- Page 1 All manuals and user guides at all-guides.com LCD TV LS15N13W LS17N13W Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. ON-SCREEN MENUS PC DISPLAY PICTURE IN PICTURE (PIP) TELETEXT...
-
Page 2: N Foreword I Caution
Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material. -
Page 3: Safety Instructions
All manuals and user guides at all-guides.com Safety Instructions These illustrations represent precautions concerning your TV. œ Do NOT expose the TV to extreme 35¡ temperature conditions or to extreme humidity conditions. 5¡ √ Do NOT expose the TV to direct sunlight. -
Page 4: Table Of Contents
All manuals and user guides at all-guides.com Contents OREWORD Caution ......................Safety Instructions ..................ONNECTING AND REPARING Viewing the Control Panel................Viewing the Connection Panel ............... - Connecting an Aerial or Cable Television Network........- Connecting DVD (or VCR)................- Connecting DTV Set-Top Box ..............- Connecting Computer................. - Page 5 All manuals and user guides at all-guides.com Contents SING THE ARIOUS UNCTIONS Changing the Sound Standard ................ Adjusting the Sound Settings ................Enjoying the Dolby Sound................Adjusting the Volume Automatically .............. Selecting the Melody Sound................Adjusting Your Headphone Preferences............Selecting the Sound Mode................Setting the Sleep Timer...................
-
Page 6: I Viewing The Control Panel
All manuals and user guides at all-guides.com Viewing the Control Panel Power TV/VIDEO DISPLAY STILL ❶ SOURCE ❹ M CH L P.STD S.STD Displays a menu of all of the available input Moves the selector up or down on the OSD. sources (TV, VIDEO, S-VIDEO, DVD(Component1), Increases or decreases the channel number. -
Page 7: I Viewing The Connection Panel
All manuals and user guides at all-guides.com Viewing the Connection Panel (continued) Option Power Input/Output ☛ Whenever you connect an audio or video system to your television, ensure that all elements are switched off. Refer to the documentation supplied with your equipment for detailed connection instructions and associated safety precautions. -
Page 8: Connecting An Aerial Or Cable Television Network
All manuals and user guides at all-guides.com Viewing the Connection Panel ❶ Connecting an Aerial or Cable Television Network To view television channels correctly, a signal must be received by the television from one of the following sources: - An outdoor aerial - A cable television network - A satellite network ❷... -
Page 9: Connecting External A/V Devices
All manuals and user guides at all-guides.com Viewing the Connection Panel ❺ Connecting External A/V Devices - Connect RCA or S-VIDEO cable to an appropriate external A/V device such as VCR, DVD, or Camcorder. - Connect RCA audio cables to “AUDIO(L)” and “AUDIO(R)” on the rear of your television and the other ends to corresponding audio out connectors on the A/V device. -
Page 10: I Attaching A Wall Or Arm Mounting Device
All manuals and user guides at all-guides.com Attaching a Wall or Arm Mounting Device This television supports VESA mounting standard for use with various VESA mounting devices. To install any VESA mounting device, please follow the instructions given. ( A ) ( B ) Lay the television face-down on a flat surface with a cushion or other soft materials to protect the screen. -
Page 11: I Installing Vesa Compliant Mounting Device
All manuals and user guides at all-guides.com Installing VESA Compliant Mounting Device Align the mounting interface pad with the holes in the rear cover mounting pad and secure it with the four screws that came with the arm-type base, wall mount hanger or other bases. Rear cover mounting pad Mounting English-11... -
Page 12: Viewing The Remote Control (All Functions Except Teletext)
All manuals and user guides at all-guides.com Viewing the Remote Control (All Functions Except Teletext) PC mode selection directly Power er Television On/Off Display the setting information TV/VIDEO TV/VIDEO PC PC DISPLA DISPLAY STILL STILL Available sources selection Picture freeze P.STD .STD S.STD... -
Page 13: Viewing The Remote Control (Teletext Functions)
All manuals and user guides at all-guides.com Viewing the Remote Control (Teletext Functions) Power er TV/VIDEO TV/VIDEO PC PC DISPLA DISPLAY STILL STILL P.STD S.STD Teletext next page Programme selection by name MENU Teletext previous page MUTE MUTE EXIT EXIT PRE-CH PRE-CH -/--... -
Page 14: I Inserting The Batteries In The Remote Control
All manuals and user guides at all-guides.com Inserting the Batteries in the Remote Control You must insert or replace the batteries in the remote control when you: N Purchase your television N Find that the remote control is no longer operating correctly Remove the cover on the rear of the remote control by pressing the symbol downwards and then pulling firmly to remove it. -
Page 15: I Becoming Familiar With The Remote Control
All manuals and user guides at all-guides.com Becoming Familiar with the Remote Control The remote control is used mainly to: N Change channels and adjust the volume N Set up your television using the on-screen menu system Power The following table presents the most frequently used buttons and TV/VIDEO TV/VIDEO PC PC... -
Page 16: Plug And Play
All manuals and user guides at all-guides.com Plug and Play When the television is initially powered on, three basic customer Power settings proceed automatically and subsequently: setting the language, Power Power channel and clock. TV/VIDEO TV/VIDEO PC PC DISPLA DISPLAY STILL STILL P.STD... -
Page 17: I Choosing Your Language
All manuals and user guides at all-guides.com Choosing Your Language Power Power Power TV/VIDEO DISPLAY STILL TV/VIDEO DISPLAY STILL TV/VIDEO DISPLAY STILL When you start using your television for the first time, you must select Power Power P.STD .STD S.STD .STD the language which will be used for displaying menus and indications. -
Page 18: I Storing Channels Automatically
All manuals and user guides at all-guides.com Storing Channels Automatically Power Power You can scan for the frequency ranges available to you (and availability depends on your country). Automatically allocated TV/VIDEO TV/VIDEO DISPLAY DISPLAY STILL STILL programme numbers may not correspond to actual or desired Power Power programme numbers. -
Page 19: I Storing Channels Manually
All manuals and user guides at all-guides.com Storing Channels Manually Power Power You can store up to 100 channels, including those received via cable networks. When storing channels manually, you can choose: N Whether or not to store each of the channels found Power Power TV/VIDEO... -
Page 20: I Giving Channels Names
All manuals and user guides at all-guides.com Giving Channels Names Power Power Power If channel name information is broadcast when you store the channels Power TV/VIDEO TV/VIDEO DISPLAY DISPLAY STILL STILL either manually or automatically, the names are assigned to the channels directly. -
Page 21: I Skipping Unwanted Channels
All manuals and user guides at all-guides.com Skipping Unwanted Channels Power Power You can exclude the channels you chosen from the channels you scanned. When you scan through the stored channels, those you have Power chosen to skip are not displayed. Power TV/VIDEO TV/VIDEO... -
Page 22: I Fine Tuning Channel Reception
All manuals and user guides at all-guides.com Fine Tuning Channel Reception Power Power If the reception is clear, you do not have to fine-tune the channel, TV/VIDEO TV/VIDEO DISPLAY DISPLAY STILL STILL as this is done automatically during the search and store operation. Power Power If however the signal is weak or distorted, you may have to fine-tune... -
Page 23: I Sorting The Stored Channels
All manuals and user guides at all-guides.com Sorting the Stored Channels Power Power You can exchange the numbers of two channels, in order to: N Modify the numeric order in which the channels have been Power Power automatically stored. TV/VIDEO TV/VIDEO DISPLAY DISPLAY... -
Page 24: Changing The Picture Standard
All manuals and user guides at all-guides.com Power Power Changing the Picture Standard Power Power TV/VIDEO DISPLAY STILL TV/VIDEO DISPLAY STILL You can select the type of picture which best corresponds to your P.STD S.STD TV/VIDEO DISPLAY STILL P.STD S.STD TV/VIDEO DISPLAY STILL... -
Page 25: Setting The Blue Screen
All manuals and user guides at all-guides.com Setting the Blue Screen Power Power If no signal is being received or the signal is very weak, a blue screen TV/VIDEO TV/VIDEO DISPLAY DISPLAY STILL STILL Power Power automatically replaces the noisy picture background. If you wish to continue viewing the poor picture, you must set the “Blue screen”... -
Page 26: Changing The Sound Standard
All manuals and user guides at all-guides.com Changing the Sound Standard Power Power TV/VIDEO TV/VIDEO DISPLAY DISPLAY STILL STILL Power Power You can select the type of special sound effect to be used when watching a given broadcast. P.STD P.STD S.STD S.STD TV/VIDEO... -
Page 27: Enjoying The Dolby Sound
All manuals and user guides at all-guides.com Power TV/VIDEO DISPLAY STILL P.STD S.STD Enjoying the Dolby Sound Power Power TV/VIDEO TV/VIDEO DISPLAY DISPLAY STILL STILL This feature provides a home theater-like Dolby effect by mixing the Power Power left and right speakers. P.STD P.STD S.STD... -
Page 28: Selecting The Melody Sound
All manuals and user guides at all-guides.com Power Power Selecting the Melody sound TV/VIDEO TV/VIDEO DISPLAY DISPLAY STILL STILL Power Power You can hear clear melody sound when the TV is powered on or off. P.STD P.STD S.STD S.STD TV/VIDEO TV/VIDEO DISPLAY DISPLAY... -
Page 29: Selecting The Sound Mode
All manuals and user guides at all-guides.com MUTE EXIT Selecting the Sound Mode -/-- PRE-CH The “DUAL I/II” button displays/controls the processing and output TTX/MIX TTX/MIX V.DOLBY .DOLBY of the audio signal. When power is switched on, the mode is automatically preset to either “Dual-I ”... -
Page 30: Setting And Displaying The Current Time
All manuals and user guides at all-guides.com Setting and Displaying the Current Time You can set the television’s clock so that the current time is displayed by Power Power pressing the “DISPLAY” button. You must also set the time if you wish to use the automatic on or off timers. -
Page 31: Switching The Television On And Off Automatically
All manuals and user guides at all-guides.com Switching the Television On and Off Automatically You can set the On/Off timers so that the television will: N Switch on automatically and tune to the channel of your choice at the time you select Power Power N Switch off automatically at the time you select... -
Page 32: Viewing The Picture In Picture (Pip)
All manuals and user guides at all-guides.com Viewing the Picture In Picture (PIP) Power Power You can display a sub picture within the main picture of TV program or Power Power external A/V devices such as VCR or DVD. In this way you can watch TV/VIDEO TV/VIDEO DISPLAY... -
Page 33: Selecting The Pip Sound
All manuals and user guides at all-guides.com MUTE EXIT Viewing the Picture In Picture (PIP) -/-- PRE-CH Easy functions of remote control TTX/MIX TTX/MIX V.DOLBY .DOLBY SLEEP SLEEP DU DUAL I/II AL I/II LIST/FLOF LIST/FLOF CANCEL CANCEL Buttons Feature P.SIZE .SIZE SIZE SIZE... -
Page 34: I Setting Up Your Pc Softerware (Based On Windows 98)
PC will probably be different, depending upon your particular version of Windows and your particular video card. But even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) First, click on “Settings” on the Windows start menu. -
Page 35: Adjusting The Screen Quality
All manuals and user guides at all-guides.com Power Power Adjusting the Screen Quality ➣ Preset to the PC mode by pressing the SOURCE button. TV/VIDEO DISPLAY STILL TV/VIDEO DISPLAY STILL This feature is used to fine tune and get the best image by removing Power Power noises that create unstable images with jitters and shimmers. -
Page 36: Adjusting The Screen Colour
All manuals and user guides at all-guides.com Power Power Adjusting the Screen Colour Power Power TV/VIDEO TV/VIDEO DISPLAY DISPLAY STILL STILL ➣ Preset to the PC mode by pressing the SOURCE button. TV/VIDEO TV/VIDEO DISPLAY DISPLAY STILL STILL P.STD P.STD S.STD S.STD Power... -
Page 37: Teletext Feature
All manuals and user guides at all-guides.com Teletext Feature Most television channels provide written information services via teletext. Information provided includes: N Television programme times N News bulletins and weather forecasts N Sports results N Travel information This information is divided into numbered pages (see diagram). Part Contents Selected page number. -
Page 38: Selecting A Page By Number
All manuals and user guides at all-guides.com Selecting a Page by Number Power TV/VIDEO DISPLAY STILL You can enter the page number directly by pressing the numeric P.STD .STD S.STD .STD buttons on the remote control. Enter the three-digit page number given in the content by pressing the corresponding numeric buttons. -
Page 39: Using Flof To Select A Page
All manuals and user guides at all-guides.com MUTE EXIT Using FLOF to Select a Page -/-- PRE-CH The various topics included in the teletext pages are colour-coded, TTX/MIX TTX/MIX V.DOLBY .DOLBY and can be selected by pressing the coloured buttons on the remote SLEEP SLEEP DU DUAL I/II... -
Page 40: I Troubleshooting: Before Contacting Service Personnel
All manuals and user guides at all-guides.com Troubleshooting: Before Contacting Service Personnel Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of your television and contact your local dealer. -
Page 41: I Powersaver
Vertical Sync Active Inactive Power Indicator Black Green, Blinking (1 sec interval) LS15N13W : 43W (Max.) Power Consumption Less than 1.5W LS17N13W : 49W (Max.) ➣ This set automatically returns to normal operation when horizontal and vertical sync return. This occurs when you move the computer’s mouse or press a key on the keyboard. -
Page 42: Technical And Environmental Specifications
All manuals and user guides at all-guides.com Technical and Environmental Specifications Model LS15N13W LS17N13W Panel Size 38.86cm Diagonal 43.18cm Diagonal Display Size 334.08 (H) x 200.448 (V) mm 370.56 (H) x 222.336 (V) mm Type a-si TFT active matrix Pixel Pitch 0.261 (H) x 0.261 (V) mm... -
Page 43: I Display Modes
All manuals and user guides at all-guides.com Display Modes If the signal from the system equals to the standard signal mode, the screen is adjusted automatically. If the signal from the system doesn’t equal to the standard signal mode, adjust the mode with referring to the Video card user guide because the screen might not display or only the power LED might be on. - Page 44 All manuals and user guides at all-guides.com - AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. ELECTRONICS BN68-00248H-03...
