Carbon and Sulfur Analyzer CS-2000
Translation
© Eltra GmbH, 42781 Haan, Retsch-Allee 1-5, Germany | 12.05.2017 Version 0001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS-2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ELTRA CS-2000

Summary of Contents for ELTRA CS-2000

  • Page 1 Manual Carbon and Sulfur Analyzer CS-2000 Translation © Eltra GmbH, 42781 Haan, Retsch-Allee 1-5, Germany | 12.05.2017 Version 0001...
  • Page 2 Copyright © Copyright by Eltra GmbH Retsch-Allee 1-5 42781 Haan Germany...

  • Page 3: Table Of Contents

    Table of Contents Contact information ..........................6 Notes on the Manual ..........................6 Explanations of the Safety Instructions ..................... 7 General Safety Instructions ....................... 9 Explanation of signs and symbols ....................10 Packaging, Transport and Installation ....................11 Packaging ............................11 Transport............................
  • Page 4 Furnace tube cleaning ......................97 8.1.12 Tic-module ..........................98 Packing ............................100 Pre-installation guide ........................103 Approved methodologies to which Eltra instruments conform ........... 105 Inorganic materials (Metals) ......................105 Organic materials (Oil, Coal, foodstuffs) ..................106 Disposal .............................. 106 Index ..............................108...

  • Page 6: Contact Information

    Subject to technical changes. Copyright The forwarding or duplication of this documentation and the recycling and passing on of its content are only permitted with the explicit consent of Eltra GmbH. Any infringements of this constitute an obligation to pay damages.

  • Page 7: Explanations Of The Safety Instructions

    Notes on the Manual 2.1 Explanations of the Safety Instructions In this Operating Manual we give you the following safety warnings Mortal injury may result from not following these safety warnings. We give you the following warnings and corresponding content. DANGER Type of danger / personal injury Source of danger...
  • Page 8 Notes on the Manual • Instructions on how the dangers are to be avoided. We also use the following signal word in the text or in the instructions on action to be taken: NOTICE...

  • Page 9: General Safety Instructions

    Changes to the machine  Changes to the machine may lead to personal injury. • Do not make any change to the analyzer and use spare parts and accessories that have been approved by Eltra exclusively. N1.0074 NOTICE Changes to the machine Improper modifications ...

  • Page 10: Explanation Of Signs And Symbols

    Notes on the Manual 2.3 Explanation of signs and symbols Number Symbol Reference Meaning Danger, high voltage, electric shock IEC 60417-5041 Caution, hot surface General hazards – see documentation ISO 7000-0434B BGV A8 W27 Risk of crushing...

  • Page 11: Packaging, Transport And Installation

    Packaging, Transport and Installation Packaging, Transport and Installation 3.1 Packaging The packaging has been adapted to the mode of transport. It complies with the generally applicable packaging guidelines. 3.2 Transport N2.0075 NOTICE Transport  Mechanical or electronic components may be damaged. •...
  • Page 12 Packaging, Transport and Installation N3.0022 NOTICE Electrical connection Failure to heed the data on the type plate  Electronic and mechanical components may be damaged. • Only connect the device to a power supply system that is consistent with the data on the type plate. –...

  • Page 13: Type Plate Description

    Packaging, Transport and Installation 3.5 Type Plate Description N4.0022 NOTICE Electrical connection Failure to observe the values on the type plate  Electronic and mechanical components may be damaged. • Connect the device only to mains supply matching the values on the type plate.

  • Page 14: Installation

    Installation Installation 4.1 Setting check up CAUTION V0092 Device falling down Incorrect erection or inadequate working space – Due to its weight, the device can cause injuries if it falls down. • Only operate the device on a sufficiently large, strong, non-slip and stable working area.

  • Page 15: Front Panel Illustration

    Installation There are no special requirements for setting up the computer monitor and printer. They can be placed on a normal desk. Below is an example of installation: Fig. 2: Example of installation Although the analyzer’s operating environment does not necessarily need to be air conditioned, it is advisable to keep the room temperature between 18°C and 30°C.
  • Page 16 Installation Catalyst furnace Oxygen pressure gauge (norm. 1,5 bar) Infrared cell purge 10 l/h Regulator for infrared cell purge (3) Carrier gas flow O – trap Button for leakage test Mains power switch Dust filter Cover attachment knobs Furnace cover O –...

  • Page 17: Mains Power Connections

    Installation 4.3 Mains power connections NOTICE Installation of the machine – It must be possible to disconnet the machine from the mains at any time. • Install the machine such that the connection for the mains cable is easily accessible. W3.0023 WARNUNG High temperature / Burning of the skin...

  • Page 18: Data Interface

    Installation Analyzer Resistance furnace Computer Monitor Printer Balance Quad power socket Analyzer mains plug Furnace mains plug First connect the analyzer to the mains power and switch it on to position 1 in order to win time. The power switch is located on the front panel in the low left hand corner. Set to position 1. The reason why to first switch on the analyzer is for the infrared detectors to have time to stabilize their temperature while cable connections and software start are made.

  • Page 19: Gas Connections

    Installation cables are included in the boxes of additional peripheral devices supplied with the analyzer. These are adapted to the interfaces when the analyzers are put into operation in our company. The serial interface of the balance is programmed in order to match the required configuration for weight transfer to the PC.

  • Page 20: Resistance Furnace-Temperature Adjustment

    Installation When the analyzer’s mains power switch is set to position 2, a valve opens and the oxygen can flow through the gas flow system. The flow rate is stabilized within a few seconds to 180 l/h and it is displayed on the lower flow meter. 4.6 Resistance furnace-Temperature adjustment C3.0096 Caution...

  • Page 21: Gas Purification Furnance Connecting (Optional)

    Installation • Normal operation temperature for the resistance furnace is 1350°C. 4.7 Gas purification furnance connecting (optional) C4.0076 CAUTION Scalding/burns Hot furnace / combustion tube / analyzer parts  Parts of the analyzer can be very hot. • Use heat protecting gloves. Fig.

  • Page 22: Autoloader (Optional)

    The CS-2000 can be supplied with an automatic sample loading system. This loading system may also be retrofitted at a later date. Unlike many other auto loaders, the ELTRA system can accommodate 130 samples giving hours of unattended operation. On request, the loader can be delivered for more crucibles.

  • Page 23: Analysis

    For eye protection use the supplied protective glass. With the CS-2000 a wide variety of materials can be analyzed. The analysis methods are therefore diverse. As different materials burn differently, the chosen sample weight, the possible accelerators, the procedure for the insertion of the sample into the furnace and, finally, the sensitivity of the infrared cell will be different.

  • Page 24: Resistance Furnace

    Analysis sensitivity of the infrared cell for free when the customer sends us samples before shipping the analyzer. 5.1.1 Resistance furnace The following describes the procedures for coal analysis. Ensure the following before analyzing: – The temperature of the analyzer is stable (Power switch at least one to two hours on position 1).
  • Page 25 Analysis – In order to make the work easier, two different rods (2/3) are supplied with the analyzer. Make sure that the boat stop (4) is in the right position. See picture below. Fig. 11: Pushing the combustion boat into the furnace With the insertion rod (2) push the combustion boat into the furnace until the stop is felt.

  • Page 26: Induction Furnace

    Analysis 5.1.2 Induction furnace The steel analysis is described in the following section, as an example. Ensure that the compressed air and oxygen supply are turned on. They should normally not be turned off anyway during working hours. By turning the mains switch to position 3, the heating for the generator tube and the cooling blower are switched on, as well as a valve which allows the oxygen to flow through the analyzer.

  • Page 27: Analysis Example

    Analysis 5.2 Analysis example The analysis of steel and cast iron is generally carried out with approx. 500mg of sample (normally grains or pieces) by adding 1,5 tungsten accelerator. 5.2.1 Combustion peak The combustion is quite rapid and the peaks on the PC screen look as follows: Fig.

  • Page 28: Work Breaks

    Analysis 5.3 Work breaks W6.0023 WARNUNG High temperature / Burning of the skin Hot combustion tube • When the analyzer (HTF, resistance furnace) is switched on again after switching off, the adjusted set point is driven immediately. Please check this! Work breaks, e.g.

  • Page 29: Operating The Pre-Heating Furnace (Optional)

    Analysis Fig. 15: Crucibles preheating The above furnace is used for preheating crucibles. It is an optional accessory and can be purchased separately. When analyzing samples with low concentration of carbon or sulfur (<1000 ppm), the pre- heating of the crucibles is advisable. The crucibles contain traces of carbon, which can vary from 20 to several hundred ppm, depending on their quality.

  • Page 30: Tic-Determination (Optional)

    5.5.1 TIC-module Due to the modular design of the CS-2000, a module for Total Inorganic Carbon (TIC) can be placed between the resistance furnace and the analyzer. For the TIC determination, the sample is treated with acid in the TIC module.
  • Page 31 Analysis Glass distributor Connection to the furnace Acid supply 50 ml glass flask Heater with magnetic stirrer Elevator with variable height Acid bottle with dispenser Furnace Analyzer Position adjustment Moisture trap TIC/TC toggle Analyzer inlet (see below :rear view) Furnace outlet (see below :rear view) Fig.

  • Page 32: Tic-Module Operation Procedure

    Analysis The TIC module is placed between the furnace and the analyser: The outlet (15) of the furnace is connected to the connection (4) of the glass distributor (3). The outlet (2) of the glass distributor (3) is connected to the upper fitting of the moisture trap (13).

  • Page 33: Applications

    Analysis 5.6 Applications 5.6.1 Induction furnace LC – low carbon measuring range HC – high carbon measuring range LS – low sulphur measuring range HS – high sulphur measuring range Typical Material/ Sample + Accelerators Calibration results Analysis time (s) Aluminium 1.5g ±...
  • Page 34 Analysis 0.3g ± 0.1g Iron 3.0% S Cast iron 0.017% S 0.1% S Cast iron Ceramics 2.2g ± 0.2g Tungsten 150mg ± 50mg Sample 12% C CaCO 5.98% C 0.7g ± 0.1g Iron 0.103% S 0.336% S Cast iron 2.57% S Cement 0.8g ±...
  • Page 35 Analysis Cu-Ni 2.0g ± 0.2g Tungsten 0.048% C Steel 0.036% C 0.7g ± 0.1g Sample 1.03% C Steel 0.1% S Steel 40ppm S Nickel 2.0g ± 0.2g Tungsten 0.048% C Steel 0.8g ± 0.1g Sample 1.03% C Steel 0.8g ± 0.1g Iron 0.1% S Steel 17ppm S Fe-Cr...
  • Page 36 Analysis Silicon 1.7g ± 0.2g Tungsten 80mg ± 20mg Sample 12% C CaCO 0.4g ± 0.1g Iron 0.1% S Steel 0.02% S Silicon Carbide 2.0g ± 0.2g Tungsten 60mg ± 10mg Sample 12% C CaCO 30% C 0.7g ± 0.1g Iron 0.1% S Steel 0.02% S Slag...

  • Page 37: Resistance Furnace

    Analysis 5.6.2 Resistance furnace C9.0096 Caution Eye injury Hot combustion tube.  Eye damage. • Avoid looking directly into the hot combustion tube. For eye protection use the supplied protective glass. 5.6.2.1 Coal analysis Furnace temperature: 1350°C. Sample weight around 300mg, depending on the sensitivity of the analyzer and on the C and S content of the sample.

  • Page 38: Ash Analysis

    Analysis Remark The marker can be a piece of tape wrapped around the rod. Check the right position of the marker by pushing another sample up to the level of the marker. The marker is at the correct position when the sample takes 3 to 5 seconds to ignite after stop pushing. Otherwise repeat and check again.

  • Page 39: Graphite Analysis

    320mm. Even though with 100mm IR-path a sample of 50ppm can give reasonable results and good carbon peaks. This shows that the CS-2000 is capable to analyze even much lower carbon values when the path length is 15 times longer! Please note that it is not a problem to...
  • Page 40 Analysis make the CS-2000 very sensitive in carbon. The limits are set by the air entering the resistance furnace and by the blanks of the boats. Good results can be obtained by using quartz boats. There is no chance to measure in this low range if you use ceramic boats. Their blanks and their deviations are huge compared to the sample’s carbon.
  • Page 41 Analysis For even lower carbon samples, a furnace extension piece, supplied by ELTRA, needs to be attached to the furnace inlet. The reason is that the thick short combustion tube allows some air to enter the combustion area. The air contains CO2 which is detected by the carbon cell. As the CO2 concentration resp.
  • Page 42 Analysis Lift and remove the glass platform (1) from the furnace inlet. Make sure that the two hexagon socket screws (2) of the low carbon attachment are turned clockwise up to the end. Use 4mm socket wrench. Attach the device to the furnace inlet, so that the pins (3) and (4) fit into the furnace inlet.

  • Page 43: Maintenance

    Maintenance Maintenance V0074 CAUTION Scalding/burns Hot furnace / combustion tube / analyzer parts – Parts of the analyzer can be very hot. • Check the furnace temperature in the software. • For maintenance the furnace temperature has to be less than 40°C. W8.0023 WARNUNG High temperature / Burning of the skin...

  • Page 44: Reagent Tubes - Removing And Installing

    Maintenance • Replace the cotton wool. It should be replaced earlier when the upper half becomes dark. See chapter Reagent tubes filling NOTICE The above is related to steel analyses and oxygen 99.5% pure. NOTICE There are especially developed chemical qualities and accelerators for analytical instruments. –...
  • Page 45 Maintenance • Wear protective gloves and safety glasses when installing/removing the reagent tubes. C12.0090 CAUTION Risk of injury to eyes Chemicals  When changing the chemicals, the smallest particles of chemicals may be suspended in the air and cause damage to eyes. •...
  • Page 46 Maintenance The copper oxide of the catalyst furnace is replaced after about 2000 analyses. See chapter Reagent tubes filling It is safer, but not absolutely essential, to switch off the analyzer. The components are refitted in reverse order. NOTICE Only the outside grid of the furnace is to be handled; the quartz reagent tube must only be held at the ends.

  • Page 47: Reagent Tubes Filling

    Maintenance Fig. 23: Replacement of moisture trap Turn both screws (1) counter clockwise, until the ring (3) touches the part (2). Lift the glass tube (5) upwards, tilt it to the side and pull downwards. Replace the magnesium perchlorate (Anhydrone). See chapter reagent tube replacing Install the glass tube (5) in reverse order after greasing the lower O-ring.
  • Page 48 Maintenance C14.0090 CAUTION Risk of injury to eyes Chemicals  When changing the chemicals, the smallest particles of chemicals may be suspended in the air and cause damage to eyes. • Always wear protective goggles when working with chemicals. • Please heed the safety data sheets for the chemicals used. as moisture absorber Magnesium perchlorate (anhydrone) Sodium hydroxide (ascarite)

  • Page 49: Reagent Tube Filling-Induction Furnace

    Maintenance 6.3.2 Reagent tube filling-Induction furnace C15.0076 CAUTION Scalding/burns Hot furnace / combustion tube / analyzer parts  Parts of the analyzer can be very hot. • Use heat protecting gloves. C16.0081 CAUTION Danger of bursting  Defective reagent tubes may cause injuries in the form of cuts and other personal injuries.
  • Page 50 Maintenance The lower end of each glass tube is filled with glass wool, for the chemicals to be retained in the reagent tubes. Do not stuff the glass wool to tight otherwise the gas flow will be blocked. The rest of the tube is filled with reagents as shown in the schematic below. The lower half of the reagent tube for the oxygen pre-cleaning tube is filled with magnesium perchlorate (Anhydrone) and the upper half with sodium hydroxide.
  • Page 51 Maintenance Fig. 24: Glass tubes Schematics Keep a tolerance of about ± 20 % of the filling lengths of the drawing. Part No. Material 1. Quartz wool 90330 2. Anhydrone 90200 3. Sodium hydroxide 90210 4. Copper oxide 90290 5. Cotton wool 90340 6.

  • Page 52: Reagent Tube Filling-Resistance Furnace

    Maintenance 6.3.3 Reagent tube filling-Resistance furnace C18.0076 CAUTION Scalding/burns Hot furnace / combustion tube / analyzer parts  Parts of the analyzer can be very hot. • Use heat protecting gloves. C19.0081 CAUTION Danger of bursting  Defective reagent tubes may cause injuries in the form of cuts and other personal injuries.
  • Page 53 Maintenance Fig. 25: Moisture trap filling Keep the shown filling sizes with a tolerance of about ± 20 % Material Part. No 90331 1. Glass wool 90200 2. Magnesium perchlorat (anhydrone) 3. Free (empty)

  • Page 54: Oxygen Purification Furnace Quartz Tube Filling (Optional)

    Maintenance 6.3.4 Oxygen purification furnace quartz tube filling (optional) 2 1 0 2 5 5 21120 2 1 0 6-2-3 Fig. 26: Oxygen purification furnace glass tube Keep a tolerance of about ± 20 % of the filling lengths of the drawing. Material Part No Quartz wool...

  • Page 55: Halogen Trap Filling (Optional)

    6.3.5 Halogen trap filling (optional) Fig. 27: Halogen trap position On request the CS-2000 can be supplied with a halogen trap. The glass tube must be filled with halogen trap material. If the customer orders an analyzer pointing out that he has to analyze materials containing halogens, the analyzer will be delivered with a halogen trap tube attached to the left panel of the analyzer.
  • Page 56 Maintenance 8 - 1 - 2 Fig. 28: Halogen trap filling Material Part No. Glass wool 90331 Halogen trap metal 90235 Halogen trap material 90234 Glass tube 09090...

  • Page 57: Paper Filter Changing

    Maintenance 6.4 Paper filter changing Fig. 29: Paper filter changing Screw an M4 screw (1) into the paper filter holder (2). With this screw, pull the filter holder (2) and the filter (3) out of the reagent tube (4). Remove the screw (1) from the filter holder (2). Remove the old filter (3). A new filter (5) is placed on the filter holder (2) and folded over.

  • Page 58: O-Rings Replacement

    Maintenance Fig. 30: Dust filter cartridge - inserting Lift the dust filter cartridge (1) upwards. Tilt its low end to the front and pull downwards. Install a new cartridge by acting in reverse order. Take care for the cartridge body to have the smaller diameter up and the bigger down. 6.6 O-rings replacement C21.0076 CAUTION...
  • Page 59 Maintenance • When the analyzer (HTF, resistance furnace) is switched on again after switching off, the adjusted set point is driven immediately. Please check this! Fig. 31: furnace details...

  • Page 60: Replacing The O-Rings 11 And 12 For Combustion Tube

    Maintenance Knurled nut Washers Wing nuts Nut for gas inlet tube Gas inlet tube Mounting Nut for gas outlet tube Gas outlet tube Wing nuts Lower furnace lock Upper o-ring for combustion tube Lower o-ring for combustion tube O-ring for lower furnace lock Combustion tube Induction coil Nuts for furnace housing...

  • Page 61: Replacing The O-Rings For Furnace Seal

    Maintenance 6.6.3 Replacing the o-rings for furnace seal Fig. 32: Cleaning mechanism details • Unscrew the knurled nuts (1). • Unscrew the wing nuts (2). • Unscrew the nuts (3) and gas inlet tubes (4). • Remove the furnace cleaning system, by pulling up the bar (5). •...
  • Page 62 Maintenance Fig. 33: Resistance furnace – The small O-rings for sealing the top of the induction furnace should also not be greased. Fig. 34: Induction furnace – The O-ring for sealing the cone should also not be greased.
  • Page 63 Maintenance Fig. 35: Induction furnace-Cone...

  • Page 64: Furnace Cleaning Brush - Replacing

    Maintenance 6.7 Furnace cleaning brush - replacing C22.0076 CAUTION Scalding/burns Hot furnace / combustion tube / analyzer parts  Parts of the analyzer can be very hot. • Use heat protecting gloves. The furnace is equipped with an auto-cleaning system. This mechanism contains a brush, which cleans the quartz tube (combustion tube).

  • Page 65: Dust Trap Cleaning

    Maintenance • Reassemble in reverse order NOTICE It is absolutely important to hold the brush holder (8) and not the bar (5), when unscrewing the heat shield (9), otherwise the rods (6) will bend. 6.8 Dust trap cleaning C23.0076 CAUTION Scalding/burns Hot furnace / combustion tube / analyzer parts ...
  • Page 66 Maintenance Fig. 37: Dust trap • The main switch (1) can stay at position 3. • The oxygen does not need to be turned off, but only the furnace has to be opened. • The heat shield (4) and the pedestal (5) can occasionally be cleaned. •...
  • Page 67 Maintenance The cock (1) is rotated by 180°, so that the O-ring (2) loosens. The dust trap (3) is raised as far as it will go. Then it is swung to the side and Detached downwards at an angle. • Clean the dust trap (3).

  • Page 68: Dust Trap Cleaning-Resistance Furnace

    Maintenance Fig. 41: Dust trap: outer and inner o-rings 6.8.2 Dust trap cleaning-Resistance furnace Fig. 42: Dust trap-Resistance furnace • Remove the two screws (1). • Remove the cover (2) using a screw driver if necessary. • Remove the dust from the inside of the dust trap (4) using the brush (5). •...

  • Page 69: Combustion Tube Replacement

    Maintenance 6.9 Combustion tube replacement C24.0076 CAUTION Scalding/burns Hot furnace / combustion tube / analyzer parts  Parts of the analyzer can be very hot. • Use heat protecting gloves. C25.0081 CAUTION Danger of bursting  Defective reagent tubes may cause injuries in the form of cuts and other personal injuries.

  • Page 70: Induction Furnace

    Maintenance 6.9.1 Induction furnace Fig. 43: Induction furnace details Knurled nut Washers Wing nuts Nut for gas inlet tube Gas inlet tube Mounting Nut for gas outlet tube Gas outlet tube Wing nuts Lower furnace lock Upper o-ring for combustion tube Lower o-ring for combustion tube O-ring for lower furnace lock Combustion tube...
  • Page 71 Maintenance Nuts for furnace housing Upper furnace lock • Remove the furnace cover by just loosening the nuts (16). • Unscrew the knurled nuts (1) and washers (2). • Unscrew the wing nuts (3). • Unscrew the nuts (4) and detach the tubes (5). •...

  • Page 72: Resistance Furnace

    Maintenance 6.9.2 Resistance furnace W14.0023 WARNUNG High temperature / Burning of the skin Hot combustion tube • When the analyzer (HTF, resistance furnace) is switched on again after switching off, the adjusted set point is driven immediately. Please check this! Fig 44: Removing the combustion tube CAUTION: Unplug the mains power cable before opening this device! Switch off the furnace and disconnect the power plug.
  • Page 73 Maintenance Fig 45: dust box Remove the boat stop (9) out of the combustion tube. Unscrew the screws (13) and remove the complete dust box assembly (14). Unscrew the screws (2) and remove the front assembly (3). Remove the O-ring (6) and the safety spring (7). Pull the dust box (D) together with the combustion tube (6) out of the rear of the furnace.

  • Page 74: Generator Tube Replacing

    Maintenance When you turn on the device after reinstalling, the set setpoint value is driven immediately. Please check it, see chapter 4.6: Resistance Furnace-Temperature adjustment. 6.10 Generator tube replacing For the replacement of the generator tube a separate manual is available. Please contact the service, see Chapter 1, contact information.

  • Page 75: Heating Elements Replacing

    Maintenance 6.13 Heating elements replacing D2.0005 DANGER Mortal danger from electric shock Exposed power contacts - High Voltage  An electric shock can cause injuries in the form of burns and cardiac arrhythmia, respiratory arrest or cardiac arrest. • Set the mains switch of the analyzer to position 0 and pull the mains plug of the mains socket.

  • Page 76: Gas Leaks Checking

    • If the pressure still decreases, then the leakage is somewhere in the gas flow system outside the furnace area. • Read the service manual or contact the local Eltra agent or contact Eltra GmbH directly.

  • Page 77: Leaks In The Furnace Inlet System

    Maintenance Fig. 50: Gas leaks check-furnace • Release the button (43), close the furnace, squeeze the tube (6) tight and press and hold the button (43). • If the pressure on gauge (12) remains constant, then the furnace has to be checked for leaks.

  • Page 78: Function Description

    The CS-2000 can be supplied with up to three independent Infrared cells, giving the following options: Two IR-cells for carbon and one for sulfur.

  • Page 79: Gas Flow System

    Function description 7.3 Gas flow system The oxygen supply is connected to the inlet of the gas flow system. Pure oxygen is available in steel bottles. A 99.5% purity is fully sufficient. Any CO2 or H2O which may be contained in the oxygen is retained in the CO2 and H2O trap.
  • Page 80 Function description Fig. 51: Gas flow system...

  • Page 81: Infrared Cell

    The signal obtained is amplified and rectified, so that the infrared cell output is DC voltage. The detectors utilize solid state sensors combined with infrared filters. The sensors are not gas filled, thus eliminating long term problems due to gas leakage. The CS-2000 can be equipped with up to four independent Infrared cells.

  • Page 82: Furnace

    The users of carbon and sulfur analyzers with induction furnaces know that dust accumulates during the combustion (mainly of iron and tungsten oxides) in the combustion chamber. The CS-2000 induction furnace is cleaned automatically after each analysis, thus ensuring repeatable and accurate results. The cleaning mechanism is mechanically attached to the furnace open/close system, to ensure that the cleaning brush will not collide with the hot crucible.The cleaning brush will never burn.

  • Page 83: Resistance Furnace

    Function description 7.5.2 Resistance furnace Description The temperature of the furnace is adjustable up to 1550°C. The combustion tube has an inner diameter of 27 cm and a hot zone of about 200 mm. The temperature, which is digitally displayed, can be adjusted with an accuracy right down to 1°C. The platform on the front-side of the furnace serves to carry samples for the analyses, as well as hot combustion boats, after been removed from the furnace.
  • Page 84 Function description This is important for analysis in the very low ppm range. The crucibles are inserted into the furnace tube and they remain preheated in the tube until needed. Each time a crucible is needed, a new one is inserted into the tube, and a preheated crucible falls out the other end of the furnace tube.

  • Page 85: Miscellaneous

    Miscellaneous Miscellaneous 8.1 Ordering numbers 8.1.1 Front side Fig. 55: Front side Description Part No. 05000 IR-cell 11170 Dust cartridge 11390 Oxygen solenoid valve 11400 Pressure outlet solenoid valve 11415 Oxygen stop solenoid valve 11430 Purge solenoid valve 11440 Bypass solenoid valve 11492 Pressure regulator 11492...

  • Page 86: Left Hand Side

    Miscellaneous 16100 Power supply board NK 31 18467 Microcontroller board UNI 8.1.2 Left hand side Fig. 56: Left hand side view Part No. Description Dust filter cartridge 11180 Gas flow regulating valve 1370-2001 Oxygen solenoid valve 11390 Pressure outlet solenoid valve 11400 Oxygen stop solenoid valve 11415...

  • Page 87: Right Side

    Miscellaneous Power supply board NK 31 16110 Valve V10 24250 Valve V11 25190 Valve V13 24260 Valve V12 24265 Board CS20 24285 Attenuator volume 35336 8.1.3 Right side 11190 13009 11492 13850 77050 12045 12100 12080 11822 B9-1-5 Fig. 57: Right side Description Part No.

  • Page 88: Pneumatics

    Miscellaneous 12045 Transformer 12080 Rectifier 12100 Transformer 8.1.4 Pneumatics Piston 26618 60240 60635 26319 60522 60240 Cushioning 60522 60513 26618 26319 60635 60631 60635 60631 60635 Coil cooling 26319 60631 60635 26618 60558 Fig. 58: Pneumatics Description Part No. 26319 Hollow screw 26618 Valve block...

  • Page 89: Oscillating Circuit

    Miscellaneous 8.1.5 Oscillating circuit Fig. 59: Oscillating circuit Description Part No. 13060 Protection sheet 13081 Capacitor support 13090 Upper coil connector 13100 Lower coil connector 13110 Anode connector 13122 Capacitor connector 13130 Capacitor connector 13140 Ground connector 13150 Anode heat sink 13160 Coil heat sink 13170...
  • Page 90 Miscellaneous 77140 HF-filter 77210 Oscillator tube 77322 Capacitorr 77330 Capacitor 77335 Capacitor 77333 Filter 77345 (13261; 13262; 77340; 77341; 77342) Capacitor 77350 Capacitor 100 nF 77489 Bracket 77600 Resistor 77610 Resistor...

  • Page 91: Furnace

    Miscellaneous 8.1.6 Furnace Fig. 60: Furnace...
  • Page 92 Miscellaneous Description Part No. 13067 Combustion coil 14009 Pneumatic cylinder for furnace lift 14021 Upper furnace lock 14026 Lower furnace lock 14030 Upper furnace plate 14035 Lower furnace plate 14090 Bearing 14100 Mounting rod 14110 Threaded rod 14120 Furnace cover 14130 Combustion tube 14150...

  • Page 93: Furnace Cleaning Mechanism

    Miscellaneous 8.1.7 Furnace cleaning mechanism Fig. 61: Furnace cleaning mechanism Description Part No. 14014 Complete furnace cleaning assembly unit: 14021 Upper furnace lock 14045 Cleaning brush for combustion tube 14051 Brush holder 14072 Ceramic heat shield for brush 14080 Cleaning mechanism Rod 14160 Upper log 70120...

  • Page 94: Gas Purification Furnace

    Miscellaneous 8.1.8 Gas purification furnace Fig. 62: Gas purification furnace Description Part No. 21010 Heather section 21120 Quartz tube 70380 O-Ring...

  • Page 95: Front Side And Rear Side

    Miscellaneous 8.1.9 Front side and rear side Fig. 63: Front side and rear side Description Part No. 09090 Reagent tube 11480 Adjustable restrictor 15095 Flow display 600l/h 35355 Lower reagent tube connector 36445 Platform 36700 Upper reagent tube connector 36730 White tube 36735 Black tube...
  • Page 96 Miscellaneous Description Part No. 36101 Boat stop 36216 Combustion boat insertion stick 36217 Combustion boat removing stick 36242 Ceramic plate 36283 Heating element connector 36445 Front panel for the combustion boat 36465 Platform plate 36620 Dust trap 36665 Spring 36799 Cooling fan *36907 Temperature control board TH 43 / TH 44...

  • Page 97: Furnace Tube Cleaning

    Miscellaneous 8.1.11 Furnace tube cleaning Fig. 65: Gas outlet tube Description Part No. 36720 Furnace outlet tube 36725 Cleaning tube...

  • Page 98: Tic-Module

    Miscellaneous 8.1.12 Tic-module Fig 66: TIC-module [35543-9008]...
  • Page 99 Miscellaneous Part No. Description 38225 Glass stopper (connection to the analyzer) 11042 Upper moisture trap connector 70230 O-ring 9*3 11064 Moisture trap 38200 Glass distributor 50 ml glass flask 90900 71070 Heater with magnetic stirrer 38400 Support with variable height 70230 O-ring 9*3 11045...

  • Page 100: Packing

    Miscellaneous 8.2 Packing Fig. 67: Packing Before packing, the analyzer and furnace must be wrapped in plastic foil, to protect it from moisture and dust, and then to be placed in a wooden case. The wrapped analyzer should be surrounded by a layer of foam (chips) of at least 10cm, in order to avoid any damage due through transportation.
  • Page 101 Miscellaneous Fig. 68: Packing-Front view • Place the analyzer directly on the pallet with the right side towards the middle of the pallet, because the furnace and the transformer are the heaviest parts of the analyzer. Fig. 69: Packing-Top view •...
  • Page 102 Miscellaneous Fig. 70: Packing-Foam I • Tilt the analyzer to the furnace side and place a piece of foam at the right position. Fig. 71: Packing-Foam II • Tilt the analyzer to the other side and place the second piece of foam at the right place. If necessary, a third piece of plastic foam can be placed on to the pallet.

  • Page 103: Pre-Installation Guide

    Miscellaneous 8.3 Pre-installation guide W15.0021 WARNING Fire hazard / Risk of burns Hot parts (crucibles, reagents,...) can fall down  Ignition of tables, floors, or any other surface the hot part falls on  Ignition of clothes and any other material •...
  • Page 104 Miscellaneous Gas connections: The supplied tubes carry a connector with G¼" inner diameter ". 72: Carrier gas tube Fig. Connections for compressed air: The tubes supplied together with the analyzer, carry a connector with G¼" inner diameter. 73: Compressed air tube Fig.

  • Page 105: Approved Methodologies To Which Eltra Instruments Conform

    Approved methodologies to which Eltra instruments conform Approved methodologies to which Eltra instruments conform 9.1 Inorganic materials (Metals) Norm Elements Materials Instruments DIN EN ISO 9556:2002-04 Steel and Iron CS-800 CS-2000 ISO 4935:1989 Steel and Iron CS-800 DIN EN 24935:1992-07...

  • Page 106: Organic Materials (Oil, Coal, Foodstuffs)

    CS 2000 9.2 Organic materials (Oil, Coal, foodstuffs) Norm Elements Materials Instruments ASTM D 1552:2008 Oil and Petrolium Products CS-580 CS-2000 ASTM D 4239:2013; Coal and Coke CS-580 CS-2000 ASTM D 5016:2008 Coal and Coke Ash CS-580 CS-2000 ASTM D 1619:2011...
  • Page 107 Disposal Accordingly, all machines supplied after 13.08.2005 in the business-to-business area to which this product is classified, may no longer be disposed of with municipal or household waste. To document this they have the following label: Fig. 74: Disposal label Since the disposal regulations within the EU may differ from country to country we would request you to consult your supplier.

  • Page 108: Index

    Analysis............... 23 Analysis example ..........27 Figure Applications ............33 Auto loader ............. 22 Approved methodologies to which Eltra Cleaning mechanism details ......61 instruments conform ........105 Crucibles preheating ........29 Ash analysis ............38 Dust filter cartridge - inserting ......58 Ash content determination ......
  • Page 109 Index plastics ............... 37 Power supply system ......... 12 Halogen trap filling (optional) ......55 Preheating furnace ..........83 Heating elements replacing ........ 75 pre-heating furnace operating ......29 Pre-installation guide ........103 property damage ..........7 Induction furnace ......26, 33, 70, 82 Protection type ...........
  • Page 110 Copyright © Copyright by Eltra GmbH Retsch-Allee 1-5 42781 Haan Germany...
