2. Stick yellow tape. Put all screw inside plastic bag. -
Page 22: Measurements And Adjustments
TH-L32E3A 8 Measurements and Adjustments 8.1. Voltage chart of A-board Set A-Board to a dummy set and check the satisfaction with the specified voltage as following table. POWER SUPPLY NAME MEASUREMENT POINT SPECIFICATION SUB1.8V TP8700 1.74 - 1.90 V SUB1.2V TP8100 1.18 - 1.32 V... -
Page 23: Block Diagram
TH-L32E3A 9 Block Diagram 9.1. Main Block Diagram... -
Page 24: Wiring Connection Diagram
TH-L32E3A 10 Wiring Connection Diagram 10.1. Wire Dressing 1. Connect all wire connector to connector. 2. Dressing wire follow diagram. Clamper Wire No.1 A09 - P2 No.2 Panel - LD2 No.3 P4 - LD4 No.4 A10 - KA10 No.5 A11 - SP (L) -
Page 25: Schematic Diagram
TH-L32E3A 11 Schematic Diagram 11.1. Schematic Diagram Notes... -
Page 26: A Board
TH-L32E3A 11.2. A Board 11.2.1. A Board - Sheet : 002 (1 / 2) <1A> <2A> <3A>... -
Page 27: A Board - Sheet : 002 (2 / 2)
TH-L32E3A 11.2.2. A Board - Sheet : 002 (2 / 2) <1A> <2A> <3A>... -
Page 28: A Board - Sheet : 003 (1 / 5)
TH-L32E3A 11.2.3. A Board - Sheet : 003 (1 / 5) <1A> <2A>... -
Page 29: A Board - Sheet : 003 (2 / 5)
TH-L32E3A 11.2.4. A Board - Sheet : 003 (2 / 5) <1A> <1B> <2B> <2A>... -
Page 30: A Board - Sheet : 003 (3 / 5)
TH-L32E3A 11.2.5. A Board - Sheet : 003 (3 / 5) <1B> <1C> <2B> <2C>... -
Page 31: A Board - Sheet : 003 (4 / 5)
TH-L32E3A 11.2.6. A Board - Sheet : 003 (4 / 5) <1C> <1D> <2D> <2C>... -
Page 32: A Board - Sheet : 003 (5 / 5)
TH-L32E3A 11.2.7. A Board - Sheet : 003 (5 / 5) <1D> <2D>... -
Page 33: A Board - Sheet : 004 (1 / 2)
TH-L32E3A 11.2.8. A Board - Sheet : 004 (1 / 2) <1A> <2A>... -
Page 34: A Board - Sheet : 004 (2 / 2)
TH-L32E3A 11.2.9. A Board - Sheet : 004 (2 / 2) <1A> <2A>... -
Page 35: A Board - Sheet : 005 (1 / 2)
TH-L32E3A 11.2.10. A Board - Sheet : 005 (1 / 2) <1A> <2A>... -
Page 36: A Board - Sheet : 005 (2 / 2)
TH-L32E3A 11.2.11. A Board - Sheet : 005 (2 / 2) <1A> <2A>... -
Page 37: A Board - Sheet : 008 (1 / 1)
TH-L32E3A 11.2.12. A Board - Sheet : 008 (1 / 1) -
Page 38: A Board - Sheet : 009 (1 / 3)
TH-L32E3A 11.2.13. A Board - Sheet : 009 (1 / 3) <1A> <2A> <3A> <4A>... -
Page 39: A Board - Sheet : 009 (2 / 3)
TH-L32E3A 11.2.14. A Board - Sheet : 009 (2 / 3) <1A> <2A> <3A> <1B> <2B> <4A>... -
Page 40: A Board - Sheet : 009 (3 / 3)
TH-L32E3A 11.2.15. A Board - Sheet : 009 (3 / 3) <1B> <2B>... -
Page 41: A Board - Sheet : 010 (1 / 1)
TH-L32E3A 11.2.16. A Board - Sheet : 010 (1 / 1) -
Page 42: A Board - Sheet : 100 (1 / 2)
TH-L32E3A 11.2.17. A Board - Sheet : 100 (1 / 2) <1A> <2A> <3A>... -
Page 43: A Board - Sheet : 100 (2 / 2)
TH-L32E3A 11.2.18. A Board - Sheet : 100 (2 / 2) <1A> <2A> <3A>... -
Page 44: A Board - Sheet : 101 (1 / 3)
TH-L32E3A 11.2.19. A Board - Sheet : 101 (1 / 3) <1A> <2A>... -
Page 45: A Board - Sheet : 101 (2 / 3)
TH-L32E3A 11.2.20. A Board - Sheet : 101 (2 / 3) <1A> <2A> <1B> <2B>... -
Page 46: A Board - Sheet : 101 (3 / 3)
TH-L32E3A 11.2.21. A Board - Sheet : 101 (3 / 3) <1B> <2B>... -
Page 47: A Board - Sheet : 300 (1 / 1)
TH-L32E3A 11.2.22. A Board - Sheet : 300 (1 / 1) -
Page 48: A Board - Sheet : 301 (1 / 3)
TH-L32E3A 11.2.23. A Board - Sheet : 301 (1 / 3) <1A> <2A>... -
Page 49: A Board - Sheet : 301 (2 / 3)
TH-L32E3A 11.2.24. A Board - Sheet : 301 (2 / 3) <1A> <1B> <2B> <3B> <2A>... -
Page 50: A Board - Sheet : 301 (3 / 3)
TH-L32E3A 11.2.25. A Board - Sheet : 301 (3 / 3) <1B> <2B> <3B>... -
Page 51: A Board - Sheet : 302 (1 / 2)
TH-L32E3A 11.2.26. A Board - Sheet : 302 (1 / 2) <1A> <2A> <3A> <4A>... -
Page 52: A Board - Sheet : 302 (2 / 2)
TH-L32E3A 11.2.27. A Board - Sheet : 302 (2 / 2) <1A> <2A> <3A> <4A>... -
Page 53: A Board - Sheet : 700 (1 / 2)
TH-L32E3A 11.2.28. A Board - Sheet : 700 (1 / 2) <1A> <2A> <3A> <4A>... -
Page 54: A Board - Sheet : 700 (2 / 2)
TH-L32E3A 11.2.29. A Board - Sheet : 700 (2 / 2) <1A> <2A> <3A> <4A>... -
Page 55: A Board - Sheet : 701 (1 / 2)
TH-L32E3A 11.2.30. A Board - Sheet : 701 (1 / 2) <1A> <2A> <3A>... -
Page 56: A Board - Sheet : 701 (2 / 2)
TH-L32E3A 11.2.31. A Board - Sheet : 701 (2 / 2) <1A> <2A> <3A>... -
Page 57: A Board - Sheet : 702 (1 / 2)
TH-L32E3A 11.2.32. A Board - Sheet : 702 (1 / 2) <1A> <2A> <3A>... -
Page 58: A Board - Sheet : 702 (2 / 2)
TH-L32E3A 11.2.33. A Board - Sheet : 702 (2 / 2) <1A> <2A> <3A>... -
Page 59: A Board - Sheet : 703 (1 / 1)
TH-L32E3A 11.2.34. A Board - Sheet : 703 (1 / 1) -
Page 60: A Board - Sheet : 704 (1 / 1)
TH-L32E3A 11.2.35. A Board - Sheet : 704 (1 / 1) -
Page 61: A Board - Sheet : 708 (1 / 1)
TH-L32E3A 11.2.36. A Board - Sheet : 708 (1 / 1) -
Page 62: Ka Board
TH-L32E3A 11.3. KA Board... -
Page 63: Ld Board
TH-L32E3A 11.4. LD Board 11.4.1. LD Board (1 / 2) <1A> <2A> <3A>... -
Page 64: Ld Board (2 / 2)
TH-L32E3A 11.4.2. LD Board (2 / 2) <1A> <2A> <3A>... -
Page 65: P Board
TH-L32E3A 11.5. P Board 11.5.1. P Board (1 / 3) <1A> <2A> <3A> <4A>... -
Page 66: P Board (2 / 3)
TH-L32E3A 11.5.2. P Board (2 / 3) <1A> <1B> <2A> <2B> <3A> <3B> <4A>... -
Page 67: P Board (3 / 3)
TH-L32E3A 11.5.3. P Board (3 / 3) <1B> <2B> <3B>... -
Page 68: Tc Board
TH-L32E3A 11.6. TC Board 11.6.1. TC Board (1 / 2) <1A> <2A> <3A> <4A>... -
Page 69: Tc Board (2 / 2)
TH-L32E3A 11.6.2. TC Board (2 / 2) <1A> <2A> <3A> <4A>... -
Page 70: Printed Circuit Board
TH-L32E3A 12 Printed Circuit Board 12.1. A-BOARD A-BOARD (TOP COMPONENT SIDE) TNP4G490 R 4 1 3 8 J S 0 0 3 0 J S 0 0 2 9 J S 0 0 0 7 J S 0 0 0 6... - Page 71 TH-L32E3A A-BOARD (BOTTOM COMPONENT SIDE) TNP4G490 R 2 0 1 6 Q 2 0 0 2 C 4 9 3 3 R 4 9 1 8 Q 4 1 2 0 Q 4 1 2 1 C 4 9 0 6...
-
Page 72: Ka-Board
TH-L32E3A 12.2. KA-BOARD KA-BOARD (TOP COMPONENT SIDE) TNPA5378 R M 2 8 0 0 A A A C KA10 A B A D C2801 R2825 R2827 R2826 R2828 C2802 R2817 R2800 S U F F I X . RM2800A RM2800... -
Page 73: Ld-Board
TH-L32E3A 12.3. LD-BOARD LD-BOARD (TOP COMPONENT SIDE) TNPA5377 L D 2 C9524 C9523 L9503 Q 9 5 0 5 Q 9 5 0 0 Q 9 5 0 4 S U F F I X . L D 4 Q 9 5 0 1... - Page 74 TH-L32E3A LD-BOARD (BOTTOM COMPONENT SIDE) TNPA5377 T P 9 5 0 4 T P 9 5 2 1 TP9504 T P 9 5 2 0 TP9505 TP9519 TP9518 TP9509 TP9508 TP9525 T P 9 5 0 1 TP9501 C9517 T P 9 5 0 0...
-
Page 75: P-Board
TH-L32E3A 12.4. P-BOARD P-BOARD (TOP COMPONENT SIDE) TNPA5364 Parts Location Ref.No Location Ref.No Location IC7301 D7102 D7103 D7203 D7204 D7205 D7302 D7303 D7332 D7333 D7501 D7502... - Page 76 TH-L32E3A P-BOARD (BOTTOM COMPONENT SIDE) TNPA5364 Parts Location Ref.No Location Ref.No Location Ref.No Location Ref.No Location IC7201 D7101 D7326 D7341 D7327 D7342 IC7301 D7102 IC7502 D7103 D7328 D7343 D7329 D7402 IC7601 D7201 D7202 D7330 D7403 D7203 D7331 D7404 D7332 D7501...
-
Page 77: Tc-Board
TH-L32E3A 12.5. TC-BOARD TC-BOARD (TOP COMPONENT SIDE) TNPA5391 C9107 C9105 T C 1 C9111 C9110 T C 2 C9108 C9106 C9112 C9109 R9101 R9102 R9103 R9104 R9105 R9106 R9107 R9108 TNPA5391 1 TC C9113 C9114 S U F F I X . -
Page 78: Exploded View And Replacement Parts List
TH-L32E3A 13 Exploded View and Replacement Parts List 13.1. Exploded View and Mechanical Replacement Parts List Please click the radio button for ‘Diagrams ll/Parts List’ on the menu bar. 13.2. Electrical Replacement Parts List 13.2.1. Replacement Parts List Notes... -
Page 79: Electrical Replacement Parts List
TH-L32E3A 13.2.2. Electrical Replacement Parts List Note: All part will be supplied by PAVCKM. Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks C4121 F1H1H104A970 C 0.1UF , 16V C4122 F1G1C104A077 C 0.1UF , 16V... - Page 80 TH-L32E3A Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks C4812 F1G1A105A047 C 1UF , 10V C7209 F1J1H104A717 C 0.1UF , 50V C4813 F1G1A105A047 C 1UF , 10V C7213 F1A3A471A060 C 470PF , 1kV...
- Page 81 TH-L32E3A Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks C8102 F1J1A475A087 C 4.7UF , 10V C8711 F1G1C223A081 C 0.022UF , 16V C8104 F1H1C105A145 C 1UF , 16V C8712 F1G1E272A123 C 2700PF , 25V C8106 F1G1C223A081 C 0.022UF , 16V...
- Page 82 TH-L32E3A Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks D5180 DZ2J033M0L DIODE COILS D5480 B0JCCE000008 DIODE L2001 J0JYC0000065 COIL D7101 ERZV10V621C2 VARISTOR L2310 J0JHC0000078 BEAD CORE L2311 J0JHC0000078 BEAD CORE...
- Page 83 TH-L32E3A Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks L8700 G1C4R7MA0416 INDUCTOR R0929 D0GA220JA023 C 22OHM ,J, 1/16W L8701 G1C4R7MA0416 INDUCTOR R0930 D0GA220JA023 C 22OHM ,J, 1/16W L9500 G1C470MA0490 INDUCTOR...
- Page 84 TH-L32E3A Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks R3061 D0GA333JA023 C 33KOHM ,J, 1/16W R4148 D0GAR00Z0001 C 0OHM ,J, 1/16W R3062 D0GA333JA023 C 33KOHM ,J, 1/16W R4150 D0GD391JA052 C 390OHM ,J, 1/16W...
- Page 85 TH-L32E3A Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks R4979 D0GA472JA023 C 4.7KOHM ,J, 1/16W R7365 D0GD103JA052 C 10KOHM ,J, 1/8W R4984 D0GA473JA023 C 47KOHM ,J, 1/16W R7367 D0GD152JA052 C 1.5KOHM ,J, 1/8W...
- Page 86 TH-L32E3A Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks R8301 D0GA681JA023 680OHM ,J, 1/16W R8918 D0GA680JA023 C 68OHM ,J, 1/16W R8302 D0GA360JA023 C 36OHM ,J, 1/16W R8919 D0GA680JA023 C 68OHM ,J, 1/16W...
- Page 87 TH-L32E3A Safety Ref. Part No. Part Name & Description Remarks FL4002 EXC28CE201U CHOKE COIL FL4003 EXC28CE201U CHOKE COIL FL4004 EXC28CE201U CHOKE COIL FL4005 EXC28CE201U CHOKE COIL FL4006 EXC28CE201U CHOKE COIL FL4007 EXC28CE201U CHOKE COIL JK1000 K1FY119D0015 CONNECTOR JK1001 K1FY119D0015 CONNECTOR...
- Page 88 Model No. : TH-L32E3A Parts Location...
- Page 89 Model No. : TH-L32E3A Packing Exploded View...
- Page 90 Model No. : TH-L32E3A Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks K2CJ2YY00038 AC POWER CORD L0AA16C00010 SPEAKER N2QAYB000604 REMOTE TRANSMITTER TBL5ZX0111 PEDESTAL ASSY TBL5ZX0187 STAND MOUNTING ASSY TBM4GC631-1 MODEL NAME PLATE TBX4GA02101 POWER BUTTON TBX4GA02701...
