Frigidaire GLEB30T8C Factory Parts Catalog page 5

A = GLEB30T8C (GLEB30T8CSA)
B = GLEB30T8C (GLEB30T8CBA)
# = Functional Parts
* = Non-Illustrated Parts
UPPER OVEN
POS. NO PART NO
1 318066402
2 318102101
2A 318071705
6 318025308
6A 318219500
9 5303317977
10 5303317976
12 # 318089913
14 5308011085
15 5303013071
16 3201911
17 5304400195
37 # 316111203
41 5303310526
54 5303310514
58A 318133744
58B 318133769
59 318072506
62 # 5303310518
62* 5303323144
66 # 5303310513
67 # 5303310512
68 5304403015
70 5303300142
76 318056202
80 5303320846
81 318192400
82 318072301
83 318089616
86 5303310524
88 5303311222
89 # 318095934
89* 318120711
107 318219401
108# 318073012
109 5303311203
111 316136600
119# 318004900
125# 5303311202
127 5303310542
128 5303311163
129 5303311164
131 318102301
132 318101704
132A 318101705
177 318053800
185 318014700
222 318080000
263 316136500
264 318143815
* # 318078507
* 5303311207
* 08002868
* 5303211311
* 5303302745
* 5303311528
* 5303323139
GLEB30T8C
DESCRIPTION
A B Panel,main back
A B Shield,oven top
A B Shield,oven top
A B Rack,oven
A B Rack,broiler pan
A B Pan,broiler
A B Insert,broiler pan
A B Switch,light
A B Receptacle,oven light
A B Bulb/Lamp,oven light
A B Cover,oven light ,glass
A B Retainer,light cover
A B Sensor,oven temp probe
A B Cover,hinge cutout
A B Housing,oven light
A B Insulation,oven wrapper
A B Insulation,oven back
A B Tube,oven vent
A B Terminal Block
A B Nut,10-32
A B Element,broil ,2750 W
A B Element,bake ,3000 W
A B Support,element hanger
A B Shield,insulation
A B Front,oven
A B Plate,oven mtg
A B Spring,oven
A B Shield,oven bottom
A B Liner,oven complete
A B Receptacle,hinge
A B Rod,latch
A B Motor,latch assy ,w/brkt & switch
A B Switch
A B Cover,fan
A B Motor,blower
A B Blade,fan
A B Nut,fan retainer
A B Switch,thermal
A B Motor,convection
A B Adapter,vent tube ,with converter
A B Bushing
A B Spring
A B Cover,control housing
A B End,cover ,RH ,control housing
A B End,cover ,LH ,control housing
A B Gasket,vent
A B Spacer,oven shield
A B Plate,oven temp probe
A B Washer,fan motor
- B Shield,wire
A B Box & wires assy
A B Tube,protector
A B Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
A B Screw,8 x 0.500
A B Screw,10-16x1-1/8 ,square drive
A B Screw,oval hd sq dr ,6-20AB x 0.625 ,black
A B Screw,10-24 x 0.906
5
Publication No.
5995383857
01/03
