- Page 1 TANK Assembly Guide VERSION: XTTM1-RPH-101 PART #: 5706201-A...
- Page 2 TOOLS NEEDED FOR ASSEMBLY: • 10MM ALLEN WRENCH (INCLUDED) • 6MM ALLEN WRENCH (INCLUDED) TABLE OF CONTENTS: • TANK ASSEMBLY: PAGES 3 - 5 • TANK STORAGE (OPTIONAL): 6 - 8 • ADJUSTMENTS: 9 - 10 • INSPECTION & LUBRICATION: PAGE 11...
- Page 3 STEP 1 NOTE: LOOSELY tighten bolt connections in this step.
- Page 4 STEP 2 NOTE: BEFORE ASSEMBLING TIRES, CHECK TIRE PRESSURE. MAKE SURE TIRES ARE INFLATED TO 30 PSI NOTE: AFTER TIRES HAVE BEEN SECURELY ASSEMBLED, SECURELY TIGHTEN THESE BOLTS. NOTE: SECURELY tighten all bolt connections in this step and previous step.
- Page 5 STEP 3 NOTE ALIGN THE "R" LABEL ON THE RIGHT HANDLE WITH THE "R: LABEL ON THE REAR FRAME NOTE: ALIGN THE PIN IN THE PUSH HANDLES WITH THE SLOT IN THE RECEIVER TUBE NOTE ALIGN THE "L" LABEL ON THE LEFT HANDLE WITH THE "L: LABEL ON THE REAR FRAME...
- Page 6 XTWMH WALL MOUNT HANGER (OPTIONAL) WARNING: THE UPPER MOUNT MUST BE ANCHORED TO THE WALL USING FOUR WALL ANCHORS SUITABLE FOR THAT PARTICULAR WALL CONSTRUCTION. 1-3/4" 35" 1-3/4" 6" (MIN) FLOOR NOTES: The images above show the anchoring hardware used for attaching WARNING: THE LOWER MOUNT MUST BE ANCHORED TO THE WALL to typical walls with wood studs spaced 16"...
- Page 7 XTWMH WALL MOUNT HANGER (OPTIONAL) NOTE: THE FRONT TIRE WILL REST ON THIS SURFACE WHEN STORED...
- Page 8 XTWMH WALL MOUNT HANGER (OPTIONAL) NOTE: ALIGN THE PIN IN THE PUSH HANDLES WITH THE SLOT IN THE RECEIVER TUBE (2X)
- Page 9 XTTM1 TOW BAR ADJUSTMENT NOTE: THE TOW BAR MUST BE ADJUSTED FORWARD TO ADD WEIGHT PLATES TOW BAR TO THE WEIGHT HORN ATTACH TOW STRAP HERE PULL SPRING PIN AND ROTATE TOW BAR FORWARD UNTIL IT ENGAGES FRONT HOLE...
- Page 10 XTTM1 RESISTANCE ADJUSTMENT PULL BACK ADJUSTER TO INCREASE RESISTANCE POSITION N: NEUTRAL POSITION 1: LOW RESISTANCE POSITION 2: MEDIUM RESISTANCE POSITION 3: HARD RESISTANCE...
- Page 11 RECOMMENDED LUBRICATION: Use a Dry lubrication for indoor use, and wet lubrication for outdoor use. Most bicycle shops carry a variety of different lubricants and can recommend a lubricant based on the conditions where the TANK will be used. BOTTOM VIEW...
