QUICK REFERENCE GUIDE
This Quick Reference Guide DOES NOT replace the Operators
Manual. You MUST read ALL the disclaimers and safety and other
instructions in the Operators Manual before initially operating this
product. Accordingly, no legal claims can be entertained based on
the data, illustrations or descriptions in this Quick Reference Guide.
Static Dimensions
Tie Down Points
A. Restraint angular range
B. Restraint angular range 40 ° to 50 °
C. Front tie down points
D. Rear tie down points
E. Tie down restraint
Cab and Switch Panel
A. Steering wheel
B. Instrument panel
C. Multi-purpose steering column switch
D. Forward/reverse switch
E. Lift arm control lever
F. Right console switches
G. Creep speed control
H. Ignition switch
J. Hand throttle control
K. Park brake
L. Steering column adjustment
M. Accelerator pedal
N. Service brake pedal
P. Horn
Q. Front window blind
R. Cab interior light
S. Speakers
8° to 11 °
Access additional information
www.servicepro.jcb.com
Revision 1.0
12/2/2020
Instrument Panel
1. Battery/ Alternator no charge
2. Transmission Error/Fault
3. Transmission oil temperature
4. Park brake
5. Engine ECU fault/stop
6. Engine pre-heat
A. LCD Display
7. Engine fault
B. Fuel level gauge
8. Engine oil pressure
C. Engine temperature gauge
9. Engine air filter
10. Water in fuel
11. Smooth ride system
12. Hydraulic error/fault
13. Transmission oil pressure
14. Foot brake
15. Fuel level
16. Engine coolant temperature
17. Rear fog light
18. Main beam
19. Trailer direction indicators
20. Direction indicators
21. Hazard warning
Start Up Sequence
