easyTymp® Operating Manual
Specification of Input / Output Connections
Outputs: Outputs:
Outputs: Outputs:
Transducer Proprietary
12-pole
USB USB type "B"
Calibration Properties
Calibrated Calibrated Calibrated Calibrated Probe System:
Transducers: Transducers:
Transducers: Transducers:
Accuracy Accuracy General:
Accuracy Accuracy
Reflex Frequencies:
Ipsilateral Reflex Tone Levels:
Compliance Measurement:
Pin 1: CH1 out
Pin 2: CH1 GND
Pin 3: DGND
Pin 4: GND A / GND Microphone
Pin 5: Microphone – input / Analog Balanced in
Pin 6: Microphone + input / Analog Balanced in
Pin 7: Power Supply +3/+5 V
Pin 8: CH2 Out
Pin 9: CH2 GND
Pin 10: I2C CLK
Pin 11: I2C DATA
Pin 12: I2C Interrupt
USB port for
Communication
Ipsilateral Earphone: is integrated in the
probe system
Probe frequency transmitter and receiver and
pressure transducer is integrated in the probe
system
Generally the instrument is made and
calibrated to be within and better than the
tolerances required in the specific standard
±3%
±5% or ±10 daPa, whichever is greater
±5% or ±0.1ml, whichever is greater
