Torrey WLS Installation Manual

WLS Scale
WLS Network Installation Guide
Windows 7 / Windows 8
I. Requirements Network.
For optimum performance connect the computer with one Ethernet cable and
the Wifi scales into a distance not greater than 50 feet from the Access Point Router
Linksys E1200 (Torrey Part No. 11900171).
Internet
II. Equipment.
- WLS scale.
- Personal Computer with Windows 7 or Windows 8.
- 2 Ethernet Network Cable, Category 5.
- Router Access Point Linksys E1200 (Torrey Part No.
- Internet connection.
III. Access Point / Router Configuration.
This procedure was performed using an Access Point Linksys E1200 (Torrey Part
# 11900171) has not been previously configured and a personal computer with
network card configuration-DHCP Client. In case your personal computer or access
point has a different configuration, consult the person who made the configuration
before proceeding.
a) Connect the network cable to the PC at one of the Ethernet ports on the
router. If you have an Internet connecting a network cable to the Internet
port.
b) Connect the power supplier to the Router to turn it on.
c) Enter in your computer, the CD-ROM that came with your Linksys
1
d) After reading the CD-ROM the following window appears, select the Install or
Run from media.
Rev. 1.0
e) The Router Configuration program opens the next window, mark the
checkbox to accept terms and press Next
11900171).
f) Check the connection is accorded to the below image and press the Next
button.
Router.
g) Make sure the connection is correct according to the image and press the
Next
button.
h) Then the Router asked to define the name and password of your wireless
network. Set the parameters and press the Next
Router name (SSID):
Password:
i) The Router will start to configure the wireless network, follow the
instructions at the end to close the
2
button.
button.
MyRouterWLS
12345678
program.
3
