Introduction
Thank you for purchasing the FrSky video transmission device. A simple and clean design, equipped with a
switchable power output and operating band and channel. Paired with a FrSky radio transmitter, the parameters can
be adjusted conveniently through the gTrans.lua script. To fully enjoy all the features of this device please thoroughly
read the instructions below to set up the device.
Overview
Specifications
• Dimension: 17×15.3×4mm (L×W×H)
• Weight: 1.2g
• Available Channel: 10CH
• Operating Voltage: 5V
Features
• Support S.Port
• Support inverted S.Port
Transmission Frequency
CH
CH1
Band
5655
A
5705
B
LED State
LED
Indication
Flash 1 time
Flash 2 times
Flash 3 times
Flash 4 times
Flash 5 times
FrSky Electronic Co., Ltd.
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: sales4tech@gmail.com
Instruction Manual for FrSky Scout VS600 Mini
BLUE
RED
GREEN
Scout VS600 Mini
CH2
5665
5715
Green
Power
25mW
100mW
200mW
300mW
www.frsky-rc.com
17 mm
• Transmission Frequency: 5.7GHz
• Transmission Power: ＜0.01mW (pit mode) /
25mW / 100mW / 200mW / 300mW
• Adjustable RF power
• Support set parameters by gTrans.lua / Button
CH3
5675
5725
Red
Band
A
B
/
/
/
Contact us: frsky@frsky-rc.com
Button
S.Port
- S.Port
VDD5.0
VEDIO IN
GND
CH4
CH5
5685
5695
5740
5750
Blue
Channel
CH1
CH2
CH3
CH4
CH5
Version
