ASTRA
VR
®
Endovaginal / Endorectal
Probe Reprocessor
Installation Manual
CIVCO Medical Solutions
102 First Street South
Kalona, IA 52247 USA
WWW.CIVCO.COM
Sales: info@civco.com
Copyright © 2017 All Rights Reserved.
Customer Service: info@civco.com
ASTRA® is a registered trademark of CIVCO Medical Solutions.
Technical Support: service@civco.com
All other trademarks are property of their respective owners.
Printed in the USA.
Phone: (800) 445-6741
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Civco ASTRA VR
Summary of Contents for Civco ASTRA VR
- Page 1 WWW.CIVCO.COM Sales: info@civco.com Copyright © 2017 All Rights Reserved. Customer Service: info@civco.com ASTRA® is a registered trademark of CIVCO Medical Solutions. Technical Support: service@civco.com All other trademarks are property of their respective owners. Printed in the USA. Phone: (800) 445-6741...
-
Page 2: Warnings And Cautions
This installation requires that appropriate plumbing and electrical supplies are present before connecting the ASTRA VR system. Installing the ASTRA VR system does not require specialized training. Contact CIVCO Medical Solutions with any questions or comments regarding the information contained in this manual at (800) 445-6741 or via email at info@civco.com. -
Page 3: Site Requirements & Specifications
ASTRA® VR Endovaginal/Endorectal Probe Reprocessor Installation Manual 3. SITE REQUIREMENTS & SPECIFICATIONS Actual Size (ASTRA VR): Width: 12.0” (30.5 cm) Depth: 14.0” (35.6 cm) Height: 53.0” (134.6 cm) Weight: 73 lbs. (33.1 kg) Minimum Clearances Required: Front: 12.0” (30.5 cm) Left: 12.0”... -
Page 4: Parts Required
ASTRA Troubleshooting Guide W0013 *Ensure all parts are available prior to attempting installation If there are any damaged or missing parts, please call Customer Service at CIVCO Medical Solutions (800) 445-6741. Required parts - NOT supplied by CIVCO Medical Solutions •... -
Page 5: Installation
5. INSTALLATION A. Typical Installation The ASTRA VR is a floor standing unit which requires a potable water supply, waste drain, and GFCI electrical connection all within 8ft (2.4 m) of the installation location. The ASTRA VR device is required to be mounted to the wall using a supplied wall bracket. Failure to follow these installation instructions may affect the operation and effectiveness of this device. - Page 6 ASTRA® VR Endovaginal/Endorectal Probe Reprocessor Installation Manual The device is supplied with 10ft. of 3/8” drain and water inlet hoses and connectors, and a 10 ft. removable hospital grade power cord. Use of the supplied power cord is required to maintain proper grounding and safe operation of the device.
- Page 7 B. Mounting the Unit Wall Bracket: The ASTRA VR requires clear wall space of 24” wide and 57” high. A wall bracket is shipped with the unit to hold the unit securely against the wall for added safety. Refer to Figure 2 for mounting location of the bracket.
-
Page 8: Electrical Connection
Switch on green illuminated power switch. If switch does not illuminate, make sure GFCI receptacle has been reset. CAUTION: Use of a power cord not supplied by CIVCO Medical Solutions may affect the safety and performance of this device. -
Page 9: Installation Checklist
Once the plumbing, electrical and mounting connections have been installed, a photograph of the installation should be taken, a list of probe models to be used with the ASTRA VR complied and the following completed checklist should be emailed to CIVCO Medical Solutions.
