Mopar 82212162 Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Click on the desired vehicle to take you directly to the vehicle
specific instructions.
2008
2008
2008
2008
2009
2010
2010
2009
2007
12/15/09
82212162
FLO TV FOR PRODUCTION OVERHEAD DVD
(OR MOPAR EQUIVALENT)
i
Contents
K6860918

Advertisement

loading
Need help?

Need help?

Do you have a question about the 82212162 and is the answer not in the manual?

Questions and answers

Related Manuals for Mopar 82212162

Summary of Contents for Mopar 82212162

  • Page 1: Table Of Contents

    82212162 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) Contents Click on the desired vehicle to take you directly to the vehicle specific instructions. 2008 Caravan 2008 Town and Country 2008 Commander 2008 Grand Cherokee 2009 Dodge Ram 1500...

  • Page 2: Caravan Town And Country

    FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) CARAVAN 2008 For technical assistance, service replacement parts, or customer service call:1-800-34-MOPAR 2008 TOWN & COUNTRY TOOLS REQUIRED: 11MM KIT CONTENTS: FLO TV Module Main Harness Wired Remote Batteries (x2) Wireless...
  • Page 3 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) CARAVAN 2008 2008 TOWN & COUNTRY Prior to Installation Care must be taken when installing this accessory to ensure damage does not occur to the vehicle. The installation of this accessory should follow approved guidelines to ensure a quality installation.
  • Page 4 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) CARAVAN 2008 2008 TOWN & COUNTRY Interior Component Removal Disassemble the upper rear header trim (Figure 2). 1. Using a trim stick C-4755 or equivalent, remove the two plastic screw covers on either side to reveal the screws.
  • Page 5 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) CARAVAN 2008 2008 TOWN & COUNTRY Interior Component Removal (continued) Remove the driver side rear sill plate (Figure 5). 1. Using a trim stick C-4755 or equivalent, pry the driver side rear sill plate up from the door sill and remove.
  • Page 6 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) CARAVAN 2008 2008 TOWN & COUNTRY Interior Component Removal (continued) Disassemble passenger side A-pillar (Figure 8). 1. Using a trim stick C-4755 or equivalent, remove the two plastic trim covers from the A-pillar trim.
  • Page 7 (or wipe), and clean a small area at a time (~ 3 ft. x 3 ft. max.). b. Shake well and apply MOPAR approved cleaner to cloth or wipe. Do not spray cleaning solution directly on vehicle surfaces.
  • Page 8 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) CARAVAN 2008 2008 TOWN & COUNTRY Route the antenna cable. 1. Run the antenna cable near the passenger side hatch hinge and secure in place using 3 pieces of foam tape (Figure 10).
  • Page 9 For optimal performance, the antenna receiver should be positioned at least two inches below the headliner (Figure 14). 2. Clean the windshield with a MOPAR approved cleaner and cleaning method. When cleaning with a MOPAR approved cleaner and cleaning method: a.
  • Page 10 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) CARAVAN 2008 2008 TOWN & COUNTRY Installing the Wired Remote Control and Antenna Receiver (continued) (Figure 15). 4. Peel the protective adhesive tape from the antenna receiver and adhere the antenna to the windshield in the marked mounting location (Figure 14).
  • Page 11 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) CARAVAN 2008 2008 TOWN & COUNTRY Connecting the Main Harness Connect the Main Harness (Figure 18). 1. Unplug the factory aux jack connector. 2. Plug the main harness male connector (A) into the aux jack.
  • Page 12 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) CARAVAN 2008 2008 TOWN & COUNTRY Connect power and ground (continued). 4. Insert the red fused wire of the main harness through the opening and wrap around the fused ignition switch output wire (Figure 22).
  • Page 13 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) CARAVAN 2008 2008 TOWN & COUNTRY In Process Functional Test 1. Temporarily reconnect the battery negative cable. 2. Turn ignition key to the ACC position. 3. Press the POWER Button on the Factory RSE unit. Verify that the Factory RSE unit powers on.
  • Page 14 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) CARAVAN 2008 2008 TOWN & COUNTRY Figure 27 For technical assistance, service replacement parts, or customer service call:1-800-34-MOPAR 12/15/09 13 of 13 K6860918...

  • Page 15: Commander

    FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) For technical assistance, service replacement 2008 GRAND CHEROKEE parts, or customer service call:1-800-34-MOPAR 2008 COMMANDER TOOLS REQUIRED: 10MM KIT CONTENTS: FLO TV Module Main Harness Wired Remote Batteries (x2) Wireless Remote...
  • Page 16 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2008 GRAND CHEROKEE 2008 COMMANDER Prior to Installation Care must be taken when installing this accessory to ensure damage does not occur to the vehicle. The installation of this accessory should follow approved guidelines to ensure a quality installation.
  • Page 17 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2008 GRAND CHEROKEE 2008 COMMANDER Interior Component Removal NOTE: Cover the face of the center console with a protective blanket during the removal procedure. NOTE: Place Components and attaching hardware on a protective blanket outside the vehicle following removal.
  • Page 18 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2008 GRAND CHEROKEE 2008 COMMANDER Interior Component Removal Disassemble the upper and lower rear header trim panels (Figure 5). 1. Using a trim stick C-4755 or equivalent, remove the upper and lower rear header trim panels.
  • Page 19 NOTE: Once attached, the antenna cannot be easily removed. 1. Clean the driver side rear roof between the two driver side roof bows with a MOPAR approved cleaner and cleaning method. When cleaning with a MOPAR approved cleaner and cleaning method: a.
  • Page 20 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2008 GRAND CHEROKEE 2008 COMMANDER Route the antenna cable. 1. Run the antenna cable near the driver side hatch hinge and secure in place using 3 pieces of foam tape (Figure 9).
  • Page 21 For optimal performance, the antenna receiver should be positioned at least two inches below the headliner (Figure 13). 2. Clean the windshield with a MOPAR approved cleaner and cleaning method. When cleaning with a MOPAR approved cleaner and cleaning method: a.
  • Page 22 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2008 GRAND CHEROKEE 2008 COMMANDER Installing the Wired Remote Control and Antenna Receiver (continued) 5. Route the antenna receiver cable under the headliner and towards the passenger side A-pillar (Figure 13).
  • Page 23 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2008 GRAND CHEROKEE 2008 COMMANDER Connecting the Main Harness Connect the Main Harness (Figure 15). 1. Unplug the factory aux jack connector. 2. Plug the main harness male connector (A) into the aux jack.
  • Page 24 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2008 GRAND CHEROKEE 2008 COMMANDER Connect power and ground (continued). 4. Insert the red fused wire of the main harness through the opening and wrap around the fused ignition switch output wire (Figure 19).
  • Page 25 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2008 GRAND CHEROKEE 2008 COMMANDER In Process Functional Test 1. Temporarily reconnect the battery negative cable. 2. Turn ignition key to the ACC position. 3. Press the POWER Button on the Factory RSE unit. Verify that the Factory RSE unit powers on.
  • Page 26 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2008 GRAND CHEROKEE 2008 COMMANDER Figure 24 For technical assistance, service replacement parts, or customer service call:1-800-34-MOPAR 12/15/09 12 of 12 K6860918...

  • Page 27: Dodge Ram 1500 Dodge Ram 2500 Dodge Ram 3500

    FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 DODGE RAM 1500 For technical assistance, service replacement 2010 DODGE RAM 2500 parts, or customer service call:1-800-34-MOPAR 2010 DODGE RAM 3500 TOOLS REQUIRED: 11MM KIT CONTENTS: FLO TV Module Main Harness...
  • Page 28 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) DODGE RAM 1500 2009 2010 DODGE RAM 2500 2010 DODGE RAM 3500 Prior to Installation Care must be taken when installing this accessory to ensure damage does not occur to the vehicle.
  • Page 29 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 DODGE RAM 1500 2010 DODGE RAM 2500 2010 DODGE RAM 3500 Interior Component Removal NOTE: Cover the face of the center console with a protective blanket during the removal procedure.
  • Page 30 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) DODGE RAM 1500 2009 2010 DODGE RAM 2500 2010 DODGE RAM 3500 Disassemble the rear center console aux plate. Vehicles equipped with center console: Using a trim stick C-4755 or equivalent, disengage the rear center console aux plate.
  • Page 31 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 DODGE RAM 1500 2010 DODGE RAM 2500 2010 DODGE RAM 3500 Installing the Antenna NOTE: You must keep the antenna at least four inches from all objects. NOTE: Once attached, the antenna cannot be easily removed.
  • Page 32 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) DODGE RAM 1500 2009 2010 DODGE RAM 2500 2010 DODGE RAM 3500 Installing the Antenna (continued) OPTION B: Vehicles NOT equipped with roof mounted lights. 1. Clean the front center of the roof per the cleaning method on the following page.
  • Page 33 DODGE RAM 2500 2010 DODGE RAM 3500 Cleaning Guidelines When cleaning with a MOPAR approved cleaner and cleaning method: a. Always use a clean (lint free scratch resistant) soft cloth (or wipe), and clean a small area at a time (~ 3 ft. x 3 ft. max.).
  • Page 34 For optimal performance, the antenna receiver should be positioned at least two inches below the headliner (Figure 12). 2. Clean the windshield with a MOPAR approved cleaner and cleaning method. When cleaning with a MOPAR approved cleaner and cleaning method: a.
  • Page 35 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 DODGE RAM 1500 2010 DODGE RAM 2500 2010 DODGE RAM 3500 Installing the Wired Remote Control and Antenna Receiver (continued) 5. Route the antenna receiver cable under the headliner and towards the passenger side A-pillar (Figure 12).
  • Page 36 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) DODGE RAM 1500 2009 2010 DODGE RAM 2500 2010 DODGE RAM 3500 Connecting the Main Harness Connect the Main Harness (Figure 14). 1. Unplug the factory aux jack connector. 2. Plug the main harness male connector (A) into the aux jack.
  • Page 37 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 DODGE RAM 1500 2010 DODGE RAM 2500 2010 DODGE RAM 3500 Connect power and ground (continued). 4. Insert the red fused wire of the main harness through the opening and wrap around the fused ignition switch output wire (Figure 18).
  • Page 38 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) DODGE RAM 1500 2009 2010 DODGE RAM 2500 2010 DODGE RAM 3500 In Process Functional Test 1. Temporarily reconnect the battery negative cable. 2. Turn ignition key to the ACC position.
  • Page 39 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 DODGE RAM 1500 2010 DODGE RAM 2500 2010 DODGE RAM 3500 Figure 23 For technical assistance, service replacement parts, or customer service call:1-800-34-MOPAR 12/15/09 13 of 13 K6860918...

  • Page 40: Journey

    FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) For technical assistance, service replacement 2009 JOURNEY parts, or customer service call:1-800-34-MOPAR TOOLS REQUIRED: T-15 KIT CONTENTS: FLO TV Module Main Harness Wired Remote Batteries (x2) Wireless Remote Antenna Antenna Tail...
  • Page 41 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 JOURNEY Prior to Installation Care must be taken when installing this accessory to ensure damage does not occur to the vehicle. The installation of this accessory should follow approved guidelines to ensure a quality installation.
  • Page 42 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 JOURNEY Interior Component Removal NOTE: Cover the face of the center console with a protective blanket during the removal procedure. NOTE: Place components and attaching hardware on a protective blanket outside the vehicle following removal.
  • Page 43 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 JOURNEY Interior Component Removal Remove the driver side rear sill plate (Figure 4). 1. Using a trim stick C-4755 or equivalent, pry the driver side rear sill plate up from the door sill and remove.
  • Page 44 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 JOURNEY Interior Component Removal (continued) Disassemble the lower rear storage bin (continued). 2. Open the rear storage bin cover. 3. Using a socket wrench, remove the four 10mm nuts, two from each side of the storage bin (Figure 7).
  • Page 45 NOTE: Once attached, the antenna cannot be easily removed. 1. Clean the driver side rear roof between the two driver side roof bows with a MOPAR approved cleaner and cleaning method. When cleaning with a MOPAR approved cleaner and cleaning method: a.
  • Page 46 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 JOURNEY Installing the Antenna (continued) Route the antenna cable (continued). 2. Pull back the rubber door seal and install the Edge Guard provided in the hardware kit over the door opening, as shown (Figure 11).
  • Page 47 Figure 14 receiver should be positioned at least two inches below the headliner (Figure 14). 2. Clean the windshield with a MOPAR approved cleaner and cleaning method. When cleaning with a MOPAR approved cleaner and cleaning method: a. Always use a clean (lint free scratch resistant) soft cloth (or wipe), and clean the area.
  • Page 48 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 JOURNEY Installing the Wired Remote Control and Antenna Receiver (continued) 4. Peel the protective adhesive tape from the antenna receiver and adhere the antenna to the windshield in the marked mounting location (Figure 14).
  • Page 49 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 JOURNEY Connecting the Main Harness Connect the Main Harness (Figure 16). 1. Unplug the factory aux jack connector. 2. Plug the main harness male connector (A) into the aux jack.
  • Page 50 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 JOURNEY Connect power and ground (continued). 4. Insert the red fused wire of the main harness through the opening and wrap around the fused ignition switch output wire (Figure 208).
  • Page 51 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 JOURNEY In Process Functional Test 1. Temporarily reconnect the battery negative cable. 2. Turn ignition key to the ACC position. 3. Press the POWER Button on the Factory RSE unit. Verify that the Factory RSE unit powers on.
  • Page 52 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2009 JOURNEY Figure 25 For technical assistance, service replacement parts, or customer service call:1-800-34-MOPAR 12/15/09 13 of 13 K6860918...

  • Page 53: Nitro

    FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2007 NITRO For technical assistance, service replacement parts, or customer service call:1-800-34-MOPAR TOOLS REQUIRED: KIT CONTENTS: FLO TV Module Main Harness Wired Remote Batteries (x2) Wireless Remote Antenna Tail Antenna HARDWARE KIT CONTENTS: DESCRIPTION 8”...
  • Page 54 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2007 NITRO Prior to Installation Care must be taken when installing this accessory to ensure damage does not occur to the vehicle. The installation of this accessory should follow approved guidelines to ensure a quality installation.
  • Page 55 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2007 NITRO Interior Preparation and Component Removal NOTE: Cover the face of the center console with a protective blanket during the removal procedure. NOTE: Place components and attaching hardware on a protective blanket outside the vehicle following removal.
  • Page 56 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2007 NITRO Interior Preparation and Component Removal (continued) Remove the center console. NOTE: Place the center console and attaching hardware on a protective blanket outside the vehicle following removal. 1. Using a trim stick C-4755 or equivalent, disengage and remove the gear shift trim plate (1) (Figure 4).
  • Page 57 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2007 NITRO Interior Preparation and Component Removal (continued) Disassemble the lower rear trim (Figure 7). 1. Using a trim stick C-4755 or equivalent, pry the lower rear trim panel upward and remove.
  • Page 58 NOTE: Once attached, the antenna cannot be easily removed. 1. Clean the driver side rear roof in line with the left driver side roof bow with a MOPAR approved cleaner and cleaning method. When cleaning with a MOPAR approved cleaner and cleaning method: a.
  • Page 59 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2007 NITRO Route the antenna cable (continued) 2. Pull back the rubber door seal and install the Edge Guard provided in the hardware kit over the door opening, as shown (Figure 11).
  • Page 60 For optimal performance, the antenna receiver should be positioned at least two inches below the headliner (Figure 14). 2. Clean the windshield with a MOPAR approved cleaner and cleaning method. When cleaning with a MOPAR approved cleaner and cleaning method: a.
  • Page 61 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2007 NITRO Installing the Wired Remote Control and Antenna Receiver (continued) 5. Route the antenna receiver cable under the headliner and towards the passenger side A-pillar (Figure 14). 6. Continue routing the antenna receiver cable down the A-pillar towards the glove box area (Figure 14).
  • Page 62 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2007 NITRO Connecting the Main Harness Connect the Main Harness (Figure 16). 1. Unplug the factory aux jack connector. 2. Plug the main harness male connector (A) into the aux jack.
  • Page 63 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2007 NITRO Connect power and ground (continued). 4. Insert the red fused wire of the main harness through the opening and wrap around the fused ignition switch output wire (Figure 20).
  • Page 64 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2007 NITRO In Process Functional Test 1. Temporarily reconnect the battery negative cable. 2. Turn ignition key to the ACC position. 3. Press the POWER Button on the Factory RSE unit. Verify that the Factory RSE unit powers on.
  • Page 65 FLO TV FOR PRODUCTION OVERHEAD DVD (OR MOPAR EQUIVALENT) 2007 NITRO Figure 25 For technical assistance, service replacement parts, or customer service call:1-800-34-MOPAR 12/15/09 13 of 13 K6860918...
