Summary of Contents for NuVision TM101W638L

  • Page 1 TM101W635L User’s Guide...

  • Page 2: Customer Service

    Customer Service NuVision Customer Service www.nuvision.com/assistance Phone: (800) 890-1288 Hours: 8:30am to 5:30pm PST M-F Email: cs@nuvision.com Register your tablet today at www.nuvision.com...
  • Page 3 Introduction Thank you for purchasing the NuVision Duo 10. The 10.1” NuVision DUO 10 is our most versatile 2-in-1 tablet/laptop yet. The superior and reliable performance of the DUO 10 starts with a certification process that requires higher end components during the manufacturing process resulting in a cleaner, faster and more secure Windows experience.

  • Page 4: Features & Package Contents

    Features & Package Contents Tablet AC Adapter (Connects to USB Type-C) Keyboard...

  • Page 5: Important Safety Instructions

    10. Static discharge is normal and can occur in an electronic device. Although not life threatening, it may corrupt files or damage memory and its content. Do not use accessories that are not from Nuvision. Dismantling the tablet will void the manufacturer’s warranty. If you are experiencing problems, review this quick start guide or visit the FAQ online at www.nuvision.com.
  • Page 6 Tablet Overview...
  • Page 7 Camera: Built in 2.0MP front camera to take HD photos or videos. Window: Press to return to Home/Start Menu. Microphone: Built in microphones. Use to speak to Cortana or for making personal recordings. Camera: Built in 5.0MP rear camera to take HD photos or videos. Power / Standby: Press and hold for 3 seconds to turn on the tablet.
  • Page 8 Keyboard Overview...
  • Page 9 Mouse Pad Lock: Press to temporarily disable the Mouse Pad (indicator light above the Mouse Pad Lock icon will glow RED). Press again to re-enable. 13. Full Size USB 2.0 Port (Left side of keyboard) 14. Mouse Pad Lock / CAPS Light Indicator 15.
  • Page 10 Connecting the Tablet and Keyboard Your tablet features a specially designed magnetic hinge that attaches and secures the tablet and keyboard together, enabling quick and easy docking. 1. Dock Port Connect the 5-pin magnetic dock port to support the keyboard and USB functions. 2.
  • Page 11 Undocking the Tablet Firmly grasp the tablet and secure the keyboard at the same time, then gently pull out the tablet.

  • Page 12: Charging The Battery

    Charging the Battery Connect the power adapter to a wall outlet, then to the tablet’s USB Type-C port as shown. It is recommended to fully charge the battery before first use. A battery status indicator appears in the lower right corner of the Task Bar. Tap to view the current battery level, time remaining, brightness control, and settings for power and sleep modes.
  • Page 13 Battery Care Operating temperature: Your device is designed to function between 32°F and 95°F (or 0°C to 35°C). Lithium-ion batteries are sensitive to higher temperatures so keep away from direct sun light. Don’t leave in a closed environment susceptible to extreme temperatures (ie: a vehicle on a hot sunny day).
  • Page 14 Starting your Tablet Power On/Off/Standby Mode/Reset Press and hold the side POWER button on the side for a couple of seconds until the logo screen appears, then release. : Press and hold the side POWER button on the side of the tablet. When prompted, slide finger downward to shut down your PC.
  • Page 15 Fingerprint ID / Lock Screen and Password The Lock Screen is the starting point when the tablet is turned ON. Swipe your finger upward from the bottom of the display to exit the Lock Screen, then enter your Password. To use Fingerprint ID, first go to Settings/Accounts and select ‘Sign-in options’.
  • Page 16 Start Menu / Tablet Task Bar Overview 10 11 13 14...
  • Page 17 The Start Menu screen consists of colorful static and live tiles that provide quick access to built-in apps, mail, entertainment, and the latest in news, weather, and sports. You can reposition tiles to other areas of the screen, resize them, or pin them to the Desktop Task Bar.

  • Page 18: Common Finger Gestures

    Common Finger Gestures Swipe from the edges: Swipe right from the left edge to access open apps. Swipe left from the right edge to open the Action Center. Pinch to Zoom in/out: Some apps (such as Maps, Browser, and Gallery) allow you to zoom in and out by placing two fingers on the screen at once.
  • Page 19 Swipe downward from the top edge to reduce the size of an active window. Move it to one area then open a second app to view both windows side by side. Swipe finger side to side and up and down to move images.
  • Page 20 Apps Menu To display the convenient and easy to use Apps menu, tap or click the All Apps button in the Start Menu. Slide your finger or scroll up and down to view all apps on your tablet. Add / Remove / Resize Apps You can reconfigure the tiles within the Start Menu quite easily.
  • Page 21 Action Center / Windows Ink Workspace The Action Center is the central The Windows Ink Workspace is your one-stop location to view alerts, notifications, shop for everything you do with your pen. user settings, and more. Swipe your Select the pen icon to open the workspace.
  • Page 22 Cortana Speak to Cortana and request the weather forecast, set personal reminders, send an email, find specific files, search the web, and more. Tap the “O” icon in the Task Bar to bring up Cortana. Tap the microphone and ask her anything! To manage and personalize Cortana, go to the Cortana app, press “Settings”...
  • Page 23 Connect to HDMI / Movies & TV / Additional Storage Connect to HDTV or Projector Connect your tablet to an HD television or projector with an optional micro-HDMI to full-size HDMI cable. Once connected, view on the external display immediately. Movies &...
  • Page 24 Creating a Microsoft Account / Adding an Email Account Create a Microsoft account It is recommended to set up or use an existing Microsoft account for better enjoyment of Microsoft services such as Xbox, Hotmail, Outlook.com, OneDrive, etc. Many apps and services rely on the account to sync content and settings across devices.

  • Page 25: Connecting To The Internet

    Connecting to the Internet The tablet utilizes WiFi 802.11b/g/n/ac networks to connect with the internet. In order to connect, you will need the following: WI-FI Network Name/SSID Available Password Here Wireless Router Connect to a WiFi Network Open the Action Center (swipe your finger inward from the right edge of the screen), then tap or click All Settings >...
  • Page 26 Connecting Bluetooth Devices Add a Bluetooth device Add or “pair” a Bluetooth compatible device with your Tablet as follows: Power on the compatible Bluetooth device and make it discoverable. From the Action Center open All Settings > Devices > Bluetooth. Turn Bluetooth to On and wait momentarily while Windows searches available devices.

  • Page 27: Using The Cameras

    Using the Cameras Front and Rear Cameras Your tablet features two cameras. With the front-facing 2MP camera you can video chat and take “selfies”. Use the 5MP rear camera to take photos or record videos. Open the Camera app and tap on the Camera or Video shutter buttons. To record video, tap the Video shutter button once to start a recording;...
  • Page 28 Using the Cameras (Cont.) Photo Mode Video Mode Panoramic Mode...
  • Page 29 Camera Function Guide View photos on the tablet: View and edit photos on the tablet. Camera Adjustments Menu: Switch Cameras and Adjust White Balance, Focus, ISO, Brightness and Shutter Speed. Make fine-tune adjustements with the slider on the right of the screen when selection is made. Camera Settings: Activate timer, or select photo and video recording settings.

  • Page 30: Compliance Information

    The following statement applies to all products that have received FCC approval. Applicable products wear the FCC logo, and /or an FCC ID in the format FCC ID:2AHYK-TM101W638L on the product label. This mobile device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This mobile device may not cause harmful interference, and this mobile device must accept any interference received, including interference that may cause undesired operation.

  • Page 31: Limited Warranty

    TO OBTAIN WARRANTY SERVICE Should it be necessary to contact Customer Support, call (800) 890-1288 or email at cs@nuvision.com. You will be instructed on how your claim will be processed. Have pertinent information available including proof of purchase and an understanding of the issue.
  • Page 32 SAR： The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential for human contact is minimized during normal operation. The exposure standard for wireless devices employs a unit of measurement known as the Specific Absorption Rate, or SAR.
