  • Page 2 SAFETY AND OPERATING MANUAL Belt and Disc Sander BD370 ORIGINAL INSTRUCTIONS BD370...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Welcome to Lumberjack! Dear Customer, Congratulations on your purchase. Before using the product for the first time please be sure to read these instructions for use. They provide you with all information necessary for using the product safely and to ensure its long service life.

  • Page 4: General Power Tool Safety Warnings

    A wrench or a key left c) Do not expose power tools to rain or wet attached to a rotating part of the power tool may conditions. Water entering a power tool will result in personal injury. increase the risk of electric shock. BD370...
  • Page 5 Power tools are cancer. Materials containing asbestos may only be dangerous in the hands of untrained users. worked by specialists. Observe the relevant regulations in your country for the materials to be worked. BD370...
  • Page 6 Never perform layout, assembly or set-up We recommend the use of a residual current device with a residual current rating of 30mA or work on the table while the sander is operating. less. BD370...
  • Page 7 The smaller the gauge number of the wire the greater the capacity of the cord. f) When using a cable reel, always unwind the cable completely. BD370...

  • Page 8: Symbols & Cable Rating Chart

    SYMBOLS AND POWER RATING CHART Danger! – Read the operating Caution! Wear safety goggles. instructions to reduce the risk of injury. Caution! Risk of Injury! Do Caution! Wear ear defenders. not reach into the running saw blade Caution! Wear a dust mask. BD370...

  • Page 9: Machine Details And Product Features

    0° - 90° line use. Disc Size - Ø 150mm Disc Speed - 225mm x 158mm Package Contents: Table Tilt - 0° - 45° Belt & Disc sander Gross Weight - 19.5kg Nett Weight - 18.5kg 01 01 01 01 06 BD370...
  • Page 10 All parts must be properly mounted and all conditions fulfilled that ensure faultless operation. Damaged protective devices and parts must be immediately replaced by an authorised service centre. 01 01 01 01 07 BD370...

  • Page 11: Assembly

    ASSEMBLY INSTRUCTIONS & OPERATION Operation Installing Sand Disc Adjusting Work Table Fix to Mounting Board (not supplied) Clamp Mounting Board to Work Surface (not supplied) Ready for Use BD370...
  • Page 12 OPERATION Sanding using Mitre Gauge Sanding Outside Curves BD370...
  • Page 13 OPERATION Surface Sanding Sanding inside Curves BD370...

  • Page 14: Operation, Maintenance And Service

    Before and aft er each use, check the product for damage or broken parts. Keep the product in top working conditi on by immediately replacing parts with spares approved by the manufacturer. Clean out accumulated dust using a brush or vacuum cleaner. Do not use compressed air. BD370...
  • Page 15 If the power supply cord is damaged, it must be replaced only by the manufacturer or by an authorised service centre to prevent damage to the saw or risk of electrocution. Changing Sanding Belt BD370...
  • Page 16 OPERATION Storage BD370...

  • Page 17: Lumberjack Guarantee

    If a return is requested by the Authorised Dealer or 1.2.3 If asked to do so by Lumberjack or its Lumberjack, you will be provided with a Returns Authorised dealer, you return the product at Material Authorisation number which must be your own cost to Lumberjack’s or supplying...
  • Page 18 Lumberjack. If you include a contact number with this it will speed your claim 2.4 Please note that it is essential that the letter of claim reaches Lumberjack on the last day of this Guarantee at the latest. Late claims will not be considered.

  • Page 19: Declaration Of Conformity

    Old Heath Road, Wolverhampton, WV1 2RP. Tel: 01902 450 470 Declares that the Belt & Disc Sander(BD370) Is in compliance with the regulations included in the Directives:2006/42/EC EC DECLARATION OF CONFORMITY Certificate for EC-type examination delivered by Intertek Testing Services Ltd.,Shanghai,Building No.86,1198 Qinzhou Road(North),Caohejing Development Zone,Shanghai 200233,China.

  • Page 20: Parts List

    Inner hex screw + Flat Washer (Black) Pin shaft Belt support Phillips Screw +spring washer +flat Phillips screw(black) washer (White) Phillips screw(black) Bearing base Hex nut Belt Tracking knob Capacitor Rubber washer Capacitor support Ⅰ Tracking spring 01 01 01 17 BD370...
  • Page 21 Phillips Screw +spring washer +flat Hex Net (White) washer(Black) Inner Hex head bolt Hex head bolt+Spring washer (Black) Phillips Screw （Black) Drive belt cover Hex nut (black) Power Cord Strain relief assembly Ⅰ Protective board 01 01 01 18 BD370...

  • Page 22: Parts Diagram

    Parts Diagram BD370...
