UHS Battery Burnisher
Subtitle
Title
PE300BU
All manuals and user guides at all-guides.com
We help you shine.™
Grou p
A company of the

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pioneer Eclipse PE300BU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Amano Pioneer Eclipse PE300BU

Summary of Contents for Amano Pioneer Eclipse PE300BU

  • Page 1 All manuals and user guides at all-guides.com Grou p A company of the UHS Battery Burnisher Subtitle Title PE300BU We help you shine.™...
  • Page 2 All manuals and user guides at all-guides.com  ...
  • Page 3 Contact Amano Pioneer Eclipse Customer Service at 1-800-367-3550 or +1-336-372-8080 or an authorized Amano Pioneer Eclipse Distributor to inquire about training or to request a replacement manual.
  • Page 4 All manuals and user guides at all-guides.com FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. Record This Important Information Date of Purchase Purchased From Address City State...

  • Page 5: Table Of Contents

    All manuals and user guides at all-guides.com Contents Stopping and Turning Off Machine.......13 Installing/Changing Burnishing Pad.....13 Machine Specifications.............4 Dust Bag Removal.............14 Routine Maintenance Parts............5 Pad Pressure Adjustment..........14 Safety Precautions...............6 Storage.................14 Operator Responsibility..........7 Operation on Inclines..........14 Operator-Ear Sound Pressure Level......7 Post-Operation Check List...........14 Hand-Arm Vibration............7 Lubrication of Rear Casters.........14 Machine Preparation..............8...
  • Page 6 All manuals and user guides at all-guides.com...

  • Page 7: Machine Specifications

    All manuals and user guides at all-guides.com Machine Specifications LENGTH: VOLTAGE: ......36 VDC (3 - 12 VDC Batteries) 20 in (Head Up).........49 in (124cm) (Head Down)........58 in (147cm) BATTERIES:.......12 VDC Lead Acid 228 Ah 12 VDC AGM 235 Ah 24 in (Head Up).........49 in (124cm) (Head Down)........61 in (155cm) BURNISH RATE: 20 in........

  • Page 8: Routine Maintenance Parts

    All manuals and user guides at all-guides.com Routine Maintenance Parts  Pads: 300BU20 300BU24 20" Blue Blend: PD3LBB20 24" Blue Blend: PD3LBB24 20" Natural Poly-Blend: PD3LNP20 24" Natural Poly-Blend: PD3LNP24 20" White Lightning: PD3LWL20 24" White Lightning: PD3LWL24 300BU30X 16" Blue Blend: PD3LBB16X 16"...

  • Page 9: Safety Precautions

    Do not make unauthorized modifications or alterations to this machine. Amano Pioneer Eclipse assumes no liabilities for injury or damage resulting from an unauthorized modification or alteration to the machine.

  • Page 10: Operator Responsibility

    Keep your machine regularly maintained by following the Surface of Hand-Guided Machinery maintenance information in this manual. We recommend taking advantage of a service contract from your Amano Pioneer Eclipse Authorized Distributor or Service Center. Amano Pioneer Eclipse measures and rates the...

  • Page 11: Machine Preparation

    All manuals and user guides at all-guides.com Machine Preparation Installing Steel Skirt 1. Lift the deck upward about 90 degrees by pulling up Unpacking the Machine on the front of the deck. At this point, the tilt latch will hold the deck in the pad change position. (Ref. 1.

  • Page 12: Machine Operation

    All manuals and user guides at all-guides.com Machine Operation Controls and Instruments Traction Non-Traction...

  • Page 13: 300Bu Traction Model

    All manuals and user guides at all-guides.com Controls and Instruments 3. Burnish Switch - Turns burnish function on/off. The burnish motor will not engage unless the burnish 300BU Traction Model switch is on and the handle lever is engaged. If the burnish head is tilted up into the pad change position, 1.
  • Page 14 2. Peel back the corner of the display label. 3. Set the DIP switches, according to your battery pack, as shown below. If your battery pack type is not listed please call Amano Pioneer Eclipse @ +1336-372-8080 for correct setting.

  • Page 15: Battery Charger Fault Codes

    All manuals and user guides at all-guides.com Battery Charger Fault Codes Fault Description Remedy Check that the plug is connected to an No display on the charger, no LED indicators. operating wall outlet. Check fuse. 20A fuse Display MP265100. Incorrect battery connection or no battery Check the connection and the polarity of the ...

  • Page 16: How The Machine Works

    All manuals and user guides at all-guides.com How the Machine Works Stopping and Turning Off Machine The Burnish components of the machine are: To stop the machine, release the handle levers and the machine will smoothly break to a stop and after 3 seconds Burnish pad holder the burnish motor will stop.

  • Page 17: Dust Bag Removal

    All manuals and user guides at all-guides.com Dust Bag Removal Storage The machine has two dust bag options. A re-usable cloth 1. Machine should be stored in a dry environment. bag and a disposable paper bag. Monitor the dust bag carefully and empty/change as needed.

  • Page 18: Body Maintenance

    All manuals and user guides at all-guides.com Body Maintenance 6. Install the new belt using the belt diagram. The body may be cleaned with a damp cloth to remove dust and scuff marks. More stubborn scuff marks on the tank exterior can be removed with a vinyl cleaner. Battery Maintenance The batteries are deep cycle 12 volt batteries.

  • Page 19: Repacking The Machine

    Inspect Deck Drive Belt (30”)  Replace Drive Belt (30”) As Required *These items must be performed with the proper tools and training. Contact a Amano Pioneer Eclipse Factory Certified Technician unless you have the proper equipment and mechanical proficiency.

  • Page 20: Machine Troubleshooting

    All manuals and user guides at all-guides.com Machine Troubleshooting Problem Possible Cause Remedy Breaker Tripped Push breaker button to reset Check batteries are wired together correctly via the battery connection diagram, Incorrect battery connection check the Anderson connectors are plugged together Machine will not turn on On-board battery charger plugged in Unplug the charging cord from the machine...

  • Page 21: Alarm Codes

    All manuals and user guides at all-guides.com Alarm Codes (Traction Model Only) *Given the following alarm codes, troubleshooting should only be done by Amano Pioneer Eclipse Factory Certified Technician. A programming handset may be required for troubleshooting. Number of Description...

  • Page 22: Wiring Schematic (Non-Traction)

    All manuals and user guides at all-guides.com Electrical Schematic (Non-Traction) 052912...

  • Page 23: Wiring Schematic (Traction)

    All manuals and user guides at all-guides.com Electrical Schematic (Traction) 041713...

  • Page 24: Connections (Non-Traction)

    All manuals and user guides at all-guides.com Connections (Non-Traction) 080612...
  • Page 25 All manuals and user guides at all-guides.com Connections (Non-Traction) Continued 080612 Ref. Part # Description Qty. Ref. Part # Description Qty. MP426500 HARNESS, MAIN, PAD ASST. J2 SA027600 CHARGER, 220V, 36V, ASM. MP426700 HARNESS, CONT. PAN., PAD ASST. 1 MP279700 CABEL, BATT./ CONNECTOR MP426800 HARNESS, MOTOR, BURNISH...

  • Page 26: Connections (Traction)

    All manuals and user guides at all-guides.com Connections (Traction) 080612...
  • Page 27 All manuals and user guides at all-guides.com Connections (Traction) Continued 080612 Ref. Part # Description Qty. Ref. Part # Description Qty. MP432200 HARNESS, MAIN, TRACTION MP238200 CABLE, BATTERY, 13.5", MP432100 HARNESS, CONT. PAN., TRAC. MP279800 CABLE, BATT./ CONNECTOR MP426800 HARNESS, MOTOR, BURNISH N1 MP223500 BATTERY, 12V, LEAD ACID MP427000...

  • Page 28: Sub Assembly

    All manuals and user guides at all-guides.com Sub Assembly 041613...
  • Page 29 All manuals and user guides at all-guides.com Sub Assembly Continued Ref. Part # Description Qty. 1A MP425200 SKIRT, 20", ASM. (20") 1B MP434200 SKIRT, 24", ASM. (24") NB050600 BOLT, HEX, TAP, 1/4-20 x 2-1/2" NB3350 WASHER, FLAT, 1/4" MX1045 NUT, HEX, 1/4-20 5A MP139800 EDGING, SKIRT, (20") 6FT.

  • Page 30: Final Bottom Assembly (Non-Traction)

    All manuals and user guides at all-guides.com Final Bottom Assembly (Non-Traction) 080312...
  • Page 31 All manuals and user guides at all-guides.com Final Bottom Assembly (Non-Traction) Continued Ref. Part # Description Qty. 1A MP424400 BRACKET, AXLE / TRANS AXLE, ASM., (20") 1B MP440800 BRACKET, AXLE / TRANSAXLE, ASM. (24") MP432500 CASTER, 4", SWIVEL, w/ BRAKE NB9267 WASHER, FLAT, 5/16"...

  • Page 32: Final Bottom Assembly (Traction)

    All manuals and user guides at all-guides.com Final Bottom Assembly (Traction) 080312 052912...
  • Page 33 All manuals and user guides at all-guides.com Final Bottom Assembly (Traction) Continued Ref. Part # Description Qty. 1A MP424400 BRACKET, TRANSAXLE, ASM. (20") 1B MP440800 BRACKET, TRANSAXLE, ASM. (24" & 30") MP424500 TRANSAXLE, 36 VDC, ASM. PG001801 BRACKET, TRANSAXLE, PAINTED NB6545 SCREW, CAP, HH, 5/16"-18 X 1"...

  • Page 34: Final Rear Assembly

    All manuals and user guides at all-guides.com Final Rear Assembly 080312...
  • Page 35 All manuals and user guides at all-guides.com Final Rear Assembly Continued Ref. Part # Description Qty. MP422901 PLATE, MOUNT, SHOCK MP206000 BALL, STUD, 10MM NB3265 NUT, LOCK, 5/16”-18, NC 4A MP415200 SPRING, GAS, (20") 4B MP434500 SPRING, GAS, (24") 4C MP450300 SPRING, GAS, (30") NB9267 WASHER, FLAT, 5/16”...

  • Page 36: Final Top Assembly

    All manuals and user guides at all-guides.com Final Top Assembly 041913...
  • Page 37 All manuals and user guides at all-guides.com Final Top Assembly Continued Ref. Part # Description Qty. MP423201 LEVER, HANDLE, LEFT MP423202 LEVER, HANDLE, RIGHT NB6390 PIN, ROLL, 1/4 X 1 1/8 MP431401 PLATE, COVER, REAR, W/ SLOT NB9267 WASHER, FLAT, 5/16” NB61111 WASHER, LOCK, 5/16”...

  • Page 38: Final Front Assembly

    All manuals and user guides at all-guides.com Final Front Assembly 080312...
  • Page 39 All manuals and user guides at all-guides.com Final Front Assembly Continued Ref. Part # Description Qty. NB039704 PIN, CLEVIS, 1/2” X 4-1/2” NB025600 PIN, PRESTO, 3/32 X 1 5/8, SS MP423301 LATCH, TILT, SHROUD NB026200 SCREW, SHOULDER, 3/8” X 1/2” NB038600 SCREW, SHOULDER, 3/8 X 3-1/2 NB3265...

  • Page 40: 30" Shroud Assembly

    All manuals and user guides at all-guides.com 30" Shroud Assembly 041613...
  • Page 41 All manuals and user guides at all-guides.com 30" Shroud Assembly Continued Ref. Part # Description Qty. MP454000 SHROUD, 30", ASM. MP237100 BUSHING, FLANGED, 1/2 ID X 3/8 L MP318400 SWITCH, MICRO, 12V NB9625 SCREW, 4-40 X 3/4" NB007000 NUT, LOCK, NYLON, 4-40 MP409700 MOTOR, 2000 RPM, ASM.

  • Page 42: 30" Skirt, Pulley, & Tensioner

    All manuals and user guides at all-guides.com 30" Skirt, Pulley, & Tensioner 041613...
  • Page 43 All manuals and user guides at all-guides.com 30" Skirt, Pulley, & Tensioner Continued Ref. Part # Description Qty. MP447200 SKIRT, 30", ASM. NB050600 BOLT, HEX, TAP, 1/4-20 x 2-1/2" NB3350 WASHER, FLAT, 1/4" MX1045 NUT, HEX, 1/4-20 MP8300 VELCRO, HOOK, 1" 88"...
  • Page 44 All manuals and user guides at all-guides.com...
  • Page 45 All manuals and user guides at all-guides.com...

  • Page 46: Warranty

    FOR LOSS OF USER TIME OF THE AMANO PIONEER ECLIPSE CORPORATION MACHINE OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL 1) The obligation of Amano Pioneer Eclipse under this warranty is DAMAGE EXCEPT AS STATED IN THE WARRANTY APPLICABLE limited to repairing or replacing, at its option, any part which is TO EACH MACHINE.
  • Page 47 All manuals and user guides at all-guides.com...
  • Page 48 Sparta, North Carolina 28675  www.pioneer-eclipse.com +1-336-372-8080 1-800-367-3550 Fax 1-336-372-2913 EC Machinery Directive 2006/42/EC, EC Restriction of Hazardous Substances Directive (2011/65/EC) Harmonized Standards Applied: EN 121001, EN12100-2 LT063500 We help you shine.™ shine on. © 2013 Amano Pioneer Eclipse Corporation PE300BU_C...
