88 5050 103
Modern Craftsman
3 Tier Tower
Important NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 Pc.
G.
Front Stretcher
1 Pc.
Hardware List
Hex Wrench
1 Pc.
Small
Hex Wrench
1 Pc.
Tools required for assembly : Phillips screwdriver
B.
Side Frame
1 Pc.
H.
Front Stretcher
2 Pcs.
Head Cap Bolt
Flat Washer
8 Pcs.(+1 extra)
8 Pcs.(+1 extra)
D.
Back Stretcher
1 Pc.
E.
Back Stretcher
1 Pc.
C.
Side Frame
1 Pc.
Spring Washer
Tapered Head Cap Bolt
8 Pcs.(+1 extra)
8 Pcs.(+1 extra)
Tools recommended for assembly : Level
F.
Back Frame
1 Pc.
I.
Shelf
2 Pcs.
Wood Screw (long)
Wood Screw (short)
6 Pcs.(+1 extra)
4 Pcs.(+1 extra)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Styles HS-5050
Summary of Contents for Home Styles HS-5050
- Page 1 88 5050 103 Modern Craftsman 3 Tier Tower IMPORTANT NOTE Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damage occurring to the parts. We have taken great care in the design of this product and request that you carefully and strictly follow our assembly instructions to ensure a completed product as it was designed.
- Page 2 Assembly Instructions 2 IMPORTANT * Please keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future. * Do not tighten up all the bolts until each part is properly assembled. * Use a soft cloth between these parts and the floor.
- Page 3 Assembly Instructions 3/3 STEP 3 Turn the unit over to its’ upright position. Place Top (A) and Shelves (I) into position. Wood Screw (short) STEP 4 Place Top (A) onto unit with Wood Screws (short). Attach Shelves (I) to unit with Wood Screws (long). To level the unit, adjust the adjustable levelers on the bottom of legs.
