Menu Hierarchy, Option Translation and Operation Information
To enter the menus, press the Edit key. Pressing Up/Down will cycle through the menus and
options, and the Edit key selects the options for editing or enters the displayed menu. Pressing Next will
back out of the current menu and save any updated parameters.
Alarm Menu (displayed as ALr) - the alarm menu contains options for changing the various
alarm parameters including alarm level, alarm color and trip settings
Alarm Level 1 (A1)
Alarm Level 2 (A2)
Alarm Level 3 (A3)
UM-1106
Trip Level (displayed as triP) - determines if alarm activates above or below
the alarm setpoint
High (Hi) - alarm level will trip when value is rising above the alarm
setpoint
Low (Lo) - alarm level will trip when value is falling below the alarm
setpoint
Setpoint (SEtP) - set this value to the desired alarm setpoint
The alarm menu contains options for changing the various alarm
parameters including alarm level, alarm color and trip settings and
contains Color Option.
Color (CoLr) - used to select the color of the display. Change the color
option by pressing the "EDIT" key. Color Option (coLr) Color options
available for this setpoint are: Red (rEd), Blue (bLuE) is red, orange, and
blue.
The alarm menu contains options for changing the various alarm
parameters including alarm level, alarm color and trip settings and
contains Color Option.
Color (CoLr) - used to select the color of the display. Change the color
option by pressing the "EDIT" key. Color Option (coLr) Color options
available for this setpoint are: Red (rEd), Blue (bLuE) is red, orange, and
blue.
3
