IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this
product or require any replacement
fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed
unless the item is found to be faulty. Should you need to return the unassembled product,
please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple
step by step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
• We recommend the use of the wall attachment bracket for safety reasons.
PRODUCT INFORMATION
Made in Poland.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down
the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
Avoid keeping furniturein direct sunlight or closeto any heat sources as this can cause cracking,
discolouration or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
All assembly fixings should always be tightened properly and periodically check all fixings and
tighten if necessary.
• The finish will mellow and change colour over time.
GLASS INFORMATION
This item contains glass. Please handle with extreme care.
Batch No: MM-42 , Date of Manufacture: May 2013
This unit contains safety film backed mirrored glass door panels of a nominal thickness of 3 mm
which are not required to be classified to BS 6206.
If a glass component is chipped or broken replace with glass of the type described on this label.
Consult the manufacturer, retailer or agent with regard to obtaining a manufacturing specification
and shape for replacement glass quoting the model number, and batch number or date of
manufacture.
852495 LINCOLN CNSL BKC
ASSEMBLY INSTRUCTIONS.
P9--LI 12
1 of 16

Advertisement

loading
Need help?

Need help?

Do you have a question about the 852495 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Next 852495

  • Page 1 852495 LINCOLN CNSL BKC ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction FLOOR AREA 3.0 M x 3,0 M 1.5 hrs 2 PERSON ASSEMBLY REQUIRED ASSEMBLY SPACE APPROXIMATE ASSEMBLY TIME REQUIRED ASSEMBLY TOOLS ASSEMBLED DIMENSIONS 1208 mm 280 mm 845 mm P9--LI 12 of 16...
  • Page 3: Parts List

    DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction PARTS LIST NO PART LIST (1) DRAWER SIDE L (2) DRAWER SIDE R (3) DRAWER BACK (4) DRAWER BOTTOM (5) DRAWER FRONT SIDE L SIDE R (8) TOP PANEL (9) HORIZONTAL DIVIDER (10) DOOR...
  • Page 4: Hardware List

    DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction HARDWARE LIST DO NOT MIX CONTENT OF HARDWARE BOXES wpm4x22 5x32 12x10 4x30 L-288mm CAM BOLT CAM LOCK SCREW DRAWER HANDLE SCREW MINI MINI BOTTOM SUPPORT BAG 6 BAG 6 BAG 6 BAG 7...
  • Page 5 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction HARDWARE LIST DO NOT MIX CONTENT OF HARDWARE BOXES 6,3x13 SCREW 8x28 5x39 15x12 HINGE PLATE BAG 4 BAG 4 DOWEL CAM BOLT CAM LOCK NYLON FEET BAG 1 BAG 1 BAG 1...
  • Page 6 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction Top Tips before you start! 1. Please check that all parts are present before you start the assembly of your furniture, as once assembed, the furniture is exempt from our home approval policy.
  • Page 7 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction SCREW IN CAM SCREWS PRESS IN CAM LOCKS. ARROW ON CAM ONLY DOWN TO FIRST RING. LOCK MUST FACE HOLE IN PANEL EDGE. FLUSH WITH DO NOT INSERT DOWELS PANEL IN CAM SCREW / LOCK HOLES.
  • Page 8 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction Instructions for hinge adjustment a) Side adjustment: Loosen fixing screw "A", adjust gap with screw "B" and retighten screw "A". b) Depth adjustment: Loosen fixing scerw "A", push hinge arm forwards or backwards, retighten screw "A", fix screw "B"...
  • Page 9 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction 1/2 TURN CLOCKWISE. P9--LI 12 of 16...
  • Page 10 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction 1x Left / 1x Right P9--LI 12 of 16...
  • Page 11 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction 1x Left / 1x Right P9--LI 12 of 16...
  • Page 12 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction P9--LI 12 of 16...
  • Page 13 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction 1/2 TURN CLOCKWISE. P9--LI 12 of 16...
  • Page 14 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction 1/2 TURN CLOCKWISE. B a c k p a n e l k e e p s u n i t s q u a r e . Ta c k b a c k p a n e l...
  • Page 15 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction NOT SUPPLIED Wall fixings are not supplied with this product as different wall materials require different types of fixing devices( such as Rawl plugs used on brick work).You must use fixing devices suitable for the type of wall you intend to mount this product to.
  • Page 16 DESCRIPTION: Assembly 852495 LINCOLN CNSL BKC Instruction P9--LI 12 of 16...
